Kollmorgen CB06561 PRD-B040SSLZ-62 Spring – applied, electrically released brake
The Kollmorgen CB06561 PRD-B040SSLZ-62 is a spring – applied, electrically released brake that has been meticulously engineered for light – to – medium – duty servo motor systems. It is part of Kollmorgen’s comprehensive range of motion control solutions, and its design is optimized to work in harmony with specific AKM series motors, such as the AKM32E – ANB2R – 00. This pairing results in a compact and efficient safety – critical subsystem that doesn’t sacrifice performance for size.
Model CB06561 PRD-B040SSLZ-62
Brand Kollmorgen
Type Spring – applied, electrically released brake
Rated Holding Torque 40 Nm
Engagement Time < 50 ms
Release Time < 30 ms
Voltage (Release) 24 V DC
Current (Release) 1.3 A
Operating Temperature – 10°C to 55°C
Storage Temperature – 40°C to 80°C
Weight 2.3 kg
Mounting Flange – mount (compatible with AKM30 series motors)
Protection Rating IP64
Friction Material High – performance, asbestos – free composite
The Kollmorgen CB06561 PRD-B040SSLZ-62 is a spring – applied, electrically released brake that has been meticulously engineered for light – to – medium – duty servo motor systems. It is part of Kollmorgen’s comprehensive range of motion control solutions, and its design is optimized to work in harmony with specific AKM series motors, such as the AKM32E – ANB2R – 00. This pairing results in a compact and efficient safety – critical subsystem that doesn’t sacrifice performance for size.
CB06561 PRD-B040SSLZ-62
Within a control system’s architecture, the Kollmorgen CB06561 PRD-B040SSLZ-62 functions as a highly responsive safety net. In the event of a power outage or a detected fault, it engages in a lightning – fast manner, typically within 50 milliseconds, bringing the connected motor to a halt. During normal operation, it releases smoothly, ensuring that the motor’s motion is not disrupted. Its compact and low – profile design allows for direct mounting onto compatible motor flanges without the need for additional adapters. This makes it an ideal choice for installations where space is at a premium, such as in collaborative robots that work side – by – side with human operators or in small – footprint benchtop automation equipment. Engineers value this brake for its ability to comply with stringent safety standards, including ISO 13849 – 1 Category 3. Moreover, it offers the flexibility to integrate with not only Kollmorgen’s own servo drives but also those from third – party manufacturers, providing more choices in system design.
CB06561 PRD-B040SSLZ-62
Main features and advantages:
One of the standout features of the Kollmorgen CB06561 PRD-B040SSLZ-62 is its ability to provide extremely stable torque during engagement. In applications where maintaining a consistent holding force is vital, such as in vertical axis applications where loads need to be suspended safely, this brake excels. Its advanced friction material and precision – engineered rotor design work in tandem to minimize torque fluctuations, ensuring that the load remains stationary even in the face of external vibrations or minor disturbances. This stability is a significant advantage over some competing products, which may experience torque variations that could potentially lead to load slippage or system instability.
Like other brakes in Kollmorgen’s lineup, it features a fail – safe spring – applied mechanism. When the power supply is interrupted, the springs automatically engage the brake, locking the motor shaft in place. This design ensures that the system remains in a safe state, preventing any unwanted movement that could cause damage to equipment or endanger personnel. Additionally, the Kollmorgen CB06561 PRD-B040SSLZ-62 is designed with energy efficiency in mind. Its release coil operates at a relatively low current of 1.3 A when powered by a 24 V DC supply. This not only reduces the overall power consumption of the system but also helps to minimize heat generation, contributing to longer – term reliability.
Durability is also a key aspect of this brake’s design. The friction surfaces are constructed from a high – quality, wear – resistant material that is rated for over 1.1 million cycles. This makes it suitable for applications where the brake is engaged and disengaged frequently, such as in automated sorting systems or continuous – motion conveyors. The brake housing is IP64 rated, providing protection against dust and water splashes, which is essential for use in a wide range of industrial environments, from dusty factories to facilities where occasional water sprays may occur.
CB06561 PRD-B040SSLZ-62
Technical specifications:
Model CB06561 PRD-B040SSLZ-62
Brand Kollmorgen
Type Spring – applied, electrically released brake
Rated Holding Torque 40 Nm
Engagement Time < 50 ms
Release Time < 30 ms
Voltage (Release) 24 V DC
Current (Release) 1.3 A
Operating Temperature – 10°C to 55°C
Storage Temperature – 40°C to 80°C
Weight 2.3 kg
Mounting Flange – mount (compatible with AKM30 series motors)
Protection Rating IP64
Friction Material High – performance, asbestos – free composite
In the intricate realm of industrial automation, where seamless operation and precise control are the cornerstones of efficiency, the Kollmorgen CB06561 PRD-B040SSLZ-62 emerges as a crucial enabler. Consider a high – speed labeling machine in the consumer goods industry, where labels must be applied with pinpoint accuracy to thousands of products per hour. The Kollmorgen CB06561 PRD-B040SSLZ-62 ensures that the labeling heads come to an immediate and stable halt between label applications, preventing misalignments that could lead to product recalls or wasted materials.
