The LCP100 is a compact local control panel, a versatile component designed for decentralized operation and monitoring in industrial automation systems. Unlike large central control consoles that require operators to be far from the machinery, this panel is engineered to be mounted directly on or near equipment, putting essential controls within arm’s reach of those who interact with the process daily.
Model LCP100
Brand Emerson
Type Compact Local Control Panel
Enclosure Material 304 Stainless Steel or Polycarbonate
Operating Temperature -20°C to 60°C (-4°F to 140°F)
Protection Rating IP65 (front panel), IP54 (rear when properly mounted)
Mounting Flush or surface mount (with optional brackets)
Dimensions 250 mm x 180 mm x 100 mm (W x H x D) – standard; custom sizes available
Weight 1.8 kg (stainless steel), 1.2 kg (polycarbonate)
Input Devices 4-8 momentary pushbuttons, 2-4 selector switches (configurable)
Indicators 6-12 LED indicators (red, green, yellow) for status display
Communication Digital I/O (standard); optional Modbus RTU (RS-485)
Power Supply 24 V DC (typically from machine control system)
Certifications CE, UL 508, CSA C22.2 No. 14
The LCP100 is a compact local control panel, a versatile component designed for decentralized operation and monitoring in industrial automation systems. Unlike large central control consoles that require operators to be far from the machinery, this panel is engineered to be mounted directly on or near equipment, putting essential controls within arm’s reach of those who interact with the process daily.
LCP100
It serves as a critical interface in automation architecture, connecting to PLCs or machine controllers via standard communication protocols to relay operator inputs and display real-time status information. What sets theLCP100 apart is its modular design, which allows customization of buttons, switches, and indicators to match specific machine requirements—whether controlling a single conveyor segment or a multi-stage packaging station. This adaptability makes it suitable for a wide range of applications, from simple on/off control to more complex operations involving multiple speed settings and fault reset functions. Its rugged construction ensures it can withstand the physical demands of factory floors, while its intuitive layout reduces operator training time—a key advantage for facilities with high turnover.
LCP100
Main features and advantages:
TheLCP100 delivers exceptional functionality through its thoughtful combination of input devices and visual indicators. It typically includes momentary pushbuttons for start/stop functions, selector switches for mode changes (such as automatic/manual), and illuminated indicators that clearly display machine status—whether running, stopped, or in fault. The panel’s tactile buttons provide positive feedback, ensuring operators can confirm their inputs even in noisy environments where auditory cues might be missed.
Hardware-wise, the LCP100 is built to last, with a stainless-steel or polycarbonate enclosure rated IP65, making it resistant to dust, water spray, and occasional splashes—critical for use in food processing or beverage bottling facilities where washdowns are common. Its compact size (typically under 300 mm in width) allows mounting in space-constrained areas, such as on conveyor frames or machine guards, without obstructing access to equipment.
Compatibility is another strength, as it integrates seamlessly with major PLC brands including Siemens, Allen-Bradley, and Mitsubishi via standard digital inputs/outputs or communication protocols like Modbus RTU. This flexibility means it can be added to existing systems with minimal reconfiguration, making it a cost-effective upgrade for improving operator interaction with automated machinery.
LCP100
Technical specifications:
Model LCP100
Brand Emerson
Type Compact Local Control Panel
Enclosure Material 304 Stainless Steel or Polycarbonate
Operating Temperature -20°C to 60°C (-4°F to 140°F)
Protection Rating IP65 (front panel), IP54 (rear when properly mounted)
Mounting Flush or surface mount (with optional brackets)
Dimensions 250 mm x 180 mm x 100 mm (W x H x D) – standard; custom sizes available
Weight 1.8 kg (stainless steel), 1.2 kg (polycarbonate)
Input Devices 4-8 momentary pushbuttons, 2-4 selector switches (configurable)
Indicators 6-12 LED indicators (red, green, yellow) for status display
Communication Digital I/O (standard); optional Modbus RTU (RS-485)
Power Supply 24 V DC (typically from machine control system)
Certifications CE, UL 508, CSA C22.2 No. 14
Contact Us Phone:+86 16626708626 WeChat/WhatsApp:+86 16626708626 Email: 3772179818@qq.com
LCP100
Application areas:
In the dynamic world of material handling systems, where precise control of conveyor belts, robotic arms, and sorting mechanisms determines operational efficiency, reliable local control panels are essential. Similarly, in packaging lines—where speed and accuracy in bottle filling, labeling, and cartoning directly impact production output—operators need intuitive interfaces to monitor and adjust processes on the fly. These industries, along with assembly plants and logistics hubs, rely on compact control solutions that can serve as the bridge between human operators and automated machinery, enabling quick interventions and ensuring smooth operations.
This is where the LCP100 shines. Used in industrial automation across manufacturing and material handling environments, it functions as a compact local control panel, putting critical operational controls and status monitoring directly at the point of operation. In warehouse conveyor systems, it allows operators to start/stop sections of the line, adjust speeds, and clear jams without returning to a central control room—reducing downtime and improving response times. In packaging facilities, its intuitive layout lets line workers monitor temperature settings on heat sealers and adjust filling parameters, ensuring product consistency without disrupting the entire line. The LCP100 is trusted because it doesn’t just provide buttons and indicators—it does so with the durability, flexibility, and user-centric design required in environments where operator efficiency and machine uptime are closely linked. Whether integrated into new automation setups or retrofitted onto legacy equipment, it’s a hands-on tool that engineers and operators alike depend on for seamless control.
LCP100
Related products:
LCP100-EXT – Extended version of the LCP100 with additional input devices for more complex machinery.
LCP100-T – Variant of the LCP100 with a small text display for showing numeric values like speed or temperature.
I/O-Module 200 – Digital input/output module that connects the LCP100 to PLCs without built-in I/O for the panel.
Mounting Bracket Kit MBK-100 – Optional accessory for secure surface mounting of the LCP100 on round or square machine frames.
Cable Harness CH-100 – Pre-wired cable assembly that simplifies connection between the LCP100 and control cabinets.
Emergency Stop Button ESS-01 – Compatible safety accessory that can be integrated into the LCP100 for emergency shutdowns.
Indicator Label Kit LK-100 – Customizable labels for the LCP100’s indicators, allowing quick updates to match process changes.
LCP100
Installation and maintenance:
Before installing the LCP100, verify that the mounting location provides easy access for operators without creating a safety hazard—ensure it’s positioned at a comfortable height (typically 1.2-1.5 meters from the floor) and clear of moving parts. Check that the surface is flat and sturdy enough to support the panel’s weight, especially for stainless-steel models. For washdown environments, use the supplied gasket and ensure all mounting screws are tightened to 2.5 Nm to maintain the IP65 rating. When wiring, separate power and signal cables to reduce electrical noise, and terminate connections with appropriate ferrules to prevent loose wires.
For maintenance, inspect the LCP100 quarterly for signs of physical damage to buttons or indicators, replacing any broken components promptly to maintain functionality. Clean the front panel with a mild detergent and soft cloth—avoid abrasive cleaners that could scratch the surface or damage labels. Check cable connections annually for tightness, especially in high-vibration areas, to prevent intermittent operation. If the panel includes a communication module, verify signal strength and error rates using the PLC’s diagnostic tools to ensure reliable data exchange between the LCP100 and the control system.
