Honeywell CC-PDOD51 high-performance digital output module
The Honeywell CC-PDOD51 functions as a high-performance digital output module within Honeywell’s Experion Process Knowledge System (PKS) architecture, specifically designed to integrate with the TDC 3000 and PlantScape systems. Its primary role is to convert digital control signals from the central controller into actionable outputs that operate field devices such as solenoid valves, motor starters, and alarm systems.
Model Number CC-PDOD51
Brand Honeywell
TypeDigital output module
Input Voltage24V DC (backplane powered)
Operating Temp Range0°C to 60°C (32°F to 140°F)
Mounting StyleRack-mounted (compatible with Honeywell I/O racks)
Dimensions160mm x 80mm x 120mm (6.30″ x 3.15″ x 4.72″)
Weight0.6kg (1.32 lb)
Interface/BusHoneywell proprietary backplane
ComplianceCE, UL, ATEX
Supported ProtocolsHoneywell ControlNet, Modbus (via gateway)
Typical Power Draw8W (max)
The Honeywell CC-PDOD51 functions as a high-performance digital output module within Honeywell’s Experion Process Knowledge System (PKS) architecture, specifically designed to integrate with the TDC 3000 and PlantScape systems. Its primary role is to convert digital control signals from the central controller into actionable outputs that operate field devices such as solenoid valves, motor starters, and alarm systems.
CC-PDOD51
What distinguishes the Honeywell CC-PDOD51 is its ability to manage multiple output channels with minimal latency, ensuring that critical operations—like emergency shutdowns or rapid process adjustments—are executed without delay. It connects to the system via Honeywell’s proprietary backplane, enabling seamless communication with the controller and other I/O modules. The module also features built-in diagnostic capabilities, including channel-level fault detection and status monitoring, which provide real-time insights into operational health. This allows engineers to quickly identify issues such as open circuits or overcurrent conditions, reducing the time spent on troubleshooting and minimizing disruptions to the process control system. Unlike basic digital output modules, the HoneywellCC-PDOD51 is designed for modular scalability, making it easy to expand output capacity as system requirements grow.
CC-PDOD51
Technical specifications:
Model Number CC-PDOD51
Brand Honeywell
TypeDigital output module
Input Voltage24V DC (backplane powered)
Operating Temp Range0°C to 60°C (32°F to 140°F)
Mounting StyleRack-mounted (compatible with Honeywell I/O racks)
Dimensions160mm x 80mm x 120mm (6.30″ x 3.15″ x 4.72″)
Weight0.6kg (1.32 lb)
Interface/BusHoneywell proprietary backplane
ComplianceCE, UL, ATEX
Supported ProtocolsHoneywell ControlNet, Modbus (via gateway)
Typical Power Draw8W (max)
Contact Us Phone:+86 16626708626 WeChat/WhatsApp:+86 16626708626 Email: 3772179818@qq.com
CC-PDOD51
Main features and advantages:
Choosing the Honeywell CC-PDOD51 brings tangible advantages to industrial operations, starting with enhanced process reliability. Its robust design ensures consistent performance even in harsh industrial environments, where factors like vibration, temperature fluctuations, and electrical noise can disrupt less durable modules. This reliability translates to fewer unplanned shutdowns, reducing the associated costs of lost production and maintenance.
Another key benefit is the module’s impact on operational efficiency. The Honeywell CC-PDOD51’s high channel density reduces the number of modules needed in the rack, simplifying system architecture and lowering both initial installation costs and long-term energy consumption. Its intuitive diagnostic features also streamline maintenance workflows: instead of manually checking each field device when a problem arises, engineers can use the module’s status indicators and software logs to pinpoint issues quickly, cutting troubleshooting time by up to 50% in many cases.
Additionally, the Honeywell CC-PDOD51 is engineered for long-term performance, with a design that minimizes drift and wear over time. This ensures that calibration intervals are extended, freeing up engineering resources to focus on optimizing processes rather than routine maintenance. For organizations aiming to improve overall equipment effectiveness (OEE), the module’s combination of reliability, efficiency, and durability makes it a valuable investment.
CC-PDOD51
Application areas:
The Honeywell CC-PDOD51 is widely deployed in industries where precise digital output control is critical to process integrity and safety. In the oil and gas sector, it plays a key role in managing valve operations in pipeline systems, ensuring that flow rates are adjusted accurately to prevent overpressure or leakage. Its ability to handle rapid signal changes makes it ideal for applications like wellhead control, where split-second responses to pressure fluctuations are essential for maintaining critical system uptime.
In chemical processing plants, the Honeywell CC-PDOD51 is used to control the operation of mixing equipment, heating elements, and safety interlocks. Here, its reliable performance is crucial for maintaining consistent batch quality and adhering to strict regulatory standards, as even minor delays in output signals could lead to incorrect chemical proportions or process deviations.
Water and wastewater treatment facilities also rely on the Honeywell CC-PDOD51 to manage pump operations, filter backwashing cycles, and chemical dosing systems. Its robust construction allows it to withstand the humid, corrosive environments common in these facilities, ensuring uninterrupted operation of processes that are vital to public health and environmental protection.
CC-PDOD51
Related products:
CC-PDOB01 – Compact 8-channel digital output module for space-constrained applications.
CC-PDOD52 – High-current version of the CC-PDOD51, designed for driving larger field devices.
CC-PAOD01 – Analog output counterpart, ideal for systems requiring both digital and analog control.
CC-PDIO10 – Combined digital input/output module, offering flexibility for mixed-signal environments.
CC-PDOD11 – Legacy predecessor to the CC-PDOD51, suitable for retrofitting older systems.
CC-PDOH01 – High-temperature rated module, designed for extreme heat environments up to 70°C.
CC-Link01 – Communication gateway module, enabling CC-PDOD51 integration with CC-Link networks.
Before installing the Honeywell CC-PDOD51, ensure that the target I/O rack is compatible with Honeywell’s current backplane specifications—older racks may require firmware updates to support the module’s advanced features. Check that the rack has adequate cooling capacity, as the Honeywell CC-PDOD51 generates slightly more heat than basic digital output modules, especially when all channels are active. It’s also important to verify that the system controller has the latest software version to enable full access to the module’s diagnostic functions.
During installation, take care to secure the module firmly in the rack to prevent vibration-induced loosening, which can cause intermittent signal loss. After mounting, perform a full channel test using Honeywell’s configuration software to confirm that each output responds correctly to control signals. For ongoing maintenance, schedule monthly visual inspections of the module’s status LEDs—steady green indicates normal operation, while amber or red lights signal issues like overcurrent or communication errors. Every six months, check the terminal connections for corrosion, particularly in humid environments, and tighten any loose connections to maintain reliable signal transmission.
