IS215ACLEH1A Industrial Relay Output Module

Description

IS215ACLEH1A

The GE IS215ACLEH1A is a robust relay output module belonging to GE’s IS215 series, specifically engineered to provide reliable switching capabilities for industrial control applications. As a dedicated interface between control systems and high-power devices, it converts low-voltage control signals from programmable logic controllers (PLCs) or distributed control systems (DCS) into mechanical relay actuation, enabling safe control of external electrical loads.

IS215ACLEH1A

This module features multiple relay channels, each capable of handling significant current loads, making it versatile for various industrial applications. What distinguishes the GE IS215ACLEH1A is its combination of rugged design and intelligent monitoring features, including relay status feedback that provides confirmation of load activation to the control system. Its seamless integration with GE’s control platforms allows engineers to configure, monitor, and troubleshoot relay operations through standard software interfaces.

Main features and advantages:

The GE IS215ACLEH1A delivers exceptional switching performance with each relay channel capable of handling up to 10A at 250V AC, making it suitable for controlling a wide range of industrial equipment from small motors to heating elements. Its hardware design features a reinforced metal housing with advanced electromagnetic interference (EMI) shielding, protecting sensitive control circuitry from electrical noise generated by high-power devices and motor drives. This module operates reliably across an extended temperature range of -5°C to 60°C, ensuring consistent performance in both climate-controlled enclosures and harsh industrial environments.

A key strength is its built-in diagnostic capabilities, including relay contact wear monitoring and overcurrent detection that provide early warning of potential failures through the control system. The GE IS215ACLEH1A also features visible LED indicators for each relay channel, allowing for quick visual status verification during maintenance checks. With its pluggable terminal design, the module simplifies wiring and replacement, reducing downtime during installation or maintenance procedures.

Application fields:

In modern industrial facilities such as large-scale manufacturing plants, water treatment facilities, and automated material handling systems, precise control over electrical loads and equipment activation is essential for maintaining operational efficiency and safety. These environments require reliable relay modules that can switch high-power devices while integrating seamlessly with distributed control systems, even in the presence of electrical noise and mechanical vibration. The GE IS215ACLEH1A addresses this critical need, serving as a high-performance relay output module within GE’s industrial control architecture. Whether controlling motor starters in production lines, activating solenoid valves in water treatment processes, or managing heating elements in industrial ovens, this module ensures safe and reliable switching of electrical loads. Used extensively in industrial automation across manufacturing, utilities, and building management sectors, the GE IS215ACLEH1A solves the challenge of bridging low-voltage control signals with high-power industrial equipment, making it an essential component for automated control systems.

Related products:

GE IS210AEPSG1BCA – Power supply module that provides stable 24V DC to the GE IS215ACLEH1A.

GE IS210AEBIH3BED – Analog input module that works with the GE IS215ACLEH1A in closed-loop control systems.

GE IS200WETBHIB – Communication module enabling status monitoring of the GE IS215ACLEH1A via Ethernet.

GE IS210VCMIH1BED – Control module that sends command signals to the GE IS215ACLEH1A in automation systems.

GE IS210TBSCH3B – Terminal base providing secure wiring connections for the GE IS215ACLEH1A.

GE IS200VIBAH1D – Isolation module enhancing noise immunity for the GE IS215ACLEH1A in high-EMI environments.

GE IS210MDIOH2BED – Diagnostic module that monitors relay status from the GE IS215ACLEH1A.

GE IS215DIOAH1A – Digital input module that works with the GE IS215ACLEH1A for complete I/O solutions.

Installation and maintenance:

Before installing the GE IS215ACLEH1A, ensure the control cabinet provides adequate space with a minimum of 30mm clearance around the module to prevent heat buildup, especially when controlling multiple high-current loads. Verify that the mounting rail is securely fastened to a grounded metal surface to maximize EMI shielding effectiveness. When wiring, use appropriately sized conductors (minimum 16AWG for load connections) and ensure proper wire termination torque (0.5-0.6 Nm) to prevent connection heating. Separate control signal wiring from load wiring within the cabinet to minimize electrical noise interference, and use strain relief for all external connections to prevent terminal damage from vibration.

For maintenance, perform monthly visual inspections to check for loose connections, signs of overheating (discoloration), and verify LED status indicators match system feedback for the GE IS215ACLEH1A. Utilize the control system’s diagnostic tools quarterly to monitor relay contact resistance trends, which can indicate early wear. When replacing the module, document all wiring connections beforehand and ensure power is disconnected from both control and load circuits. Consider cleaning relay contacts periodically using manufacturer-recommended procedures for critical applications, and replace the module if consistent contact resistance increases are detected, as this indicates potential contact degradation.
