Honeywell DC1020CL Single-Loop Temperature Controller
Sale!
Honeywell DC1020CL Single-Loop Temperature Controller
The Honeywell DC1020CL is a compact single-loop temperature controller designed to deliver precise thermal regulation in industrial processes. As part of Honeywell’s DC1000 series, it fits seamlessly into both standalone control setups and larger automation systems, communicating with sensors, heaters, and cooling devices to maintain target temperatures with exceptional accuracy.
Model DC1020CL
Brand Honeywell
Type Single-Loop Temperature Controller
Power Supply 100-240 V AC, 50/60 Hz
Operating Temperature 0°C to 50°C (32°F to 122°F)
Mounting Panel-mounted (1/8 DIN cutout)
Dimensions 48 mm (W) x 96 mm (H) x 112 mm (D)
Weight 180 grams
Input Types Thermocouples (J, K, T, E, R, S), RTD (Pt100)
Output Signals 1x Relay (5A), 1x SSR drive (12V DC), 1x 4-20 mA analog
Control Algorithm PID with adaptive tuning
Display 4-digit LED, 0.1°C resolution
Certifications CE, UL, CSA
Protection Rating IP65 (front panel), IP20 (rear)
The Honeywell DC1020CL is a compact single-loop temperature controller designed to deliver precise thermal regulation in industrial processes. As part of Honeywell’s DC1000 series, it fits seamlessly into both standalone control setups and larger automation systems, communicating with sensors, heaters, and cooling devices to maintain target temperatures with exceptional accuracy.
DC1020CL
Unlike generic controllers, the Honeywell DC1020CLis engineered specifically for applications where space is limited but performance can’t be compromised—its slim 48mm width allows installation in crowded control panels without sacrificing functionality. It operates as a standalone unit or integrates with SCADA systems via optional communication modules, making it suitable for both local operator control and remote monitoring. For process engineers and plant managers, its value lies in its balance of simplicity and sophistication: it offers intuitive programming for basic tasks while providing advanced features like adaptive tuning for complex thermal processes. Whether regulating a single oven or coordinating with other DC1000 series controllers in a multi-zone system, the Honeywell DC1020CL ensures temperature remains within tight tolerances, directly impacting product quality and process efficiency.
DC1020CL
Main features and advantages:
The Honeywell DC1020CL stands out for its combination of precision and user-centric design. Its core strength lies in its control accuracy: with a measurement resolution of 0.1°C and a control stability of ±0.2°C, it maintains temperatures even in environments with fluctuating ambient conditions—critical in applications like semiconductor wafer annealing, where thermal uniformity directly affects electrical performance.
The controller’s adaptive tuning algorithm sets it apart, automatically adjusting proportional-integral-derivative (PID) parameters in real time as process conditions change. This eliminates the need for manual recalibration when load variations occur, such as when a new batch of material enters a heating chamber. For operators, this means reduced setup time and fewer process interruptions.
Hardware-wise, the Honeywell DC1020CL features a rugged plastic housing rated for industrial environments, with protection against dust and minor splashes (IP65 front panel). Its bright LED display ensures visibility even in poorly lit control rooms, while tactile membrane keys simplify parameter adjustments without accidental changes. Compatibility is another key advantage: it works with a wide range of temperature sensors (thermocouples, RTDs) and output devices (SSR, relay, analog), integrating smoothly with existing heating/cooling systems. Long-term reliability is enhanced by built-in diagnostics that alert operators to sensor faults or output errors, preventing unplanned shutdowns and extending equipment lifespan.
DC1020CL
Technical specifications:
Model DC1020CL
Brand Honeywell
Type Single-Loop Temperature Controller
Power Supply 100-240 V AC, 50/60 Hz
Operating Temperature 0°C to 50°C (32°F to 122°F)
Mounting Panel-mounted (1/8 DIN cutout)
Dimensions 48 mm (W) x 96 mm (H) x 112 mm (D)
Weight 180 grams
Input Types Thermocouples (J, K, T, E, R, S), RTD (Pt100)
Output Signals 1x Relay (5A), 1x SSR drive (12V DC), 1x 4-20 mA analog
Control Algorithm PID with adaptive tuning
Display 4-digit LED, 0.1°C resolution
Certifications CE, UL, CSA
Protection Rating IP65 (front panel), IP20 (rear)
Contact Us Phone:+86 16626708626 WeChat/WhatsApp:+86 16626708626 Email: 3772179818@qq.com
DC1020CL
Application areas:
In industrial environments where precise temperature control can mean the difference between consistent product quality and costly waste, the Honeywell DC1020CL emerges as a trusted solution. This compact controller finds its place in a wide range of manufacturing and processing settings, from plastic extrusion lines where maintaining melt temperatures within ±0.5°C ensures uniform product dimensions, to food processing facilities regulating oven temperatures for batch baking.
In chemical processing plants, the Honeywell DC1020CL plays a critical role in controlling reactor jacket temperatures, ensuring exothermic reactions proceed safely without runaway heat. It’s equally valuable in pharmaceutical production, where strict regulatory requirements demand precise control of fermentation tanks—even minor temperature fluctuations can alter microbial growth rates and compromise batch integrity. Used in industrial automation setups ranging from small-scale packaging lines to large-scale composite material curing systems, the HoneywellDC1020CL delivers the stability needed to keep processes on track, reduce energy consumption, and minimize downtime caused by temperature-related errors. Its ability to integrate with existing control systems makes it a versatile choice for both new installations and retrofits, addressing the unique challenges of diverse thermal control applications.
Related products:
Honeywell DC1040CL – Dual-loop version of the Honeywell DC1020CL, ideal for processes requiring coordinated control of two related temperatures (e.g., heater and cooling water).
Honeywell DC1010CL – Basic single-loop model with simplified features, suitable for applications where advanced tuning isn’t required.
Honeywell TC-ILM01 – Isolation module that eliminates ground loops between the Honeywell DC1020CL and high-voltage heating elements.
Honeywell DC-COM02 – RS485 communication module, enabling the Honeywell DC1020CL to connect to SCADA systems for remote monitoring.
Honeywell PT100-3M – Precision RTD sensor calibrated for use with the Honeywell DC1020CL, ensuring optimal measurement accuracy.
Honeywell SSR-25A – Solid-state relay recommended for use with the Honeywell DC1020CL in high-switching-frequency applications like plastic molding.
Honeywell TC-TERM05 – Terminal block adapter that simplifies wiring between the Honeywell DC1020CL and sensor/actuator cables.
Honeywell DC-CAL01 – Calibration tool used to verify the Honeywell DC1020CL’s temperature measurement accuracy during maintenance.
Installation and maintenance:
Before installing the Honeywell DC1020CL, ensure the control panel cutout matches the 48mm x 96mm dimensions to prevent gaps that could allow dust ingress. Verify that the mounting location is free from direct vibration—excessive movement can loosen terminal connections over time, leading to measurement errors. Check that the power supply is stable and filtered; voltage spikes from nearby motors can disrupt the controller’s operation. For sensor wiring, use shielded cables with the shield grounded at one end to minimize electromagnetic interference, especially in environments with variable frequency drives.
For maintenance, schedule monthly checks of the display and keypad to ensure all functions remain responsive. Inspect wiring terminals quarterly for signs of corrosion, which can occur in high-humidity areas like food processing plants, and retighten connections as needed. Use the controller’s built-in self-diagnostic mode every six months to test sensor input and output signals—this can identify drifting calibration or failing components before they affect process control. When replacing sensors, recalibrate the Honeywell DC1020CL using the factory-recommended procedure to maintain ±0.2°C accuracy.
