The Honeywell CC-TAIX11 is an analog input module designed specifically for integration with Honeywell’s Experion Process Knowledge System (PKS), a leading distributed control system used in large-scale industrial operations. As a core component of the Experion architecture, it serves as the interface between field devices—such as thermocouples, RTDs, and pressure transmitters—and the DCS, converting raw analog signals into digital data that the system’s controllers can process and act upon.
Model CC-TAIX11
Brand Honeywell
Type Analog Input Module
Power Supply 24 V DC (from system backplane)
Operating Temperature 0°C to 60°C (32°F to 140°F)
Mounting Backplane-mounted in Control Processor Chassis
Dimensions 152 mm (W) x 102 mm (H) x 229 mm (D)
Weight 550 grams
Interfaces 8 analog input channels; ControlNet/Ethernet/IP
Certifications UL, CSA, ATEX, IECEx, CE
Cooling Convection cooling (no fan)
Environmental Rating NEMA 12 (when installed in enclosed chassis)
Input Types Supported Thermocouples, RTDs, 4-20 mA, 0-10 V
Conversion Resolution 16-bit
The Honeywell CC-TAIX11 is an analog input module designed specifically for integration with Honeywell’s Experion Process Knowledge System (PKS), a leading distributed control system used in large-scale industrial operations. As a core component of the Experion architecture, it serves as the interface between field devices—such as thermocouples, RTDs, and pressure transmitters—and the DCS, converting raw analog signals into digital data that the system’s controllers can process and act upon.
CC-TAIX11
Unlike generic input modules, the Honeywell CC-TAIX11 is engineered to meet the rigorous demands of process industries, where signal accuracy and system uptime are non-negotiable. It fits seamlessly into Honeywell’s TDC 3000 and Experion PKS systems, connecting via the ControlNet or Ethernet/IP networks to ensure real-time data transmission. For system integrators and control engineers, its value lies in its ability to simplify complex signal management: it handles multiple input types without requiring hardware reconfiguration, reducing setup time and minimizing the risk of configuration errors. Whether deployed in a new system or as a replacement in an existing Honeywell setup, the Honeywell CC-TAIX11 ensures that analog data flows reliably, forming the foundation of informed decision-making in process control.
CC-TAIX11
Main features and advantages:
The Honeywell CC-TAIX11 distinguishes itself with a combination of precision and ruggedness that’s essential in process industries. Its 16-bit analog-to-digital conversion delivers measurement accuracy within ±0.1% of full scale, ensuring that even small changes in process variables—like a 0.5°C shift in reactor temperature—are captured and relayed to the DCS. This level of precision is critical in applications such as pharmaceutical batch processing, where tight parameter control directly impacts product quality.
Built to withstand the harsh conditions of industrial settings, the Honeywell CC-TAIX11 features a robust metal housing that resists corrosion from airborne contaminants common in chemical plants or coastal refineries. It operates reliably in temperatures ranging from 0°C to 60°C, withstanding vibration and electrical noise that would degrade signal quality in less durable modules. This durability translates to lower replacement rates and reduced maintenance overhead, even in environments with high ambient humidity or frequent temperature fluctuations.
Compatibility is another key strength. The Honeywell CC-TAIX11 supports a wide range of analog input types, including thermocouples (J, K, T, E, R, S, B types), RTDs (Pt100, Ni100), and 4-20 mA current loops, eliminating the need for separate modules for different sensor types. It integrates smoothly with other Honeywell components, such as the CC-TAIX11 power supply module and the CC-TDIL01 digital input module, allowing for scalable system design. Long-term reliability is enhanced by built-in self-diagnostic features that alert operators to signal drift or module faults, enabling proactive maintenance before issues affect process performance.
CC-TAIX11
Technical specifications:
Model CC-TAIX11
Brand Honeywell
Type Analog Input Module
Power Supply 24 V DC (from system backplane)
Operating Temperature 0°C to 60°C (32°F to 140°F)
Mounting Backplane-mounted in Control Processor Chassis
Dimensions 152 mm (W) x 102 mm (H) x 229 mm (D)
Weight 550 grams
Interfaces 8 analog input channels; ControlNet/Ethernet/IP
Certifications UL, CSA, ATEX, IECEx, CE
Cooling Convection cooling (no fan)
Environmental Rating NEMA 12 (when installed in enclosed chassis)
Input Types Supported Thermocouples, RTDs, 4-20 mA, 0-10 V
Conversion Resolution 16-bit