In the field of laboratory robotics, where delicate samples are being manipulated, this component plays a pivotal role. For instance, in an automated liquid handling system, it secures the robotic arms in place when dispensing minute volumes of reagents, safeguarding against even the slightest movement that could compromise experimental results. It’s also indispensable in the electronics manufacturing sector, where printed circuit boards are being assembled. Here, it stops the pick – and – place machines precisely, allowing for the accurate placement of tiny components like microchips and resistors. From precision assembly lines to automated inspection stations, the Kollmorgen CB06561 PRD-B040SSLZ-62 is designed to meet the demands of applications that require both reliability and high – speed response.
CB06561 PRD-B040SSLZ-62
Related products:
Kollmorgen CB06560 PRD-B040SAIB-62 – A related model with a slightly different design, offering a similar torque rating but with different application – specific features. It may be more suitable for applications where a different level of precision or environmental resistance is required.
Kollmorgen AKM32E – ANB2R – 00 – A primary servo motor that pairs well with the Kollmorgen CB06561 PRD-B040SSLZ-62. The flange dimensions of this motor are optimized for direct mounting of the brake, ensuring a seamless mechanical connection.
Kollmorgen AKD – N00407 – DSEC – E000 – A servo drive that can be integrated with the Kollmorgen CB06561 PRD-B040SSLZ-62 and the AKM32E – ANB2R – 00 motor. It synchronizes the brake release and motor startup processes, enabling smooth and vibration – free operation.
Kollmorgen BCS – 03 – A brake control module specifically designed to monitor the health and status of the Kollmorgen CB06561 PRD-B040SSLZ-62. It can detect issues such as coil failures or abnormal friction wear, providing valuable diagnostic information to the overall control system.
Kollmorgen CAB – BRK – 4M – S – A shielded cable set that is ideal for connecting the brake to the servo drive. The cable’s shielding helps to reduce electromagnetic interference, ensuring reliable communication and operation, especially in environments with a high electromagnetic field.
Kollmorgen S700 – 300 – A motion controller that can be used to coordinate the operation of multiple axes in a system that includes the Kollmorgen CB06561 PRD-B040SSLZ-62. It can precisely time the brake engagement and disengagement, optimizing the overall motion control performance.
Kollmorgen BRK – CLEAN – 01 – A cleaning kit designed specifically for the Kollmorgen CB06561 PRD-B040SSLZ-62. This kit contains specialized cleaning agents and tools that can be used to maintain the brake’s performance in cleanroom or high – hygiene environments.
Installation and maintenance:
Before installing the Kollmorgen CB06561 PRD-B040SSLZ-62, it is crucial to ensure that the motor shaft (compatible with the AKM32E – ANB2R – 00) is in perfect condition. Any burrs or imperfections on the shaft can cause uneven wear on the brake’s inner components and lead to reduced performance or premature failure. Use a fine – grit sandpaper to gently smooth out any rough spots, and then clean the shaft thoroughly with a suitable solvent. When mounting the brake to the motor flange, use the provided mounting hardware and torque the bolts to 15 Nm. Over – torquing can cause the brake flange to distort, which may result in noisy operation or inconsistent braking performance.
For maintenance, it is recommended to inspect the friction surfaces every 12,000 cycles or 7 months, whichever comes first. Look for signs of excessive wear, such as uneven grooves or a significant reduction in the thickness of the friction material. The minimum safe thickness of the friction material for this model is 1.2 mm. If the thickness drops below this value, the friction pads should be replaced. Regularly check the resistance of the release coil using a multimeter. The target resistance at 25°C is 18 ohms. Any deviation of more than ±10% from this value may indicate a problem with the coil, such as a short circuit or an open circuit. In dusty environments, use a compressed air gun with a filter attachment to clean the ventilation ports of the brake housing at least once a month. This helps to prevent dust from accumulating inside the brake, which could affect its performance. When the brake is paired with an AKM motor, perform a full – cycle test every quarter. This involves engaging and disengaging the brake multiple times while monitoring the motor’s performance to ensure that there are no issues with the braking or releasing mechanisms.
