Name: Honeywell CC-PFB401 High-speed backplane interface module | Qiming Automation
Brand: Honeywell

Description

The Honeywell CC-PFB401 functions as a high-speed backplane interface module, serving as the critical link between the controller and I/O modules within Honeywell’s Experion PKS and TDC 3000 systems. Its primary role is to manage data transmission across the system backplane, ensuring that real-time process data, control signals, and diagnostic information flow efficiently between components. Unlike basic backplane modules, the Honeywell CC-PFB401 is designed to handle increased data throughput, supporting up to 100 Mbps transfer rates to accommodate the growing demands of modern industrial systems with hundreds of connected I/O points.

CC-PFB401

This module integrates seamlessly with Honeywell’s redundant controller architectures, providing path diversity to prevent single points of failure. It communicates using Honeywell’s proprietary backplane protocol, which is optimized for industrial environments to minimize latency and maximize data integrity. The Honeywell CC-PFB401 also includes advanced error-checking mechanisms, such as cyclic redundancy checks (CRC), to detect and correct data corruption—critical for maintaining process accuracy in applications where even small data errors could lead to costly or unsafe conditions. By acting as a high-performance intermediary, it ensures that the controller remains in constant, reliable communication with all connected I/O modules, forming the foundation of a responsive and resilient control system.

CC-PFB401

Technical specifications:
Model Number CC-PFB401
Brand Honeywell
Type High-speed backplane interface module
Input Voltage5V DC (backplane powered)
Operating Temp Range-40°C to 70°C (-40°F to 158°F)
Mounting StyleRack-mounted (Honeywell I/O chassis compatible)
Dimensions145mm x 90mm x 115mm (5.71″ x 3.54″ x 4.53″)
Weight0.5kg (1.1 lb)
Interface/BusHoneywell high-speed backplane (100 Mbps)
ComplianceCE, UL, IEC 61508 (SIL 2), RoHS
Supported ProtocolsHoneywell backplane protocol, compatible with Modbus via gateway
Typical Power Draw3.5W (max)

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

CC-PFB401

Main features and advantages:

Choosing the Honeywell CC-PFB401 delivers tangible operational benefits that directly impact system performance and reliability. Its high-speed data transfer capability eliminates the latency issues common with older backplane modules, ensuring that process changes are detected and responded to in milliseconds—critical for applications like emergency shutdown systems or rapid process adjustments where timing is paramount. This responsiveness translates to tighter process control, reducing variability in product quality and minimizing waste in manufacturing and processing environments.

Another key advantage is the module’s contribution to system uptime. The Honeywell CC-PFB401 ’s robust design and error-correction features significantly reduce the risk of communication failures, which are a leading cause of unplanned downtime in industrial control systems. By ensuring consistent data flow between the controller and I/O modules, it prevents “blind spots” in process monitoring, allowing operators to make informed decisions based on complete, real-time data.

Additionally, the Honeywell CC-PFB401 is engineered for long-term scalability. As facilities expand and add more I/O points, its high throughput capacity avoids the need for costly backplane upgrades, protecting capital investments. For maintenance teams, its built-in diagnostic capabilities—including link status indicators and error counters—simplify troubleshooting, reducing the time spent identifying communication issues from hours to minutes.

CC-PFB401

Application areas:

The Honeywell CC-PFB401 is widely deployed in industries where high-speed, reliable backplane communication is critical to operational success. In the oil and gas industry, it’s a cornerstone of offshore platform control systems, where it manages data flow between controllers and hundreds of I/O modules monitoring wellhead pressure, flow rates, and safety systems. Its ability to handle high data volumes ensures that operators receive real-time alerts about potential issues, such as pressure spikes, enabling rapid responses to maintain critical system uptime.

In power generation facilities, the Honeywell CC-PFB401 supports communication between turbine controllers and I/O modules tracking temperature, vibration, and fuel flow. Its low latency is essential here, as delays in data transmission could lead to missed warning signs of equipment stress, increasing the risk of unplanned outages.

Chemical processing plants also rely on the Honeywell CC-PFB401 to manage the complex interplay between batch controllers and I/O modules regulating reactor conditions. In these environments, its error-correction features prevent data corruption that could lead to incorrect chemical dosing or temperature control, ensuring compliance with strict safety and quality standards.

CC-PFB401

Related products:

CC-PFB301 – Previous generation backplane module, suitable for retrofitting older TDC 3000 systems.
CC-PFB402 – Redundant version of the CC-PFB401, providing automatic failover for critical applications.
CC-PFB501 – High-bandwidth upgrade, supporting 1 Gbps data transfer for large-scale systems.
CC-Link401 – Gateway module enabling CC-PFB401 integration with CC-Link industrial networks.
CC-ENET401 – Ethernet interface add-on, allowing remote monitoring of CC-PFB401 backplane traffic.
CC-PWR401 – Power supply module optimized for use with CC-PFB401 in high-density racks.
CC-DBM401 – Data buffer module that works with CC-PFB401 to manage peak data loads.
CC – Diagnosis 401- Diagnostic tool for CC-PFB401, providing real-time backplane performance analytics.

CC-PFB401

Installation and maintenance:

Before installing the Honeywell CC-PFB401, verify that the target I/O rack is compatible with Honeywell’s high-speed backplane specifications—older racks may require hardware modifications to support 100 Mbps operation. Check that the rack’s power supply can deliver stable 5V DC, as voltage fluctuations can disrupt backplane communication. It’s also critical to ensure that the system controller firmware is up to date, as newer versions include optimizations for the Honeywell CC-PFB401’s advanced features.

During installation, handle the module carefully to avoid electrostatic discharge (ESD), which can damage sensitive components. Ensure the module is fully seated in the rack, with the locking lever engaged to prevent intermittent connections. After installation, use Honeywell’s Experion Configuration Studio to verify backplane link status and data throughput, confirming that transfer rates meet the 100 Mbps specification.
