HONEYWELL HCIX15-TE-FA-NC Humidity and Temperature Sensor
Sale!
HONEYWELL HCIX15-TE-FA-NC Humidity and Temperature Sensor
The HONEYWELL HCIX15-TE-FA-NC is a high-accuracy humidity and temperature sensor, specifically designed to integrate with industrial control systems and provide critical environmental data for process optimization. Its primary role is to measure relative humidity (RH) and ambient temperature, converting these physical parameters into a 4-20 mA analog output signal that can be easily interpreted by DCS, PLCs, or building management systems.
Model HCIX15-TE-FA-NC
Brand Honeywell
Type Humidity and Temperature Sensor
Power Supply 24 V DC (12–30 V DC range)
Operating Temperature Range -40°C to 85°C (-40°F to 185°F)
Humidity Measurement Range 0–100% RH
Humidity Accuracy ±2% RH (25°C, 20–80% RH); ±3% RH (0–100% RH)
Temperature Accuracy ±0.3°C (0–65°C); ±0.5°C (-40–85°C)
Output Signal 4-20 mA (dual signal: humidity and temperature via scaling)
Response Time <5 seconds (63% of step change, moving air)
Dimensions 45 mm x 35 mm x 20 mm (W x H x D)
Weight 25 g (0.88 oz)
MountingSurface mount (screw or adhesive)
Certifications CE, UL, RoHS, IP65
Housing Material Polycarbonate
Cable Length 1.5 m (standard); custom lengths available
The HONEYWELL HCIX15-TE-FA-NC is a high-accuracy humidity and temperature sensor, specifically designed to integrate with industrial control systems and provide critical environmental data for process optimization. Its primary role is to measure relative humidity (RH) and ambient temperature, converting these physical parameters into a 4-20 mA analog output signal that can be easily interpreted by DCS, PLCs, or building management systems.
HCIX15-TE-FA-NC
What distinguishes the HONEYWELL HCIX15-TE-FA-NC is its combination of precision and ruggedness, making it suitable for both indoor and semi-outdoor industrial environments. It integrates seamlessly with Honeywell’s Experion PKS, as well as third-party control platforms, providing engineers and facility managers with actionable data to maintain optimal conditions. Whether deployed in a new facility or retrofitted into an existing climate control system, the HONEYWELL HCIX15-TE-FA-NC delivers consistent performance that industrial operators can depend on.
HCIX15-TE-FA-NC
Main features and advantages:
A key strength of the HONEYWELL HCIX15-TE-FA-NC is its exceptional measurement accuracy. The sensor provides humidity readings with an accuracy of ±2% RH (at 25°C, 20-80% RH) and temperature measurements within ±0.3°C, ensuring that even small deviations from setpoints are detected promptly. This level of precision is crucial in applications like semiconductor manufacturing, where minor humidity fluctuations can affect wafer etching processes. Hardware-wise, the HONEYWELL HCIX15-TE-FA-NC features a compact, IP65-rated enclosure that protects against dust and water jets, making it suitable for use in food processing areas or outdoor kiosks. Its robust design includes a polycarbonate sensor housing that resists chemical exposure, ensuring long-term stability in environments with occasional contact with cleaning agents or mild industrial fluids.
The HONEYWELL HCIX15-TE-FA-NC also stands out for its reliability and ease of integration. It operates on a 24 V DC power supply, compatible with standard industrial power systems, and outputs a 4-20 mA signal that can be directly connected to most control systems without the need for additional converters. The sensor’s response time of less than 5 seconds (for 63% of step change) ensures that rapid environmental shifts—such as those caused by equipment malfunctions—are quickly detected, allowing for timely corrective actions. Its long-term stability (less than 1% RH drift per year) reduces the need for frequent recalibration, lowering maintenance costs over the sensor’s lifespan.
