IS200TREGH1BDC Terminal Base with Integrated Power Regulation

Description

IS200TREGH1BDC

The GE IS200TREGH1BDC is a specialized terminal base module with integrated power regulation capabilities, designed as a key connectivity component within GE’s Mark VIe control system architecture. More than just a standard terminal block, it functions as an integrated power distribution and signal termination solution optimized for systems requiring regulated 24V DC power delivery to connected modules.

IS200TREGH1BDC

This terminal base integrates seamlessly with GE’s industrial ecosystem, serving as the connection point for modules like the GE IS200TDBTH6ACD high-density terminal base, digital output modules, and communication interfaces. What makes the GE IS200TREGH1BDC invaluable for system integrators is its combination of secure signal termination with built-in power regulation, eliminating the need for separate power distribution components in space-constrained cabinets.

Main features and advantages:

The GE IS200TREGH1BDC delivers exceptional performance through its dual-purpose design that handles both signal termination (32 channels) and regulated power distribution. Its integrated power regulation circuitry provides stable 24V DC output with ±2% tolerance, protecting connected modules from voltage fluctuations common in industrial environments. The terminal base features isolated power and signal pathways that prevent electromagnetic interference between power distribution and signal lines, ensuring clean data transmission even when power demands fluctuate. Its precision terminal design includes captive screws with wire guides that simplify installation and maintain consistent connection quality across all terminals.

Hardware-wise, the GE IS200TREGH1BDC features a ruggedized thermoplastic housing with UL94 V-0 flame rating, capable of operating in extreme temperatures from -40°C to +85°C. Its DIN rail mounting system includes anti-vibration hardware that maintains stable connections in high-motion environments like turbine halls. The terminal base incorporates dedicated power distribution busses with overcurrent protection that safeguard connected modules from power surges, while its clear labeling and color-coded terminals simplify installation and troubleshooting. Its compact design integrates power regulation components without sacrificing connection density, making it ideal for space-constrained control cabinets.

Application fields:

In industrial automation systems where precise power distribution and signal integrity are critical, terminal bases that combine secure connections with power regulation capabilities provide essential operational stability. Power plants managing sensitive turbine control electronics, manufacturing facilities coordinating distributed I/O networks, and chemical processing plants operating safety-critical instrumentation all require specialized terminal solutions that can handle both signal and power distribution without interference. This is where the GE IS200TREGH1BDC excels, serving as an integrated connection and power regulation hub designed for applications where reliable power delivery is as important as signal transmission.

In power generation environments, the GE IS200TREGH1BDC provides regulated power distribution to system health monitors like the GE IS200ESYSH1AAA while maintaining secure signal connections from critical sensors. In factory automation setups, it delivers stable power to remote I/O modules and control components, preventing voltage fluctuations that could disrupt production line synchronization. Used in industrial automation across heavy industries, the GE IS200TREGH1BDC acts as a dual-function hub that streamlines both power and signal pathways, reducing installation complexity in systems where reliable power distribution is mission-critical.

Related products:

GE IS200TDBTH6ACD – High-density terminal base that integrates with the GE IS200TREGH1BDC in large systems.

GE IS200ESYSH1AAA – System health monitor that receives regulated power through the GE IS200TREGH1BDC.

IS200EPSMG2A – Power supply module that connects to the GE IS200TREGH1BDC for distributed power regulation.

IS200JPDFG1A – Digital output module whose power and signal connections use the GE IS200TREGH1BDC.

IS200TREGH1BDB – Previous generation regulated terminal base compatible with the GE IS200TREGH1BDC.

IS200ERIOH1ABB – Remote I/O module that utilizes the GE IS200TREGH1BDC for power and signal termination.

IS200EGPAG1BCA – Ethernet gateway whose power is regulated by the GE IS200TREGH1BDC.

Installation and maintenance:

Before installing the GE IS200TREGH1BDC, ensure the mounting rail is properly secured with additional support brackets to handle the module’s weight plus connected wiring. Verify input power compatibility with the facility’s 24V DC supply, ensuring it falls within the 18–30V DC range for proper regulation. When connecting field devices, separate power and signal wiring pathways to minimize interference, following the terminal base’s color-coded guidance. Torque power terminals to 0.8–1.0 Nm and signal terminals to 0.5–0.7 Nm using a calibrated torque screwdriver, ensuring proper contact without terminal damage.

For maintenance, perform monthly visual inspections of the GE IS200TREGH1BDC to check power LED status indicators and secure connections. Measure output voltage quarterly using a calibrated multimeter to ensure regulation remains within the ±2% tolerance range. Clean terminal blocks semi-annually with compressed air, ensuring power is disconnected before cleaning. Inspect overcurrent protection components annually for signs of activation, replacing if necessary. When upgrading system components, verify compatibility with the GE IS200TREGH1BDC’s power capacity to prevent overload conditions.
