Honeywell 05701-A-0293 Environmental Control and Monitoring Device
The Honeywell 05701-A -0293 is a highly specialized environmental control and monitoring device. It is designed to be a key building block within Honeywell’s extensive range of environmental management solutions, which are engineered to work in harmony with other components of a comprehensive control system. Functionally, it acts as a transducer, collecting real – time data on environmental factors relevant to its application and converting this information into electrical signals that can be easily interpreted and processed by control systems.
Model 05701-A -0293
BrandHoneywell
TypeEnvironmental Control and Monitoring Device
Power Supply24V AC (±10%), 50/60Hz, 100mA max
Operating Temperature- 20°C to 60°C (- 4°F to 140°F)
MountingWall – mountable with included brackets
Dimensions120mm (height) x 80mm (width) x 50mm (depth)
Weight350 grams
Interfaces1 x Modbus RTU port, 1 x BACnet MS/TP port (optional wireless module available)
CertificationsCE, UL, RoHS
Temperature Measurement Range- 40°C to 80°C (- 40°F to 176°F)
Temperature Accuracy±0.5°C
Humidity Measurement Range0% to 100% RH
Humidity Accuracy±3% RH
Response Time< 10 seconds
The Honeywell 05701-A -0293 is a highly specialized environmental control and monitoring device. It is designed to be a key building block within Honeywell’s extensive range of environmental management solutions, which are engineered to work in harmony with other components of a comprehensive control system. Functionally, it acts as a transducer, collecting real – time data on environmental factors relevant to its application and converting this information into electrical signals that can be easily interpreted and processed by control systems.
05701-A-0293
This device is engineered to integrate seamlessly into both centralized building management systems (BMS) and decentralized control setups found in industrial plants. Its modular design allows for easy installation and replacement, making it a practical choice for both new construction projects and retrofitting existing systems. What makes the Honeywell 05701-A -0293 particularly appealing to engineers and facility managers is its adaptability. It can be configured to meet the specific needs of different applications, whether it’s a small – scale office environment or a large – scale industrial complex.
05701-A-0293
Main features and advantages:
The Honeywell 05701-A -0293 showcases remarkable performance capabilities. In terms of temperature measurement, it offers an accuracy of ±0.5°C over a wide operating range, which is essential for applications where even slight temperature variations can have a significant impact. Its humidity sensing capabilities are equally impressive, with an accuracy of ±3% RH, ensuring that humidity levels are maintained precisely. This high level of accuracy is crucial in environments such as museums, where delicate artifacts are sensitive to changes in humidity.
The device also features a rapid response time, typically within 10 seconds, enabling it to detect and report changes in environmental conditions almost instantaneously. This quick response is vital for control systems to take immediate corrective actions, minimizing the risk of equipment damage or product spoilage.
From a hardware perspective, the Honeywell 05701-A -0293 is built to withstand the rigors of industrial and commercial use. Its enclosure is constructed from durable materials that are resistant to dust, moisture, and corrosion, making it suitable for installation in harsh environments. The internal components are designed to operate reliably under a wide range of temperatures, from – 20°C to 60°C, ensuring continuous performance even in extreme conditions.
In terms of communication, the Honeywell 05701-A -0293 supports multiple communication protocols, including Modbus RTU and BACnet MS/TP. This compatibility allows it to communicate effectively with a variety of control systems and devices, facilitating seamless integration into existing infrastructure. It also has the ability to transmit data wirelessly in some models, providing added flexibility for installation in areas where wired connections may be difficult to establish.
