LAM 853-150806-001 is a high-performance RF match network module, a core component of LAM Research’s etch system architecture. It serves as the critical link between the RF generator and the plasma chamber, tuning impedance to maximize power transfer efficiency—essential for creating stable plasma environments where etching occurs.
Model LAM 853-150806-001
Brand LAM Research
Type RF Match Network Module
Power Supply 48 V DC ± 5%
Operating Temperature 18°C to 45°C
Mounting Rack-Mount with Anti-Vibration Brackets
Dimensions 220 mm x 160 mm x 100 mm
Weight 2.1 kg
Interfaces Ethernet, RS-485, Analog Control Signals
Certifications SEMI S2/S3, CE, UL 61010
Cooling Forced Air (Integrated Fan)
Environmental Rating Class 1 Cleanroom Compatible
RF Frequency Range 13.56 MHz (Standard)
Power Handling Up to 3000 W
Impedance Tuning Range 50 to 500 ohms
LAM 853-150806-001 is a high-performance RF match network module, a core component of LAM Research’s etch system architecture. It serves as the critical link between the RF generator and the plasma chamber, tuning impedance to maximize power transfer efficiency—essential for creating stable plasma environments where etching occurs.
853-150806-001
Designed to integrate seamlessly with LAM’s Versys® and Sabre® etch platforms, this module acts as a dynamic regulator: it continuously adjusts to changes in chamber conditions (like gas composition or pressure) to maintain optimal RF coupling. For process engineers, its value lies in its ability to reduce process variability—directly translating to higher wafer yields. For integrators, its compatibility with LAM’s FabWorks® control software simplifies system integration, ensuring smooth communication with upstream process controllers. In short, LAM 853-150806-001 is the unsung hero that keeps plasma etch processes consistent, reliable, and repeatable.
853-150806-001
Main features and advantages:
At its core, LAM 853-150806-001 excels in dynamic impedance matching, with a response time of less than 50 microseconds—fast enough to counteract sudden plasma instabilities that could otherwise distort wafer features. This speed, paired with a tuning range of 50 to 500 ohms, allows it to adapt to varying process conditions, from low-power polysilicon etching to high-power metal etch steps.
Hardware design prioritizes the harsh realities of semiconductor cleanrooms. The module features a hermetically sealed aluminum housing with a specialized ceramic coating, resistant to corrosive byproducts from halogen-based process gases (like CF4 or Cl2). Its compact, modular build (30% smaller than older generations) fits into dense system racks, freeing up space for additional process monitoring tools.
Compatibility is a standout feature: LAM 853-150806-001 integrates with LAM’s RF generators (including the 2000W and 3000W models) and supports SECS/GEM protocols for seamless data flow to fab-wide MES systems. Long-term reliability is ensured by a built-in thermal management system that operates efficiently in 18°C to 45°C cleanroom environments, with a mean time between failures (MTBF) exceeding 150,000 hours—critical for minimizing unplanned downtime in 24/7 production cycles.
853-150806-001
Technical specifications:
Model LAM 853-150806-001
Brand LAM Research
Type RF Match Network Module
Power Supply 48 V DC ± 5%
Operating Temperature 18°C to 45°C
Mounting Rack-Mount with Anti-Vibration Brackets
Dimensions 220 mm x 160 mm x 100 mm
Weight 2.1 kg
Interfaces Ethernet, RS-485, Analog Control Signals
Certifications SEMI S2/S3, CE, UL 61010
Cooling Forced Air (Integrated Fan)
Environmental Rating Class 1 Cleanroom Compatible
RF Frequency Range 13.56 MHz (Standard)
Power Handling Up to 3000 W
Impedance Tuning Range 50 to 500 ohms
