Honeywell CC-PAOH01 Precision-Oriented Analog Output Module
Sale!
Honeywell CC-PAOH01 Precision-Oriented Analog Output Module
The Honeywell CC-PAOH01 serves as a vital link between the control system and various field devices such as valves, actuators, and motors. It takes digital control signals from higher – level controllers, like those in the Honeywell Experion PKS system, and converts them into analog signals within the standard 4 – 20 mA or 0 – 10 V range. These analog signals are then transmitted to the field devices, precisely regulating their operation. What sets the Honeywell CC-PAOH01 apart is its advanced output signal conditioning circuitry. This circuitry ensures that the output signals are free from distortion and noise, even in electrically noisy environments. By maintaining signal integrity, the module enables highly accurate control of actuators, which is essential in applications where tight process tolerances are required, such as in the semiconductor manufacturing industry, where minute adjustments can significantly impact product yield.
Model Number CC-PAOH01
Brand Honeywell
Type Precision – Oriented Analog Output Module
Output Voltage 24V DC (±10%)
Output Current 4 – 20 mA (±0.05%)
Operating Temp Range – 40°C to 70°C (- 40°F to 158°F)
Mounting Style Rack – mounted (19 – inch standard)
Dimensions 125mm x 85mm x 215mm (L x W x H)
Weight 0.78kg (1.72 lbs)
Interface/Bus ControlNet, Modbus (optional)
Compliance CE, RoHS, UL 508, ATEX
Supported Protocols HART, Modbus RTU (direct or via gateway)
Typical Power Draw 2.9W
The Honeywell CC-PAOH01 serves as a vital link between the control system and various field devices such as valves, actuators, and motors. It takes digital control signals from higher – level controllers, like those in the Honeywell Experion PKS system, and converts them into analog signals within the standard 4 – 20 mA or 0 – 10 V range. These analog signals are then transmitted to the field devices, precisely regulating their operation. What sets the Honeywell CC-PAOH01 apart is its advanced output signal conditioning circuitry. This circuitry ensures that the output signals are free from distortion and noise, even in electrically noisy environments. By maintaining signal integrity, the module enables highly accurate control of actuators, which is essential in applications where tight process tolerances are required, such as in the semiconductor manufacturing industry, where minute adjustments can significantly impact product yield.
CC-PAOH01
One of the remarkable features of the Honeywell CC-PAOH01 is its support for multiple communication protocols. It is fully compatible with the industry – standard ControlNet backplane, allowing for seamless integration within Honeywell’s control ecosystems. Additionally, it supports HART communication, which enables bidirectional communication with intelligent field devices. This feature is particularly useful as it allows engineers to remotely configure and diagnose connected actuators, reducing the need for on – site visits and minimizing downtime. The module’s modular design is another advantage, as it can be easily installed in standard Honeywell I/O racks. This simplifies the process of retrofitting into existing systems and reduces the complexity of installation, as there is no need for custom – made mounting solutions. The Honeywell CC-PAOH01 also comes equipped with built – in diagnostic LEDs that provide real – time status information. These LEDs can quickly alert maintenance personnel to potential issues, such as overcurrent conditions, communication failures, or output signal abnormalities. This proactive approach to monitoring helps in preventing major system failures and ensures continuous operation of industrial processes.
CC-PAOH01
Technical specifications:
Model Number CC-PAOH01
Brand Honeywell
Type Precision – Oriented Analog Output Module
Output Voltage 24V DC (±10%)
Output Current 4 – 20 mA (±0.05%)
Operating Temp Range – 40°C to 70°C (- 40°F to 158°F)
Mounting Style Rack – mounted (19 – inch standard)
Dimensions 125mm x 85mm x 215mm (L x W x H)
Weight 0.78kg (1.72 lbs)
Interface/Bus ControlNet, Modbus (optional)
Compliance CE, RoHS, UL 508, ATEX
Supported Protocols HART, Modbus RTU (direct or via gateway)
Typical Power Draw 2.9W
Contact Us Phone:+86 16626708626 WeChat/WhatsApp:+86 16626708626 Email: 3772179818@qq.com
CC-PAOH01
Main features and advantages:
Opting for the Honeywell CC-PAOH01 brings a plethora of benefits to industrial operations. Its robust construction, featuring a high – quality enclosure and reliable components, is built to withstand harsh industrial environments. The module is resistant to vibration, shock, and electromagnetic interference, ensuring consistent performance over an extended service life. This durability translates into reduced maintenance costs and fewer replacement requirements, as the module can operate reliably in challenging conditions. The Honeywell CC-PAOH01‘s pre – configured compatibility with Honeywell’s control systems simplifies the integration process. Engineers can easily incorporate the module into their existing infrastructure with minimal programming efforts, significantly reducing commissioning time by up to 35%. This not only expedites the deployment of new systems but also minimizes the risk of configuration errors, ensuring a seamless start – up.
