KJ3242X1-FA1 Enhanced Redundant Communication Module
Sale!
KJ3242X1-FA1 Enhanced Redundant Communication Module
The Emerson KJ3242X1-FA1 is a next-generation enhanced redundant communication module, a key element of Emerson’s Ovation distributed control system—a platform renowned for its advanced performance in high-risk industrial settings. Unlike standard redundant communication modules that focus solely on basic failover capabilities, this module is engineered with advanced signal processing and enhanced redundancy features, making it the ideal choice for applications where data accuracy and system availability are paramount.
Model KJ3242X1-FA1
Brand Emerson
Type Enhanced Redundant Communication Module
Communication Channels 2 independent high-speed Ethernet channels
Data Transfer Rate 1 Gbps per channel
Operating Temperature -40°C to 85°C (-40°F to 185°F)
Mounting Ovation Advanced I/O rack (4U form factor)
Dimensions 250 mm x 120 mm x 180 mm (W x H x D)
Weight 2.2 kg
Supported Protocols Modbus TCP/IP, OPC UA, DNP3, PROFINET, Ovation LinkCertifications IEC 61508 (SIL 3 capable), UL 1604, ATEX, IECEx, ISO 14001
Redundancy Switchover Time ≤5 ms
Power Supply 24 V DC (dual redundant inputs with surge protection)
Environmental Rating IP66 front panel, NEMA 4X compliant
The Emerson KJ3242X1-FA1 is a next-generation enhanced redundant communication module, a key element of Emerson’s Ovation distributed control system—a platform renowned for its advanced performance in high-risk industrial settings. Unlike standard redundant communication modules that focus solely on basic failover capabilities, this module is engineered with advanced signal processing and enhanced redundancy features, making it the ideal choice for applications where data accuracy and system availability are paramount.
KJ3242X1-FA1
It plays a central role in Ovation system architecture, acting as a high-performance redundant data conduit between the primary controller, I/O modules, and critical peripheral devices such as safety instrumented systems (SIS) and real-time data historians. What distinguishes the Emerson KJ3242X1-FA1 is its intelligent dual-core processing architecture, which independently manages each communication channel while cross-verifying data integrity at the packet level. This ensures that even minor data corruptions are detected and corrected before they reach the controller. If a channel fault is identified—whether due to severe electromagnetic interference, cable degradation, or hardware malfunction—the module switches to the secondary channel in under 5 milliseconds, with zero data loss. This ultra-fast failover is crucial in industries like chemical processing, where a brief data gap could result in process excursions beyond safe operating limits. Its seamless integration with Ovation’s advanced diagnostic suite also allows engineers to monitor channel performance metrics in real time, such as signal-to-noise ratio and packet error rate, enabling predictive maintenance to prevent potential failures.
KJ3242X1-FA1
Main features and advantages:
The Emerson KJ3242X1-FA1 delivers exceptional performance with a data transfer rate of up to 1 Gbps per channel, ensuring that large volumes of high-resolution data—such as multi-point temperature profiles from industrial furnaces or continuous emissions data from power plant stacks—are transmitted without latency. Its hardware design is optimized for extreme environments: a reinforced titanium-alloy chassis with a specialized anti-corrosive coating, and an IP66-rated front panel that can withstand high-pressure water jets and prolonged exposure to harsh chemicals, making it suitable for installation in areas with frequent washdowns or corrosive atmospheres.
Compatibility is a major strength, as it integrates seamlessly with all current and legacy Ovation controller models and supports a comprehensive range of industry-standard protocols, including Modbus TCP/IP, OPC UA, DNP3, and PROFINET. This broad protocol support allows it to connect effortlessly with third-party equipment, such as advanced analytics platforms and enterprise resource planning (ERP) systems, eliminating the need for custom interface development in complex multi-vendor environments. For example, in waste-to-energy plants, it can simultaneously transmit operational data to the Ovation DCS for process control and to a regulatory reporting system, ensuring compliance with environmental standards.
Long-term reliability is engineered into every aspect of the Emerson KJ3242X1-FA1. It operates efficiently in an extended temperature range of -40°C to 85°C, making it suitable for both freezing cold storage areas and high-temperature process zones in industrial plants. Its advanced thermal management system, which combines passive heat sinks with heat pipes, ensures efficient cooling without the need for fans, reducing the risk of mechanical failure in dusty or humid environments. With a mean time between failures (MTBF) exceeding 500,000 hours, it is designed to outlast the typical 20-year lifecycle of industrial control systems, minimizing replacement costs and unplanned downtime.
