The Honeywell CC-TAID01 functions as a high-performance thermocouple input module, serving as the critical interface between field-mounted thermocouples and Honeywell’s Experion PKS control system. Its primary role is to convert the millivolt-level signals from thermocouples—devices that generate voltage proportional to temperature differences—into digital data that the DCS can process, analyze, and act upon. Unlike generic analog input modules, the Honeywell CC-TAID01 is specifically engineered for thermocouple applications, featuring built-in cold junction compensation to account for ambient temperature variations at the module itself—a common source of measurement error.
Model Number CC-TAID01
Brand Honeywell
Type Thermocouple input module
Input Voltage 24V DC (backplane powered)
Operating Temp Range 0°C to 60°C (32°F to 140°F)
Mounting Style Rack-mounted (Honeywell I/O chassis compatible)
Dimensions 125mm x 85mm x 105mm (4.92″ x 3.35″ x 4.13″)
Weight 0.4kg (0.88 lb)
Interface/Bus ControlNet/Ethernet/IP
Compliance CE, UL, ATEX, RoHS
Supported Protocols HART, Modbus TCP/IP, Honeywell proprietary
Typical Power Draw 4.2W (max)
The Honeywell CC-TAID01 functions as a high-performance thermocouple input module, serving as the critical interface between field-mounted thermocouples and Honeywell’s Experion PKS control system. Its primary role is to convert the millivolt-level signals from thermocouples—devices that generate voltage proportional to temperature differences—into digital data that the DCS can process, analyze, and act upon. Unlike generic analog input modules, the Honeywell CC-TAID01 is specifically engineered for thermocouple applications, featuring built-in cold junction compensation to account for ambient temperature variations at the module itself—a common source of measurement error.
CC-TAID01
This module integrates seamlessly with Honeywell’s ControlNet and Ethernet/IP networks, communicating processed temperature data to the controller with minimal latency. It supports multiple thermocouple types (including J, K, T, E, R, S, B, and N), allowing engineers to mix sensor types within a single system without sacrificing accuracy. The Honeywell CC-TAID01 also includes advanced signal filtering to reduce noise from industrial environments, ensuring that even in EMI-heavy settings—such as near large motors or variable frequency drives—temperature readings remain stable. By acting as a dedicated, precision converter for thermocouple signals, it forms a critical link in the chain of thermal process control, ensuring that the DCS receives the most accurate temperature data possible.
CC-TAID01
Technical specifications:
Model Number CC-TAID01
Brand Honeywell
Type Thermocouple input module
Input Voltage 24V DC (backplane powered)
Operating Temp Range 0°C to 60°C (32°F to 140°F)
Mounting Style Rack-mounted (Honeywell I/O chassis compatible)
Dimensions 125mm x 85mm x 105mm (4.92″ x 3.35″ x 4.13″)
Weight 0.4kg (0.88 lb)
Interface/Bus ControlNet/Ethernet/IP
Compliance CE, UL, ATEX, RoHS
Supported Protocols HART, Modbus TCP/IP, Honeywell proprietary
Typical Power Draw 4.2W (max)
Contact Us Phone:+86 16626708626 WeChat/WhatsApp:+86 16626708626 Email: 3772179818@qq.com
CC-TAID01
Main features and advantages:
Choosing the Honeywell CC-TAID01 delivers tangible operational benefits that extend beyond basic temperature measurement. Its precision engineering ensures temperature readings with an accuracy of ±0.1°C, enabling tighter process control that reduces product variability and waste. This level of accuracy is particularly valuable in batch processing, where even small temperature deviations can alter chemical reactions or material properties, leading to costly rework.
Another key advantage is the module’s contribution to maintenance efficiency. The HoneywellCC-TAID01includes built-in diagnostics that monitor thermocouple health, detecting open circuits, short circuits, and drift—issues that would otherwise require manual inspection. This feature reduces troubleshooting time from hours to minutes, as maintenance teams can quickly identify problematic sensors without shutting down the entire process.
Additionally, the Honeywell CC-TAID01 is engineered for long-term reliability in harsh industrial environments. Its rugged design resists vibration, humidity, and temperature fluctuations, ensuring consistent performance even in the most demanding settings. For facilities operating 24/7, this reliability translates to fewer unplanned shutdowns, protecting production schedules and revenue streams.
CC-TAID01
Application areas:
The Honeywell CC-TAID01 is widely deployed in industries where precise temperature control is non-negotiable. In the petrochemical sector, it’s used to monitor temperatures in distillation columns and catalytic reactors, where maintaining precise thermal profiles is critical for product quality and safety. Its ability to handle high-temperature inputs (up to 1800°C depending on thermocouple type) makes it ideal for these applications, ensuring that even extreme heat conditions are accurately measured.
In power generation facilities, the Honeywell CC-TAID01 plays a vital role in boiler and turbine temperature monitoring. Here, its fast response time—less than 100ms—ensures that sudden temperature spikes are detected immediately, allowing the control system to adjust fuel flow or cooling rates to prevent equipment damage.
Aerospace manufacturing plants also rely on the Honeywell CC-TAID01 to monitor heat treatment processes for metal components, where precise temperature control directly impacts material strength and durability. In each case, the module’s accuracy and reliability make it indispensable for maintaining process integrity and meeting strict industry standards.
CC-TAID01
Related products:
CC-TAID02 – 8-channel version of the CC-TAID01 for larger thermocouple networks.
CC-RTD01 – RTD input module, ideal for applications requiring resistance-based temperature measurement.
CC-HIST01 – Data historian add-on, storing CC-TAID01 temperature trends for process optimization.
Installation and maintenance:
Before installing the Honeywell CC-TAID01, verify that the target I/O chassis firmware supports thermocouple-specific features—older versions may require updates to enable cold junction compensation. Check that the mounting rack has adequate ventilation, as the module generates slight heat during operation, and ensure that thermocouple wiring runs are separated from power cables to minimize EMI. It’s also critical to confirm that the thermocouple types in use are compatible with the module’s configuration (J, K, T, etc.) to avoid calibration errors.
During installation, take care to tighten terminal connections to the specified torque (0.5 N·m) to prevent signal degradation from loose contacts. After mounting, use Honeywell’s Configuration Studio to set cold junction compensation parameters and configure alarm thresholds for out-of-range temperatures. For ongoing maintenance, schedule quarterly checks of the module’s status LEDs—steady green indicates normal operation, while red or flashing lights signal issues like sensor faults or communication errors. Annual calibration using a precision temperature reference ensures that accuracy is maintained over time, especially in environments with high vibration or temperature cycling.