HCIX15-TE-FA-NC
Technical specifications:
Model HCIX15-TE-FA-NC
Brand Honeywell
Type Humidity and Temperature Sensor
Power Supply 24 V DC (12–30 V DC range)
Operating Temperature Range -40°C to 85°C (-40°F to 185°F)
Humidity Measurement Range 0–100% RH
Humidity Accuracy ±2% RH (25°C, 20–80% RH); ±3% RH (0–100% RH)
Temperature Accuracy ±0.3°C (0–65°C); ±0.5°C (-40–85°C)
Output Signal 4-20 mA (dual signal: humidity and temperature via scaling)
Response Time <5 seconds (63% of step change, moving air)
Dimensions 45 mm x 35 mm x 20 mm (W x H x D)
Weight 25 g (0.88 oz)
MountingSurface mount (screw or adhesive)
Certifications CE, UL, RoHS, IP65
Housing Material Polycarbonate
Cable Length 1.5 m (standard); custom lengths available
Contact Us Phone:+86 16626708626 WeChat/WhatsApp:+86 16626708626 Email: 3772179818@qq.com
HCIX15-TE-FA-NC
Application areas:
In industrial facilities where precise humidity and temperature control directly impact product quality and equipment performance, a reliable sensing solution is non-negotiable. Consider a pharmaceutical manufacturing cleanroom, where maintaining humidity levels between 45-55% and temperatures at 22°C ±1°C is critical for ensuring the stability of sensitive medications. Or a data center housing server racks, where excessive humidity can cause corrosion of electrical components, while high temperatures risk thermal throttling of equipment. These are the environments where the HONEYWELL HCIX15-TE-FA-NC excels, serving as a precision monitoring tool in industrial automation systems. Used in industrial automation setups ranging from food storage facilities to electronics production lines, the HONEYWELL HCIX15-TE-FA-NC is engineered to provide accurate, real-time measurements of both humidity and temperature, enabling systems to adjust climate controls proactively. It’s particularly valuable in applications where space is limited but the need for reliable environmental data is high, such as in compact control panels or modular processing units. The HONEYWELL HCIX15-TE-FA-NC addresses the challenge of maintaining optimal conditions in diverse industrial settings, helping to reduce waste, extend equipment life, and ensure regulatory compliance.
HCIX15-TE-FA-NC
Related products:
HONEYWELL HCIX15-TE-FA-IP – Similar to the HONEYWELL HCIX15-TE-FA-NC but with an IP67 rating for fully outdoor or wet environments.
HONEYWELL HCIX20-TE-FA-NC – Higher-range variant of the HONEYWELL HCIX15-TE-FA-NC with extended temperature tolerance up to 100°C.
HONEYWELL HC-AM-01 – Amplifier module that conditions the HONEYWELL HCIX15-TE-FA-NC’s output for long cable runs (over 100 m).
HONEYWELL HC-CAL-02 – Calibration kit specifically designed for verifying the accuracy of the HONEYWELL HCIX15-TE-FA-NC.
HONEYWELL HC-ISO-03 – Isolation module that protects the HONEYWELL HCIX15-TE-FA-NC from electrical noise in high-EMI environments.
HONEYWELL HC-MUX-04 – Multiplexer that allows up to 4 HONEYWELL HCIX15-TE-FA-NC sensors to share a single input channel on a PLC.
HONEYWELL HC-ENET-01 – Ethernet converter that converts the HONEYWELL HCIX15-TE-FA-NC’s 4-20 mA signal to IP-based data for remote monitoring.
HONEYWELL HC-ALARM-01 – Local alarm module that triggers visual/audio alerts when the HONEYWELL HCIX15-TE-FA-NC detects out-of-range conditions.
HCIX15-TE-FA-NC
Installation and maintenance:
Before installing the HONEYWELL HCIX15-TE-FA-NC, ensure the mounting location is representative of the environment being monitored—avoid placing it near heat sources (such as motors) or direct air vents, which can skew readings. For best accuracy, position the sensor at least 1.5 meters above the floor and away from walls by 30 cm to ensure proper air circulation. When wiring the HONEYWELL HCIX15-TE-FA-NC to the control system, use shielded twisted-pair cable to minimize electromagnetic interference, especially in areas with nearby variable frequency drives or high-voltage equipment. The sensor’s 1.5 m cable can be extended using compatible connectors, but ensure total resistance in the loop does not exceed 500 ohms to maintain signal integrity.
For maintenance, schedule annual calibration checks of the HONEYWELL HCIX15-TE-FA-NC using a calibrated reference hygrometer and thermometer, particularly in environments with high chemical exposure, which may accelerate drift. Conduct quarterly visual inspections to check for dust buildup on the sensor’s vent openings—gently clean with compressed air if necessary, taking care not to damage the internal sensing element. Verify the 4-20 mA output signal using a multimeter during each inspection to ensure it corresponds accurately to known humidity and temperature values. The HONEYWELL HCIX15-TE-FA-NC is designed for a service life of 5+ years under normal operating conditions, with replacement of the sensing element recommended if calibration errors exceed ±3% RH or ±0.5°C.