KJ3242X1-FA1
Technical specifications:
Model KJ3242X1-FA1
Brand Emerson
Type Enhanced Redundant Communication Module
Communication Channels 2 independent high-speed Ethernet channels
Data Transfer Rate 1 Gbps per channel
Operating Temperature -40°C to 85°C (-40°F to 185°F)
Mounting Ovation Advanced I/O rack (4U form factor)
Dimensions 250 mm x 120 mm x 180 mm (W x H x D)
Weight 2.2 kg
Supported Protocols Modbus TCP/IP, OPC UA, DNP3, PROFINET, Ovation LinkCertifications IEC 61508 (SIL 3 capable), UL 1604, ATEX, IECEx, ISO 14001
Redundancy Switchover Time ≤5 ms
Power Supply 24 V DC (dual redundant inputs with surge protection)
Environmental Rating IP66 front panel, NEMA 4X compliant
Contact Us Phone:+86 16626708626 WeChat/WhatsApp:+86 16626708626 Email: 3772179818@qq.com
KJ3242X1-FA1
Application areas:
In the high-pressure environments of chemical processing plants, where a single communication failure between reactor control systems and safety shutdown mechanisms could lead to hazardous material releases, reliable data transmission is a non-negotiable safety imperative. Similarly, in large-scale power generation facilities—especially those operating with fossil fuels or biomass—seamless communication between boiler control systems and emissions monitoring equipment is critical for maintaining compliance with strict environmental regulations. These industries, along with waste-to-energy plants and industrial incinerators, rely on communication modules that can function as the nervous system of their distributed control systems (DCS), ensuring that critical operational data flows without interruption, even in the face of electrical noise, temperature extremes, and mechanical stress.
This is where the Emerson KJ3242X1-FA1 proves its mettle. Deployed in industrial automation across high-risk process environments, it serves as an enhanced redundant communication interface within Emerson’s Ovation DCS, providing a robust and secure data pathway that prioritizes both safety and efficiency. In chemical processing plants, it ensures that pH and pressure readings from corrosive material reactors are transmitted to the main control system without delay, enabling immediate adjustments to prevent chemical imbalances. In power generation facilities, its advanced filtering capabilities eliminate electrical noise from generators, ensuring that emissions data from continuous emissions monitoring systems (CEMS) remains accurate and compliant with regulatory reporting requirements. The Emerson KJ3242X1-FA1 is trusted because it doesn’t merely transmit data—it does so with the enhanced redundancy, noise immunity, and durability required in environments where communication integrity directly impacts worker safety, regulatory standing, and operational continuity. Whether integrated into new DCS implementations or upgrading legacy systems, it is a cornerstone component that engineers depend on for unwavering connectivity.
KJ3242X1-FA1
Related products:
Emerson KJ3241X1-EA1 – High-performance primary communication module that pairs with the Emerson KJ3242X1-FA1 to form a complete redundant communication system with enhanced data processing capabilities.
Emerson KJ2002X1-BA1 – Advanced Ovation controller that leverages the Emerson KJ3242X1-FA1’s high-speed redundant channels for real-time process control.
Emerson KJ1502X1-BC1 – High-accuracy analog input/output module whose data is transmitted via the Emerson KJ3242X1-FA1 for enhanced reliability in critical control loops.
Emerson SK-P303 – Advanced power distribution unit that provides conditioned, redundant power to the Emerson KJ3242X1-FA1, ensuring stable operation even during voltage fluctuations.
Emerson 14205-01-01 – High-performance shielded Ethernet cable with enhanced noise rejection, designed for connecting the Emerson KJ3242X1-FA1 to remote switches in high-interference environments.
Emerson VE5001S1-BA1 – Advanced remote HMI terminal that receives data through the Emerson KJ3242X1-FA1 for high-resolution monitoring in critical process areas.
Emerson 3500/53 – Advanced machinery protection system that uses the Emerson KJ3242X1-FA1 to transmit high-speed vibration data with redundant paths for enhanced equipment safety.
KJ3242X1-FA1
Installation and maintenance:
Before installing the Emerson KJ3242X1-FA1, ensure that the Ovation Advanced I/O rack backplane firmware is version 8.2 or higher to fully support the module’s enhanced communication features and high-speed data transfer capabilities. Verify that the mounting surface is perfectly flat and securely anchored, as any warping or movement can affect the module’s internal alignment in high-vibration environments such as near large pumps or compressors. For installations in chemical processing areas with corrosive vapors, apply the specialized chemical-resistant coating (part number 1231-CR) to the chassis before mounting, and use nickel-plated hardware to prevent corrosion. When routing cables, maintain a minimum separation of 500 mm between the two communication channels to avoid cross-talk, and terminate each channel to separate, redundant Ethernet switches with independent power sources to ensure true physical redundancy.
For maintenance, perform monthly checks of the module’s status indicators to confirm that both channels are operating optimally—steady blue lights indicate normal operation, while a flashing red light signals a critical channel fault that requires immediate attention. Utilize Ovation’s Advanced Redundancy Monitoring Tool bi-monthly to log detailed performance metrics, including channel latency, packet error rates, and switchover times. Consistently elevated error rates or switchover times exceeding 5 ms may indicate the need for cable replacement, connector cleaning, or module calibration. In environments with high levels of dust or chemical residues, inspect the front panel filters quarterly and replace them with genuine Emerson filters (part number F450-02) when clogged. While the module is designed for minimal maintenance, schedule a comprehensive calibration check every 3 years by certified Emerson technicians to ensure continued compliance with performance specifications.
