IS420ESWBH2A High performance Ethernet switch

Description

IS420ESWBH2A is a high-performance Ethernet switch specifically designed for industrial applications, belonging to the Mark VIe series designed by General Electric. In the network architecture of industrial automation, it is a critical node for data transmission, responsible for connecting various devices and building an efficient data transmission network.

IS420ESWBH2A

This switch is equipped with two 100Base FX multimode ports, which can be used for long-distance data transmission and are particularly suitable for scenarios that require stable communication between different areas or devices. At the same time, it also has 16 10/100Base TX copper cable ports (RJ-45 interfaces), which can easily connect various industrial equipment such as PLCs, sensors, actuators, etc., meeting diverse network access needs.

IS420ESWBH2A

Technical specifications:
Model Number IS420ESWBH2A
Brand GE
Type Unmanaged Industrial Ethernet Switch
Interface/Bus 16 10/100Base TX copper cable ports (RJ-45), 2 100Base FX multimode fiber ports (LC interface)
Compliance complies with relevant industry standards, such as CE, etc
Supported Protocols supports commonly used industrial Ethernet protocols

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

IS420ESWBH2A

Main features and advantages:
Firstly, its efficient data transmission capability ensures the timeliness and accuracy of data exchange between devices, greatly improving production efficiency. A stable network connection effectively reduces the number of production interruptions caused by communication issues, lowers the defect rate, and thus improves product quality. The unmanaged design feature makes the installation and deployment process extremely simple, without the need for professional network engineers to perform complex configurations, and can quickly build a reliable industrial network, saving a lot of manpower and time costs.
The durability design of this switch, including the high number of RJ45 connector insertions and good anti-interference performance, enables it to operate stably in harsh industrial environments for a long time, reducing the frequency of equipment maintenance and replacement and lowering overall operating costs. In addition, its flexible port configuration can meet the access needs of different industrial equipment, whether it is the construction of new automation projects or the upgrading and transformation of existing systems, it can be easily adapted, providing strong support for the digital transformation of industrial enterprises.

IS420ESWBH2A

Application areas:
In the automotive manufacturing industry, automated production lines are highly complex and numerous devices require real-time collaborative work. This switch can ensure high-speed and stable data transmission between various workstations on the production line, ensuring precise control of the automotive production process and improving the production efficiency and quality consistency of automobiles.
In the chemical industry, the production environment is often accompanied by high temperature, high pressure, and complex electromagnetic interference. IS420ESWBH2A, with its excellent anti-interference ability and stable performance, can still operate normally under such harsh working conditions, transmit key production data in real time, and provide reliable network guarantee for the safety and stability of chemical production.
In the energy and power industry, both real-time monitoring of equipment operation status by power plants and rapid collection and processing of power data by grid dispatch centers rely on stable network communication. The IS420ESWBH2A switch can meet these demanding communication requirements, laying a solid foundation for the reliable operation of energy and power systems.

IS420ESWBH2A

Related products:
IS420ESWBH1A – With relatively few port configurations, it is suitable for small industrial automation scenarios that require small network sizes and limited budgets.
IS420ESWBH3A – Based on IS420ESWBH2A, the number of fiber ports has been increased or certain performance has been optimized to meet the strong demand for long-distance and high-speed data transmission in large-scale industrial projects.
IS420ESWCH2A – In industries with extremely high requirements for network security, this version may enhance network security protection capabilities.
IS420ESWDH2A – Improved heat dissipation design, more suitable for operation in high-temperature environments, such as the metallurgical industry and other high-temperature work scenarios.
IS420ESWBE2A – With stronger network management capabilities, although it has increased configuration difficulty compared to IS420ESWBH2A, it is more suitable for large enterprises that require refined network management.
IS420ESWBF2A – Optimized in power management with lower power consumption, suitable for green industrial projects with strict energy consumption restrictions.
IS420ESWBG2A – Enhanced compatibility with third-party devices to better integrate into complex heterogeneous network environments and connect more industrial equipment of different brands and types.

Installation and maintenance:
Before installing the IS420ESWBH2A industrial Ethernet switch, engineers need to do a lot of preparation work. Firstly, it is necessary to carefully inspect the installation environment to ensure that there is sufficient space and good ventilation and heat dissipation conditions in the installation location, in order to avoid the performance of the switch being affected by overheating during operation. Confirm the power supply status of the system, ensure that the input voltage matches the rated voltage of the switch completely, and prevent equipment damage due to abnormal voltage. At the same time, it is necessary to conduct a comprehensive evaluation of the existing industrial network architecture, clarify the network requirements and topology of each device, in order to plan the port connections of switches reasonably. In addition, checking whether the hardware appearance of the switch is damaged and whether the accessories are complete is also an essential step.
Regularly checking the status indicator lights of the switch is a key operation during daily maintenance. Under normal circumstances, the indicator light will flash according to a specific pattern. By observing the status of the indicator light, it is possible to quickly determine whether the switch is working properly. For example, if the indicator light corresponding to a certain port is not on, it may indicate that there is a problem with the connection of that port, and it is necessary to check whether the connecting cable is loose or damaged. Every once in a while, conduct a comprehensive inspection of the port connections of the switch to ensure that all connecting cables are secure and reliable. At the same time, it is important to keep the switch clean and avoid dust accumulation that could affect device heat dissipation and performance. It is recommended to conduct regular network performance tests on switches, such as data transmission rate tests, packet loss rate tests, etc., to promptly identify potential network issues and optimize them.
