HONEYWELL MC-TAIH02 High-Voltage and High-Temperature Temperature Input Module
The HONEYWELL MC-TAIH02 is a high-voltage and high-temperature tolerant temperature input module, purpose-built as an integral part of Honeywell’s advanced industrial control systems, such as the TDC 3000 and Experion PKS platforms. Its core function is to interface with a variety of temperature sensors (including thermocouples and RTDs) in high-voltage and high-temperature industrial settings. It then isolates, amplifies, and conditions the incoming temperature signals before converting them into digital data that can be readily processed by distributed control systems (DCS).
Model MC-TAIH02
Brand Honeywell
Type High-Voltage and High-Temperature Temperature Input Module
Power Supply 24 V DC (18 – 30 V DC range)
Operating Temperature Range -50°C to 125°C (-58°F to 257°F)
Number of Channels 8 (independently configurable)
Sensor Types Supported J, K, T, E thermocouples; 2-wire, 3-wire, 4-wire RTDs
Isolation Rating 3000 V RMS (channel-to-channel and channel-to-backplane)
Accuracy ±0.1°C (over operating temperature range)
Resolution 24 bits
EMI/RFI Immunity High (complies with industry standards)
Dimensions 180 mm x 120 mm x 250 mm (W x H x D)
Weight 2.2 kg (4.85 lbs)
Mounting DIN rail (35 mm) or rack mount
Interfaces Backplane connector (compatible with TDC 3000/Experion racks)
Certifications CE, UL, CSA, IEC 61010-1 (CAT III 600 V equivalent for electrical safety)
Cooling Passive (conduction and radiation-based)
The HONEYWELL MC-TAIH02 is a high-voltage and high-temperature tolerant temperature input module, purpose-built as an integral part of Honeywell’s advanced industrial control systems, such as the TDC 3000 and Experion PKS platforms. Its core function is to interface with a variety of temperature sensors (including thermocouples and RTDs) in high-voltage and high-temperature industrial settings. It then isolates, amplifies, and conditions the incoming temperature signals before converting them into digital data that can be readily processed by distributed control systems (DCS).
MC-TAIH02
What makes the HONEYWELLMC-TAIH02 stand out is its ability to operate in extreme conditions, with a temperature range of -50°C to 125°C and the capacity to handle electrical isolation up to 3000 V RMS. This makes it suitable for use in areas where standard modules would quickly succumb to the harsh environment. It integrates smoothly with Honeywell’s suite of control and monitoring software, as well as third-party SCADA systems, providing industrial operators and engineers with a robust solution for temperature monitoring in high-risk areas. Whether it’s being installed in a newly commissioned industrial complex or retrofitted into an existing aging infrastructure, the HONEYWELL MC-TAIH02 offers the reliability and performance required for critical temperature monitoring applications.
MC-TAIH02
Technical specifications:
Model MC-TAIH02
Brand Honeywell
Type High-Voltage and High-Temperature Temperature Input Module
Power Supply 24 V DC (18 – 30 V DC range)
Operating Temperature Range -50°C to 125°C (-58°F to 257°F)
Number of Channels 8 (independently configurable)
Sensor Types Supported J, K, T, E thermocouples; 2-wire, 3-wire, 4-wire RTDs
Isolation Rating 3000 V RMS (channel-to-channel and channel-to-backplane)
Accuracy ±0.1°C (over operating temperature range)
Resolution 24 bits
EMI/RFI Immunity High (complies with industry standards)
Dimensions 180 mm x 120 mm x 250 mm (W x H x D)
Weight 2.2 kg (4.85 lbs)
Mounting DIN rail (35 mm) or rack mount
Interfaces Backplane connector (compatible with TDC 3000/Experion racks)
Certifications CE, UL, CSA, IEC 61010-1 (CAT III 600 V equivalent for electrical safety)
Cooling Passive (conduction and radiation-based)
Contact Us Phone:+86 16626708626 WeChat/WhatsApp:+86 16626708626 Email: 3772179818@qq.com
MC-TAIH02
Main features and advantages:
One of the most remarkable aspects of the HONEYWELL MC-TAIH02is its outstanding signal handling and environmental resilience. The module is equipped with 8 independent channels, each featuring dedicated isolation circuitry. This not only shields the control system from electrical transients but also ensures that individual channel failures do not impact the overall operation. Each channel can be configured to accept different types of temperature sensors, such as J, K, T, and E type thermocouples, as well as 2-wire, 3-wire, and 4-wire RTDs. This flexibility eliminates the need for multiple specialized modules, streamlining the system design. From a hardware perspective, the HONEYWELL MC-TAIH02 sports a ruggedized enclosure made of high-grade stainless steel, which can withstand the rigors of industrial environments. It is designed to resist vibrations, shocks, and chemical corrosion, making it suitable for installation in areas with frequent mechanical disturbances or exposure to industrial chemicals. The module also incorporates a unique heat dissipation mechanism that allows it to operate efficiently even in high-temperature surroundings, without the need for additional cooling systems in most cases.
Reliability is the cornerstone of the HONEYWELL MC-TAIH02‘s design. It comes equipped with advanced self-diagnostic features that continuously monitor for sensor faults, signal drift, and power supply irregularities. In the event of any anomalies, it can immediately send out real-time alerts to the DCS, enabling operators to take prompt corrective action. The module utilizes a high-resolution 24-bit analog-to-digital converter, which provides exceptional measurement accuracy of ±0.1°C over a wide temperature range. This level of precision is crucial in applications where even a small temperature variation can have significant consequences. Additionally, the HONEYWELL MC-TAIH02 has a high immunity to electromagnetic interference (EMI) and radio-frequency interference (RFI), ensuring that the temperature readings remain accurate even in the presence of strong electrical fields. It also supports hot-swapping, allowing for module replacement during system operation without disrupting the critical temperature monitoring process, which is essential for maintaining continuous production in 24/7 industrial facilities.
