MIVII1000E00HI00 Distributed I/O Module

Description

MIVII1000E00HI00

The GE MIVII1000E00HI00 is a high-performance I/O module designed as a key component of GE’s Mark VIe control system, widely used in power generation and heavy industrial applications. As an intelligent input/output handler, it serves as the critical interface between field devices—such as sensors, transmitters, and actuators—and the central control processor. This module is fully integrated into GE’s PACSystems ecosystem, working seamlessly with Proficy Machine Edition software for configuration, programming, and diagnostics. In control system architecture, the GE MIVII1000E00HI00 acts as a distributed processing node, reducing data traffic to the central controller by performing local signal conditioning and basic control logic. Its value lies in combining high-density I/O capabilities with rugged construction, making it ideal for harsh industrial environments where reliability and space efficiency are paramount.

MIVII1000E00HI00

A defining strength of the GE MIVII1000E00HI00 is its advanced signal processing capability, delivering 16-bit resolution for analog inputs with a sampling rate of 100 ms per channel, ensuring accurate and timely data acquisition from critical process variables. The hardware design features a cast aluminum housing with conformal coating on circuit boards, providing protection against moisture, dust, and chemical contaminants commonly found in industrial environments.

MIVII1000E00HI00

Main features and advantages:

The module offers exceptional compatibility with industry-standard field devices through its support for multiple signal types, including 4-20 mA analog inputs, thermocouple signals, and RTD measurements. Its redundant communication capability via dual Ethernet ports ensures uninterrupted data transmission even in the event of a network fault. The GE MIVII1000E00HI00 also incorporates advanced diagnostics, including self-test routines and signal integrity monitoring, enabling predictive maintenance and reducing troubleshooting time.

MIVII1000E00HI00

Application fields:

In power generation facilities, oil and gas processing plants, and large-scale industrial complexes, reliable control systems are the backbone of safe and efficient operations. These high-stakes environments require control modules that can withstand extreme temperatures, maintain precise signal processing, and integrate with complex distributed control systems (DCS) without compromising performance. This is where the GE MIVII1000E00HI00 delivers exceptional value, serving as a critical I/O processing module in GE’s Mark VIe control system architecture. Used in industrial automation scenarios ranging from turbine control to boiler management, this module handles essential tasks like analog signal conversion, digital input monitoring, and real-time data transmission to central controllers. It addresses key industry challenges including signal noise in high-voltage environments, system redundancy requirements, and the need for seamless integration with legacy equipment. Engineers depend on the GE MIVII1000E00HI00 to maintain accurate control over critical processes, ensuring operational safety and minimizing unplanned downtime in mission-critical facilities.

MIVII1000E00HI00

Related products:

GE MIVIO1600E00HI00 – Digital output module that pairs with the GE MIVII1000E00HI00 to provide 16 relay outputs for control applications.

GE MIVID1600E00HI00 – Digital input module that works alongside the GE MIVII1000E00HI00 to monitor 16 discrete signals from field devices.

GE MIVIA800E00HI00 – Analog output module that complements the GE MIVII1000E00HI00 by providing 8 channels of 4-20 mA output signals.

GE MIVIC0100E00HI00 – Communication module that extends the GE MIVII1000E00HI00 with additional protocol support for legacy systems.

GE IC695PWR002 – Power supply unit specifically engineered to provide stable power to the GE MIVII1000E00HI00 and associated I/O modules.

GE IC695ETM001 – Ethernet switch module that creates a redundant network for the GE MIVII1000E00HI00 in critical control loops.

GE Proficy Machine Edition – Programming software required to configure and calibrate the GE MIVII1000E00HI00 module.

GE MIVIB1600E00HI00 – Specialty I/O module that connects to the GE MIVII1000E00HI00 for high-speed counter applications in motion control systems.