During daily operation, the Honeywell CC-PAOH01 maintains an outstanding accuracy of ±0.05% in its output signals, even when faced with fluctuating ambient temperatures and electrical noise. This high level of precision enables precise control of industrial processes, resulting in improved product quality and reduced variability. By providing stable and accurate output signals, the module also alleviates the load on controllers, allowing them to focus on more complex control algorithms and decision – making tasks.
CC-PAOH01
Application areas:
The Honeywell CC-PAOH01 finds extensive applications in industries where accurate control of actuators is crucial. In the oil and gas industry, it is used to precisely control the opening and closing of valves in pipelines, ensuring the smooth flow of fluids and preventing leaks. In power generation plants, the module is employed to regulate the speed of turbines, optimizing power output and maintaining grid stability. In the food and beverage industry, it controls the filling levels in packaging machines, guaranteeing consistent product quantities. Across these industries, the Honeywell CC-PAOH01‘s ability to handle high – density analog output requirements while maintaining peak performance over long periods is invaluable, especially in scenarios where continuous and reliable operation is essential for maintaining production efficiency and competitiveness.
CC-PAOH01
Related products:
CC – PAIX01 – An analog input module that pairs perfectly with the CC – PAOH01 to form a complete control loop. The CC – PAIX01 can collect sensor data, which is then processed by the control system, and the CC – PAOH01 can send out corresponding output signals to control actuators based on this data, enabling closed – loop control of industrial processes.
CC – PCIX01 – A digital input module that can be integrated with the CC – PAOH01 in mixed – signal systems. It can monitor discrete signals, such as the status of switches and relays, while the CC – PAOH01 controls analog – based actuators. Together, they provide a comprehensive solution for systems that require both digital and analog control capabilities.
CC – PDIX01 – A digital output module that works in tandem with the CC – PAOH01. It can be used to trigger alarms, activate emergency shutdowns, or control digital devices based on the output status of the CC – PAOH01. This combination enhances the overall control and safety features of industrial automation setups.
CC – PAOH02 – A high – channel density variant of the CC – PAOH01, suitable for large – scale industrial applications that require a greater number of analog output connections. It offers the same high – performance features as the CC – PAOH01 but with an increased capacity to control more actuators, making it ideal for complex industrial processes.
CC – PAOH51 – An isolated analog output module designed for use in systems with extremely high levels of electrical noise. In environments where EMI is a major concern, such as near high – voltage transformers or large – scale power distribution equipment, the CC – PAOH51 can provide enhanced noise immunity, ensuring accurate output signal transmission.
51304391 – 100 – A legacy analog output module that is compatible with older Honeywell TDC 3000 systems. It can be used as a stepping – stone for companies looking to upgrade their existing systems gradually. While it may not have all the advanced features of the CC – PAOH01, it can still serve as a reliable option during the transition phase.
CC – TCOH01 – A thermocouple output module that is specifically designed to work in conjunction with the CC – PAOH01 in high – temperature control applications. In industries such as steel manufacturing, glass production, and foundries, where precise temperature control is crucial, the CC – TCOH01 can accurately convert thermocouple signals into control outputs, working together with the CC – PAOH01 to regulate heating and cooling processes.
CC-PAOH01
Installation and maintenance:
Before installing the Honeywell CC-PAOH01, it is imperative to conduct a comprehensive compatibility check. Verify that the firmware of the target I/O rack is at least version 5.3 or higher to ensure full compatibility with the module. Honeywell offers a dedicated firmware compatibility tool on its official website, which should be regularly updated to reflect the latest requirements. Ensure that the mounting rack has sufficient clearance around the module to facilitate proper ventilation. The CC-PAOH01 generates heat during operation, and restricted airflow can lead to performance degradation and a shortened lifespan. A minimum of 55mm of clearance above and below the module is recommended, especially in high – heat industrial environments. Thoroughly inspect the ControlNet and other communication connectors for any signs of damage or corrosion. Even a minor amount of oxidation on the connectors can cause intermittent communication problems, disrupting the normal operation of the system. If any issues are detected, clean the connectors using a suitable contact cleaner and a dry, lint – free cloth. When wiring the analog outputs, use high – quality, shielded cables to minimize the impact of electromagnetic interference. Ground the shield at both ends to enhance noise rejection, especially in areas with high levels of electrical noise.
For ongoing maintenance, establish a regular inspection routine. Check the module’s status LEDs on a weekly basis. A solid green LED indicates normal operation, while a flashing amber LED signals a minor fault, such as a low – output signal or a communication glitch. A flashing red LED indicates a more serious problem that requires immediate attention. Perform a visual inspection of the connectors and wiring every four months to ensure that they remain securely fastened. Vibration and movement in industrial environments can cause connections to loosen over time, leading to signal loss or intermittent operation. Calibrate the module annually using Honeywell’s official calibration software to maintain its high – level accuracy. Although theCC-PAOH01 is equipped with advanced drift compensation features, regular calibration is still necessary to account for any long – term changes in the module’s performance. Additionally, monitor the module’s power consumption. An abnormal increase in power draw may indicate an internal problem, such as a component malfunction, and should be investigated promptly.