05701-A-0293
Technical specifications:
Model 05701-A -0293
BrandHoneywell
TypeEnvironmental Control and Monitoring Device
Power Supply24V AC (±10%), 50/60Hz, 100mA max
Operating Temperature- 20°C to 60°C (- 4°F to 140°F)
MountingWall – mountable with included brackets
Dimensions120mm (height) x 80mm (width) x 50mm (depth)
Weight350 grams
Interfaces1 x Modbus RTU port, 1 x BACnet MS/TP port (optional wireless module available)
CertificationsCE, UL, RoHS
Temperature Measurement Range- 40°C to 80°C (- 40°F to 176°F)
Temperature Accuracy±0.5°C
Humidity Measurement Range0% to 100% RH
Humidity Accuracy±3% RH
Response Time< 10 seconds
Contact Us Phone:+86 16626708626 WeChat/WhatsApp:+86 16626708626 Email: 3772179818@qq.com
05701-A-0293
Application areas:
In the intricate web of industrial and commercial operations, the Honeywell 05701-A -0293 has carved out a niche for itself as an essential component in various critical processes. In manufacturing plants that deal with the production of precision – engineered goods, such as electronics or high – end automotive parts, maintaining a controlled environment is crucial. The Honeywell 05701-A -0293 plays a significant role in these settings, often being part of systems that regulate temperature, humidity, and air quality within cleanrooms or production areas. By ensuring that environmental conditions remain within tight tolerances, it helps to prevent defects in the manufacturing process, thereby safeguarding product quality and reducing waste.
In large – scale data centers, where servers generate substantial heat and require a stable climate to operate efficiently, the Honeywell 05701-A -0293 contributes to the overall cooling and environmental management systems. It can be integrated into air handling units or cooling coils, accurately measuring and controlling parameters like refrigerant pressure and flow rates. This precise control not only optimizes the energy consumption of the cooling infrastructure but also extends the lifespan of the expensive server equipment by preventing overheating. Similarly, in pharmaceutical manufacturing facilities, where strict regulatory requirements govern environmental conditions to ensure the safety and efficacy of drugs, this component is utilized in environmental monitoring and control systems. It helps in maintaining the right balance of temperature, humidity, and air purity, which is essential for the proper storage and production of medications.
Related products:
Honeywell 05701 – A – 0294 – An upgraded version with enhanced sensor accuracy, suitable for applications where extremely precise environmental monitoring is required, such as in semiconductor manufacturing cleanrooms.
Honeywell 05701 – B – 0293 – A variant with additional input and output channels, allowing for more complex control scenarios, like integrating with multiple environmental control devices in a large – scale greenhouse.
Honeywell 05701 – A – 0293W – A wireless – only model, ideal for installations where running wires is challenging, such as in historical buildings or outdoor monitoring stations.
Honeywell EM – 100 – An environmental monitoring software suite that can be used in conjunction with the Honeywell 05701 – A – 0293 to provide real – time data visualization and analytics.
Honeywell CC – 200 – A communication concentrator that can be used to expand the connectivity options of the Honeywell 05701 – A – 0293 in large – scale networks, enabling it to communicate with a greater number of devices.
Honeywell FC – 300 – A filter – cleaning module that can be paired with the Honeywell 05701 – A – 0293 in applications where air quality control is a primary concern, such as in hospitals, to ensure the longevity of the sensors.
Honeywell 05701 – A – 0293S – A solar – powered version, suitable for remote or off – grid installations where access to traditional power sources is limited, like in some environmental monitoring stations in remote wilderness areas.
Installation and maintenance:
Before installing the Honeywell 05701-A -0293, ensure that the mounting surface is clean, dry, and able to support the weight of the device. If the device is being installed in an area with high electromagnetic interference, such as near large motors or power lines, consider using shielded cables for the communication and power connections to minimize interference. Also, verify that the power supply voltage matches the device’s requirements and that the electrical circuit is properly grounded.
For maintenance, it is recommended to perform monthly visual inspections of the device to check for any signs of physical damage, such as cracks in the enclosure or loose connections. Every six months, calibration of the sensors should be carried out using Honeywell – approved calibration tools and procedures. This calibration process involves comparing the device’s readings against known reference values and adjusting the sensor settings if necessary. Additionally, keep the device’s software up – to – date by regularly checking for firmware updates on the Honeywell website. These updates often include bug fixes, performance improvements, and new features that can enhance the functionality of the Honeywell 05701-A -0293.
