The MOTOROLA MVME162-212 serves as a powerful processing hub in advanced VMEbus systems, featuring a 68060 microprocessor that represents a significant leap forward from the 68040-based modules in earlier MVME162 variants. This 66 MHz processor, with its superscalar architecture and enhanced floating-point unit, delivers approximately twice the computational throughput of its predecessors, enabling the MOTOROLA MVME162-212 to handle more complex control algorithms, faster data acquisition rates, and multitasking operations with greater efficiency.
Model Number MVME162-212
Brand Motorola
Type High-Performance VMEbus Single-Board Computer (SBC)
Processor Motorola 68060 (66 MHz) with enhanced floating-point unit
Memory 32 MB DRAM (expandable to 128 MB), 2 MB Flash EPROM
Operating Temp Range -10°C to 70°C (14°F to 158°F)
Mounting Style 6U VMEbus Chassis (3HE height)
Dimensions 233.7mm x 160mm (9.2″ x 6.3″)
Weight 380g (13.4 oz)
Interface/Bus VMEbus (32-bit, 80 MB/s), dual RS-232C/422, parallel I/O, SCSI-2, 10/100 Ethernet
Compliance UL 1950, CE, FCC Class A, ISO 9001, RoHS
Supported Protocols Modbus TCP/IP, PROFIBUS-DP, Ethernet/IP (via software), custom industrial protocols
Typical Power Draw 20W (max 25W under full load)
The MOTOROLA MVME162-212 serves as a powerful processing hub in advanced VMEbus systems, featuring a 68060 microprocessor that represents a significant leap forward from the 68040-based modules in earlier MVME162 variants. This 66 MHz processor, with its superscalar architecture and enhanced floating-point unit, delivers approximately twice the computational throughput of its predecessors, enabling the MOTOROLA MVME162-212 to handle more complex control algorithms, faster data acquisition rates, and multitasking operations with greater efficiency.
MVME162-212
What sets the MOTOROLA MVME162-212 apart is its expanded I/O and connectivity options. In addition to the standard serial and parallel interfaces, it incorporates a 10/100 Ethernet port (an upgrade from the 10Base-T in earlier models) and enhanced SCSI-2 functionality, supporting faster data transfer to external storage devices. These features allow it to communicate seamlessly with both legacy peripherals and modern networked systems, acting as a bridge between older VMEbus infrastructure and contemporary industrial networks. The board fits into standard 6U VMEbus chassis, maintaining compatibility with existing backplanes and adjacent modules, making it an ideal upgrade for facilities using earlier MVME162 or MVME147 series boards.
MVME162-212
Main features and advantages:
Choosing the MOTOROLA MVME162-212 delivers substantial advantages for organizations scaling their industrial operations. Its 68060 processor, with its ability to execute multiple instructions per clock cycle, enables the handling of more complex control logic—such as advanced PID algorithms for precision temperature control in semiconductor manufacturing—without sacrificing real-time performance. This computational power allows facilities to enhance process efficiency while retaining existing software written for 68k architectures, avoiding the cost and risk of complete application rewrites.
The MOTOROLA MVME162-212 also offers enhanced connectivity through its 10/100 Ethernet port, supporting faster data transfer to modern SCADA systems and cloud-based monitoring platforms. This feature is particularly valuable for facilities implementing industrial IoT (IIoT) initiatives, where real-time data analytics drive operational improvements. Its rugged design, tested to withstand industrial vibration, temperature extremes, and electromagnetic interference, ensures reliable operation in harsh environments, minimizing unplanned downtime. For maintenance teams, the board’s backward compatibility with existing VMEbus infrastructure simplifies upgrades, reducing installation time and ensuring a smooth transition.
MVME162-212
Technical specifications:
Model Number MVME162-212
Brand Motorola
Type High-Performance VMEbus Single-Board Computer (SBC)
Processor Motorola 68060 (66 MHz) with enhanced floating-point unit
Memory 32 MB DRAM (expandable to 128 MB), 2 MB Flash EPROM
Operating Temp Range -10°C to 70°C (14°F to 158°F)
Mounting Style 6U VMEbus Chassis (3HE height)
Dimensions 233.7mm x 160mm (9.2″ x 6.3″)
Weight 380g (13.4 oz)
Interface/Bus VMEbus (32-bit, 80 MB/s), dual RS-232C/422, parallel I/O, SCSI-2, 10/100 Ethernet
Compliance UL 1950, CE, FCC Class A, ISO 9001, RoHS
Supported Protocols Modbus TCP/IP, PROFIBUS-DP, Ethernet/IP (via software), custom industrial protocols
Typical Power Draw 20W (max 25W under full load)
Contact Us Phone:+86 16626708626 WeChat/WhatsApp:+86 16626708626 Email: 3772179818@qq.com
MVME162-212
Application areas:
The MOTOROLAMVME162-212 excels in applications where increased processing power and connectivity are critical. In semiconductor fabrication, it’s used in upgraded wafer processing control systems, where its high-speed processing manages the precise timing of lithography equipment and monitors multiple sensors simultaneously—improving yield rates while maintaining compatibility with legacy vacuum system controllers.
In water and wastewater treatment, the MOTOROLA MVME162-212 handles expanded monitoring networks, processing data from additional pH, turbidity, and flow sensors added during plant expansions. Its enhanced Ethernet connectivity enables real-time data transmission to centralized SCADA systems, supporting more informed decision-making and regulatory compliance reporting.
Aerospace and defense facilities also rely on the MOTOROLA MVME162-212 for test and measurement systems, where its computational power supports complex signal analysis and its rugged design ensures reliability in vibration-intensive environments. By integrating with existing test equipment, it enhances data collection capabilities without requiring complete system overhauls.
Related products:
MVME162-202 – Base model with 50 MHz 68060 processor, suitable for moderately demanding applications.
MVME162-211 – Predecessor to 212 with 66 MHz 68060 but limited Ethernet functionality.
MVME162-222 – Higher-performance variant with 80 MHz 68060, ideal for data-intensive tasks.
MVME162-031 – Earlier 68040-based model, upgradeable to MVME162-212 for increased performance.
MVME712D – Memory expansion module, doubling DRAM capacity when paired with MVME162-212.
MVME310B – High-precision analog I/O module, complementing MVME162-212 in process control systems.
MVME5600 – Advanced VME-to-Ethernet gateway, enhancing MVME162-212’s connectivity to modern networks.
MVME162-212-R – Refurbished version, certified for reuse in non-critical industrial systems with 1-year warranty.
Installation and maintenance:
Installing the MOTOROLA MVME162-212requires verifying that the target VMEbus chassis supports 32-bit operations and provides stable +5V, +12V, and -12V power within ±5% tolerance. Given its higher power draw compared to 68040-based models, ensure cooling systems can handle the additional heat—consider adding forced-air cooling in densely packed chassis. Before installation, update system firmware to the latest version compatible with the 68060 processor to fully utilize expanded memory and I/O features.
For ongoing maintenance, inspect edge connectors quarterly for corrosion or wear, cleaning with isopropyl alcohol as needed. Monitor memory performance using diagnostic software to detect early DRAM degradation. Replace electrolytic capacitors every 7–10 years as preventive maintenance. Always use anti-static equipment when handling the MOTOROLA MVME162-212 to avoid damage to sensitive components. Schedule firmware updates during planned shutdowns for 24/7 systems to minimize disruption.
