The HONEYWELL FC-TSRO-0824 is a high-performance time-synchronized relay output module, specifically designed as part of Honeywell’s Experion Process Knowledge System (PKS) to provide precise control of electromechanical devices in distributed control systems (DCS). Its primary role is to receive digital commands from the central controller and actuate relays, which in turn control external equipment such as motors, valves, and alarm systems.
Model FC-TSRO-0824
Brand Honeywell
Type Time-Synchronized Relay Output Module
Power Supply 24 V DC (18–30 V DC range)
Operating Temperature -40°C to 70°C (-40°F to 158°F)
Mounting DIN rail (35 mm)
Dimensions 150 mm x 190 mm x 90 mm (W x H x D)
Weight 1.5 kg (3.31 lbs)
Relay Outputs 8 timed (time-synchronized), 24 general-purpose
Relay Rating 5 A @ 250 V AC, 5 A @ 30 V DC
Time Synchronization IEEE 1588 PTP (±1 µs accuracy)
Interface to DCSEthernet/IP, Modbus TCP/IP
Response Time <1 ms from command to relay actuation
Certifications CE, UL, CSA, ATEX Zone 2, IEC 61010
Cooling Passive (conduction-based)
Environmental Rating IP20 (when mounted in enclosure)
The HONEYWELL FC-TSRO-0824 is a high-performance time-synchronized relay output module, specifically designed as part of Honeywell’s Experion Process Knowledge System (PKS) to provide precise control of electromechanical devices in distributed control systems (DCS). Its primary role is to receive digital commands from the central controller and actuate relays, which in turn control external equipment such as motors, valves, and alarm systems.
FC-TSRO-0824
What sets the HONEYWELL FC-TSRO-0824 apart is its configuration of 8 timed relay outputs and 24 general-purpose relay outputs, making it a versatile solution for systems requiring both scheduled operations and immediate response actions. It integrates seamlessly with Honeywell’s Control Station and Sequence of Events (SOE) recorder, as well as third-party DCS platforms through standard protocols, providing engineers and integrators with flexibility in system design. Whether deployed in new installations or as an upgrade to legacy systems, the HONEYWELLFC-TSRO-0824 delivers the reliability and precision that industrial control demands.
FC-TSRO-0824
Main features and advantages:
A key strength of the HONEYWELL FC-TSRO-0824is its exceptional relay performance and timing accuracy. The 8 timed relay outputs offer microsecond-level synchronization, ensuring that coordinated actions—such as the simultaneous activation of multiple valves in a filling process—occur with minimal skew, reducing product waste and improving process consistency. Each relay contact is rated for 5 A at 250 V AC, allowing the HONEYWELL FC-TSRO-0824 to directly control small to medium-sized motors and actuators without the need for intermediate contactors, simplifying system design. Hardware-wise, the module features a rugged design with arc-suppression circuitry, extending relay life by minimizing contact wear during switching. Its compact form factor, measuring 150 mm in width, allows for easy installation in crowded control cabinets, while its modular construction enables quick replacement of individual relay modules if needed.
Reliability and diagnostic capabilities are central to the HONEYWELL FC-TSRO-0824’s design. It includes built-in monitoring of relay contacts, continuously checking for welds, excessive resistance, or coil failures, and providing real-time alerts to the controller if issues are detected. The module’s time-synchronization feature, using IEEE 1588 Precision Time Protocol (PTP), ensures that relay actions are coordinated across the entire system, critical for applications such as synchronized shutdowns in emergency situations. The HONEYWELL FC-TSRO-0824 also supports manual override functionality, allowing operators to actuate relays locally for troubleshooting or maintenance without disrupting the overall control system. Like other Honeywell modules, it supports hot-swapping, enabling replacement during operation to minimize downtime—a vital feature in 24/7 production environments.
FC-TSRO-0824
Technical specifications:
Model FC-TSRO-0824
Brand Honeywell
Type Time-Synchronized Relay Output Module
Power Supply 24 V DC (18–30 V DC range)
Operating Temperature -40°C to 70°C (-40°F to 158°F)
Mounting DIN rail (35 mm)
Dimensions 150 mm x 190 mm x 90 mm (W x H x D)
Weight 1.5 kg (3.31 lbs)
Relay Outputs 8 timed (time-synchronized), 24 general-purpose
Relay Rating 5 A @ 250 V AC, 5 A @ 30 V DC
Time Synchronization IEEE 1588 PTP (±1 µs accuracy)
Interface to DCSEthernet/IP, Modbus TCP/IP
Response Time <1 ms from command to relay actuation
Certifications CE, UL, CSA, ATEX Zone 2, IEC 61010
Cooling Passive (conduction-based)
Environmental Rating IP20 (when mounted in enclosure)
