Name: Honeywell CC-PAIH01 Analog Input Module | Qiming Automation
Brand: Honeywell
Price: 56994.00 CNY
Availability: InStock

Description

The Honeywell CC-PAIH01 serves as a vital link between field sensors and the control system, converting raw analog signals from pressure, temperature, and flow transmitters into digital data that can be processed by higher-level controllers. It integrates seamlessly with Honeywell’s Experion PKS and TPS systems, connecting via the standard ControlNet backplane to ensure smooth communication within the automation architecture. What distinguishes this module is its advanced signal conditioning capabilities, which filter out electrical interference to deliver stable, noise-free data—critical for applications requiring precise process control.

CC-PAIH01

The Honeywell CC-PAIH01 supports redundant configurations, allowing it to switch automatically to a backup module in the event of a failure, thus maintaining uninterrupted operation in systems where downtime is costly. It also features built-in diagnostic tools that monitor module health and signal quality, providing real-time alerts through the control system to enable proactive maintenance. This combination of compatibility, signal processing precision, and diagnostic intelligence makes the Honeywell CC-PAIH01 a cornerstone of reliable industrial control systems.

CC-PAIH01

Technical specifications:
Model Number CC-PAIH01
BrandHoneywell
TypeAnalog Input Module
Input Voltage24V DC
Operating Temp Range-40°C to 70°C (-40°F to 158°F)
Mounting StyleRack-mounted (19-inch standard)
Dimensions125mm x 85mm x 220mm (L x W x H)
Weight0.8kg (1.76 lbs)
Interface/BusControlNet
ComplianceCE, RoHS, UL 508
Supported ProtocolsHART, Modbus RTU (via gateway)
Typical Power Draw3.5W

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

CC-PAIH01

Main features and advantages:

Choosing the Honeywell CC-PAIH01 delivers tangible operational benefits that extend beyond basic signal conversion. Engineered for long-term performance in harsh conditions, its rugged design resists vibration, humidity, and extreme temperatures, reducing the need for frequent replacements and lowering lifecycle costs. The module’s pre-configured compatibility with Honeywell’s control systems minimizes integration time—engineers can deploy it with minimal programming, reducing setup errors and accelerating commissioning. This ease of integration translates to faster project timelines and lower engineering overhead, allowing teams to focus on optimizing process performance rather than troubleshooting hardware compatibility.

In operation, the Honeywell CC-PAIH01 maintains signal accuracy across a wide range of input conditions, ensuring that control systems receive reliable data for decision-making. This precision leads to tighter process control, reduced product variability, and improved energy efficiency—key metrics in industries where operational excellence is a competitive advantage.

CC-PAIH01

Application areas:

The Honeywell CC-PAIH01 excels in industries where analog signal integrity is critical to safety and efficiency. In power generation facilities, it monitors steam pressure and turbine temperature signals, providing the precise data needed to maintain optimal generator performance and prevent overheating. In chemical processing plants, it handles corrosive environment sensor inputs, ensuring accurate readings for reactor pressure and chemical composition—measurements that directly impact batch quality and worker safety. In pharmaceutical manufacturing, the module’s high precision supports strict regulatory compliance by delivering consistent data for temperature and pH control, critical for meeting FDA and EMA process validation requirements. Across all these use cases, the Honeywell CC-PAIH01 proves its value in applications requiring continuous uptime, where even a momentary signal loss could lead to costly shutdowns or non-compliant production runs.

CC-PAIH01

Related products:

CC-PAOH01 – Analog output module for controlling valves and actuators in the same system architecture

CC-PCIH01 – Digital input module for monitoring discrete signals, complementary to the CC-PAIH01 in mixed I/O systems

CC-PDOH01 – Digital output module, ideal for pairing with the CC-PAIH01 in complete control loop implementations

CC-PAIH02 – Higher-channel density version (16 inputs vs. 8) for larger-scale applications

CC-PAIH03 – Isolated analog input module for systems requiring enhanced electrical noise immunity

51304482-100 – Legacy predecessor, compatible with older TDC 3000 systems for gradual upgrades

CC-TAOX01 – Thermocouple input module, designed for high-temperature measurement applications alongside the CC-PAIH01

Installation and maintenance:

Before installing the Honeywell CC-PAIH01, verify that the target control rack firmware is compatible with the module’s version—check Honeywell’s compatibility matrix for the latest requirements. Ensure the mounting rack has adequate cooling; the module requires ambient airflow of at least 1 m/s to maintain operating temperatures in high-heat environments. Inspect the ControlNet backplane connectors for bent pins or corrosion, as poor contact can cause intermittent communication issues. During installation, confirm that shielded wiring is used for analog inputs to maximize noise rejection—a critical step in environments with high electromagnetic interference.

For ongoing maintenance, review the module’s status LEDs monthly: a steady green light indicates normal operation, while a flashing red light signals a fault requiring attention. Perform a calibration check once a year to ensure that the input accuracy remains within the factory specifications, even though the automatic drift compensation function of the module has significantly reduced the adjustment frequency. Regularly check the tightness of input terminals to prevent loose connections caused by vibration, which is particularly important in installations near heavy machinery.
