HONEYWELL FC-SDO-0824 high-performance analog output module
Sale!
HONEYWELL FC-SDO-0824 high-performance analog output module
The HONEYWELL FC-SDO-0824 is a high-performance analog output module, specifically designed as part of Honeywell’s Experion Process Knowledge System (PKS) to serve as a key control component in distributed control systems (DCS). Its primary function is to receive digital commands from the central controller, convert them into precise analog signals, and transmit these signals to various field devices such as control valves, variable frequency drives, and positioners.
Model FC-SDO-0824
Brand Honeywell
Type 8-Channel Analog Output Module
Power Supply 24 V DC (18–30 V DC range)
Operating Temperature -40°C to 70°C (-40°F to 158°F)
Mounting DIN rail (35 mm)
Dimensions 120 mm x 160 mm x 80 mm (W x H x D)
Weight 0.7 kg (1.54 lbs)
Interfaces 1 x High-Speed Backplane Connector, 8 x Analog Outputs
Certifications CE, UL, CSA, ATEX, IEC 61010-1
Cooling Passive (conduction-based)
Environmental Rating IP20 (when installed in enclosure)
Output Signal Types 4-20 mA, 0-10 V DC
Output Accuracy ±0.05% of full scale
The HONEYWELL FC-SDO-0824 is a high-performance analog output module, specifically designed as part of Honeywell’s Experion Process Knowledge System (PKS) to serve as a key control component in distributed control systems (DCS). Its primary function is to receive digital commands from the central controller, convert them into precise analog signals, and transmit these signals to various field devices such as control valves, variable frequency drives, and positioners.
FC-SDO-0824
What makes the HONEYWELL FC-SDO-0824 stand out is its configuration of 8 channels, each capable of delivering a range of analog outputs up to 24 mA, making it a versatile choice for systems with varying actuation requirements. It integrates seamlessly with Honeywell’s Control Station and other components of the Experion PKS, as well as with third-party DCS platforms through standard communication protocols, providing engineers and integrators with flexibility in system design. Whether deployed in a new installation or as part of an upgrade, the HONEYWELL FC-SDO-0824 delivers consistent and accurate performance that industrial operators can rely on.
FC-SDO-0824
Main features and advantages:
A key strength of the HONEYWELLFC-SDO-0824 is its exceptional output accuracy and stability. Each of its 8 channels can be independently configured to deliver 4-20 mA or 0-10 V signals, with a precision of ±0.05% of full scale, ensuring that actuators receive the exact commands needed for precise process control. This level of accuracy minimizes process variability, leading to improved product quality and reduced waste. Hardware-wise, the module features a rugged design with surge protection up to 2 kV, safeguarding against electrical transients that are common in industrial environments. Its compact form factor, measuring 120 mm in width, allows for easy installation in crowded control cabinets, while its fan-less design reduces the risk of mechanical failure and lowers maintenance needs.
The HONEYWELL FC-SDO-0824 also offers impressive reliability and diagnostic capabilities. It continuously monitors output signals for deviations, short circuits, and overload conditions, providing real-time alerts to the central controller to enable prompt troubleshooting. The module supports hot-swapping, allowing for replacement during system operation without disrupting the entire process—a crucial feature in continuous production environments where downtime is costly. Additionally, its compatibility with Honeywell’s Experion PKS software simplifies configuration and calibration, with tools that enable engineers to set output ranges, perform signal trimming, and monitor channel performance remotely, reducing setup time and minimizing errors.
