The Honeywell CC-PAOX01 is highly versatile in terms of communication. It is fully compatible with the industry – standard ControlNet backplane. This compatibility allows for seamless integration within Honeywell’s control ecosystems, enabling easy communication and data exchange with other components of the control system. In addition to ControlNet, it also supports HART communication. HART (Highway Addressable Remote Transducer) technology enables bidirectional communication with intelligent field devices. This bidirectional communication capability is extremely useful as it allows engineers to remotely configure and diagnose connected actuators. For example, in a large – scale oil refinery, engineers can use HART communication to remotely adjust the settings of actuators controlling the opening and closing of valves in pipelines, without the need for on – site visits. This not only saves time but also reduces the potential for human error and downtime.
CC-PAOX01
Main features and advantages:
The module is equipped with built – in diagnostic LEDs, which provide real – time status information. These LEDs are located on the front panel of the module and serve as a visual indicator of its operational health. A solid green LED indicates normal operation, meaning that the module is functioning correctly and all systems are operating as expected. A flashing amber LED signals a minor fault, such as a temporary glitch in the output signal or a minor communication issue. This early warning system allows maintenance personnel to quickly identify and address potential problems before they escalate into more significant issues. In the case of a flashing red LED, it indicates a more serious problem, such as an overcurrent condition or a critical communication failure. This proactive approach to monitoring helps in preventing major system failures and ensures the continuous and reliable operation of industrial processes.
The Honeywell CC-PAOX01 offers several benefits in industrial operations. Its robust construction, with a high – quality enclosure and reliable components, allows it to withstand harsh industrial environments. It is resistant to vibration, shock, and electromagnetic interference, ensuring consistent performance over an extended service life. This durability reduces maintenance costs and the frequency of replacements. The module’s pre – configured compatibility with Honeywell’s control systems simplifies the integration process. Engineers can easily incorporate it into existing infrastructure with minimal programming efforts, reducing commissioning time by up to 30%. During daily operation, its high – precision output signals enable accurate control of industrial processes, leading to improved product quality and reduced variability. It also alleviates the load on controllers, allowing them to focus on more complex control algorithms and decision – making tasks.
CC-PAOX01
Technical specifications:
Model Number CC-PAOX01
Brand Honeywell
Type High – Performance Analog Output Module
Output Voltage 24V DC (±10%)
Output Current 4 – 20 mA (±0.05%)
Operating Temp Range – 40°C to 70°C (- 40°F to 158°F)
Mounting Style Rack – mounted (19 – inch standard)
Dimensions 120mm x 80mm x 210mm (L x W x H)
Weight 0.75kg (1.65 lbs)
Interface/Bus ControlNet, Modbus (optional)
Compliance CE, RoHS, UL 508, ATEX
Supported Protocols HART, Modbus RTU (direct or via gateway)
Typical Power Draw 2.7W
Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com
CC-PAOX01
Application areas:
The Honeywell CC-PAOX01 finds extensive applications across various industries. In the oil and gas industry, it is used to precisely control the opening and closing of valves in pipelines, ensuring the smooth flow of fluids and preventing leaks. In power generation plants, it is employed to regulate the speed of turbines, optimizing power output and maintaining grid stability. In the food and beverage industry, it controls the filling levels in packaging machines, guaranteeing consistent product quantities. In the pharmaceutical industry, it plays a crucial role in controlling the flow of chemicals during the manufacturing process, ensuring product quality and safety.
CC-PAOX01
Related products:
- CC – PAIX01: An analog input module that pairs perfectly with the CC – PAOX01 to form a complete control loop. The CC – PAIX01 collects sensor data, which is then processed by the control system, and the CC – PAOX01 sends out corresponding output signals to control actuators based on this data.
- CC – PCIX01: A digital input module that can be integrated with the CC – PAOX01 in mixed – signal systems. It monitors discrete signals, such as the status of switches and relays, while the CC – PAOX01 controls analog – based actuators.
- CC – PDIX01: A digital output module that works in tandem with the CC – PAOX01. It can be used to trigger alarms, activate emergency shutdowns, or control digital devices based on the output status of the CC – PAOX01.
- CC – PAOH02: A high – channel density variant of the CC – PAOX01, suitable for large – scale industrial applications that require a greater number of analog output connections.
- CC – PAOH51: An isolated analog output module designed for use in systems with extremely high levels of electrical noise.
- 51304391 – 100: A legacy analog output module that is compatible with older Honeywell TDC 3000 systems. It can be used as a stepping – stone for companies looking to upgrade their existing systems gradually.
- CC – TCOH01: A thermocouple output module that is specifically designed to work in conjunction with the CC – PAOX01 in high – temperature control applications.
