IS215UCCCS05A High performance Mark VIE safety controller board

Description

IS215UCCCS05A is a high-performance Mark VIE safety controller board designed as the core of General Electric’s (GE) advanced control system. It is located at the center of the security control layer in the automation stack, serving as a central hub for monitoring, analyzing, and executing safety critical operations. This board can seamlessly connect with various input/output devices, sensors, and actuators, ensuring accurate collection of safety related data and real-time processing.

IS215UCCCS05A

It supports redundant configuration, which means that if the motherboard fails, the backup card can immediately take over, thereby maintaining system integrity without any interruption. IS215UCCCS05A is also equipped with an advanced diagnostic system that can continuously monitor its own status and connected devices, providing detailed error codes and alerts to help engineers quickly identify and solve problems. It follows industry standard safety protocols and is compatible with various safety instrumented systems in different industrial applications.

IS215UCCCS05A

Technical specifications:
Model: IS215UCCCS05A
Brand: General Electric (GE)
Type: Mark VIE Safety Controller Board
Input voltage: 24V DC
Working temperature range: -40 ° C to+85 ° C
Installation method: rack installation
Size: 200 x 150 x 30 millimeters
Weight: 1.2 kilograms
Interface/Bus: VMEbus
Compliance: CE, RoHS, IEC 61508 (Safety Integrity Level 3)
Supported protocols: Modbus, Profibus
Typical power consumption: 15 W

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

IS215UCCCS05A

Main features and advantages:
Its sturdy and durable structural design can withstand harsh industrial environments, ensuring long-term reliable operation, reducing component replacement frequency and related maintenance costs. The redundant design and advanced diagnostic functions of this board significantly improve system availability, minimize unplanned downtime, and ensure continuous operation. By simplifying the security control process and providing accurate and real-time data, it can achieve faster decision-making and improve overall operational efficiency. In addition, its compatibility with multiple protocols and systems simplifies the integration process, reduces engineering costs, and facilitates the extension of existing control settings.

、IS215UCCCS05A

Application areas:
In power plants, it is crucial to maintain the safety of turbines, generators, and the power grid, ensuring that protective measures can be immediately activated in the event of abnormalities.
In chemical plants, it monitors and controls the process flow, prevents the leakage and reaction of hazardous chemicals, and ensures the safety of personnel and the environment. For offshore oil drilling platforms operating under extreme conditions, this safety controller board ensures the continuous and safe operation of key equipment from drilling machinery to oil processing units. It can operate reliably in high temperature, high humidity, and vibration prone environments, making it an ideal choice for any industry that requires extremely high safety and continuous operation time.

Related products:
IS215UCCCS01A – With fewer input/output channels, it is suitable for small safety control applications.
IS215UCCCS03A – Provides enhanced processing speed, suitable for applications that require fast data analysis and decision-making.
IS215UCCCS07A – With additional communication interfaces, it provides greater flexibility for integration with various field devices.
IS215UCCCS09A – With improved diagnostic capabilities, it enables deeper system health monitoring.
IS215UCCCS11A – Designed specifically for high-density installations, it provides a more compact form factor without compromising performance.

Installation and maintenance:
Before installing IS215UCCCS05A, engineers must carefully verify the compatibility of its VMEbus with existing system components to ensure that electrical specifications and data transmission rates match. It is crucial to check the firmware version of the board and connected devices, as outdated firmware may cause communication issues or reduced functionality. In a closed control cabinet, it is necessary to ensure sufficient ventilation around the chassis to prevent overheating.
For continuous maintenance, regular inspection of the LED indicator lights on the board is crucial for quickly identifying any abnormal operating conditions. Regular inspection of connectors for signs of wear and corrosion, as well as annual system integrity testing, will help maintain their optimal performance throughout the lifespan of IS215UCCCS05A.