FC-SDO-0824
Technical specifications:
Model FC-SDO-0824
Brand Honeywell
Type 8-Channel Analog Output Module
Power Supply 24 V DC (18–30 V DC range)
Operating Temperature -40°C to 70°C (-40°F to 158°F)
Mounting DIN rail (35 mm)
Dimensions 120 mm x 160 mm x 80 mm (W x H x D)
Weight 0.7 kg (1.54 lbs)
Interfaces 1 x High-Speed Backplane Connector, 8 x Analog Outputs
Certifications CE, UL, CSA, ATEX, IEC 61010-1
Cooling Passive (conduction-based)
Environmental Rating IP20 (when installed in enclosure)
Output Signal Types 4-20 mA, 0-10 V DC
Output Accuracy ±0.05% of full scale
Contact Us Phone:+86 16626708626 WeChat/WhatsApp:+86 16626708626 Email: 3772179818@qq.com
FC-SDO-0824
Application areas:
In industrial processes where precise control of actuators, valves, and variable speed drives directly impacts production quality and efficiency, a reliable analog output module is indispensable. Think of a large-scale water treatment plant, where maintaining precise flow rates through 8 different chemical dosing pumps is critical to meeting water purity standards. Or a plastics extrusion facility, where adjusting the speed of 24 conveyor belts across multiple production lines ensures consistent product dimensions. These are the scenarios where the HONEYWELL FC-SDO-0824 excels, serving as a vital component in industrial automation systems that demand accurate and responsive signal output. Used in industrial automation setups ranging from food processing plants to oil refineries, the HONEYWELL FC-SDO-0824 is engineered to convert digital control signals into precise analog outputs, enabling seamless communication between the central controller and field devices. It’s particularly well-suited for applications where a combination of high channel count and reliable performance is required, such as in batch processing facilities or continuous manufacturing lines. The HONEYWELL FC-SDO-0824 addresses the challenge of integrating diverse actuators into a single control system, ensuring consistent and timely signal delivery to keep processes running smoothly.
Related products:
HONEYWELL FC-SDI-1624 – 16-channel analog input module that pairs with the HONEYWELL FC-SDO-0824 for complete input-output signal handling in control systems.
HONEYWELL FC-DO-32 – 32-channel digital output module often used alongside the HONEYWELL FC-SDO-0824 for mixed signal control applications.
HONEYWELL FC-PSU-24V-10A – Power supply unit optimized to provide stable 24 V DC to the HONEYWELL FC-SDO-0824 and associated modules.
HONEYWELL FC-COMM-01 – Communication adapter enabling the HONEYWELL FC-SDO-0824 to interface with Ethernet/IP networks for remote monitoring.
HONEYWELL FC-CAL-TOOL – Calibration kit specifically designed for verifying and adjusting the output accuracy of the HONEYWELL FC-SDO-0824.
HONEYWELL FC-ISO-08 – Isolation module that provides galvanic isolation for each channel of the HONEYWELL FC-SDO-0824 in high-noise environments.
HONEYWELL FC-BP-02 – Backplane adapter allowing the HONEYWELL FC-SDO-0824 to integrate with legacy Honeywell DCS racks.
HONEYWELL FC-DIAG-03 – Diagnostic module that works with the HONEYWELL FC-SDO-0824 to provide advanced output signal analysis and fault reporting.
Installation and maintenance:
Before installing the HONEYWELL FC-SDO-0824, ensure the mounting rail is securely fastened and properly grounded to minimize electrical noise, which can affect output signal stability. Verify that the control cabinet has sufficient space to accommodate the module and the connected wiring, with a minimum clearance of 50 mm above and below to facilitate proper heat dissipation. When connecting field devices to the HONEYWELL FC-SDO-0824, use shielded twisted-pair cables for analog signals, with the shield terminated at the module’s ground terminal to reduce electromagnetic interference. It’s also important to check that the load impedance of connected devices falls within the module’s specified range (250–1000 ohms for 4-20 mA signals) to ensure accurate output.
For maintenance, schedule quarterly calibration checks using Honeywell’s recommended procedures to ensure the HONEYWELL FC-SDO-0824 maintains its high accuracy. Conduct monthly visual inspections to check for loose connections, corrosion, or signs of overheating, which can indicate Potential issues. Use the Experience PKS software to run output drift analysis reports semi annually, which can identify channels requesting adjustment before they impact process control. The module’s design allows for in place calibration without removal from the DIN rail, reducing maintenance downtime. With proper care, the HONEYWELL FC-SDO-0824 is engineered to provide reliable service for 10+years in typical industrial operating conditions
