HIMA F8627X High Quality Ethernet Communication Module

Description

HIMA F8627X is a high-quality Ethernet communication module for the HIMA F7000 series safety controller, which is part of the ELOP II platform. As a security gateway between security and automation networks, it can establish a bidirectional bridge between fault-tolerant controllers (such as HIMA F7553) and various devices from monitoring and data acquisition (SCADA) systems to cloud gateways. Unlike standard modules, it combines SIL 3 certification with Time Sensitive Network (TSN) functionality, making it ideal for applications that require deterministic performance and advanced protocol support.

F8627X

In terms of architecture, the module adopts a dual core processor: one core processes security related traffic with microsecond level accuracy (such as emergency stop commands), while the other core manages non security data (such as OPC UA analysis), and the two do not interfere with each other. It is natively integrated with HIMA’s engineering tools, simplifying the configuration of virtual local area networks (VLANs), firewall rules, and redundancy policies. Compared to multi vendor solutions, deployment time can be reduced by up to 30%.

F8627X is positioned as a digital transformation driver that prioritizes security. It complies with the ISA/IEC 62443-4-2 standard and has AES-256 encryption, secure boot, and dynamic threat detection capabilities. For facilities that use digital twins or remote monitoring, these features make secure data transmission an indispensable part.

F8627X

Main features and advantages:
Deterministic performance: Supports PROFINET IRT protocol, with cycle times as low as 1 millisecond, and utilizes IEEE 1588 Precision Time Protocol (PTP) v2 for nanosecond level clock synchronization, which is crucial for robot motion control or high-speed packaging lines.
High speed redundancy: The dual port 1 Gbps Ethernet interface (RJ45/small package hot swappable fiber module) supports redundant ring topology, with a fault switching time of less than 20 milliseconds, and can maintain communication in case of cable or switch failure.
Built in network security: equipped with a state firewall, intrusion detection system (IDS), and zero trust whitelist filtering function, it can block unauthorized protocols (such as DNS tunnels) and implement role-based access control (RBAC).
Durable design: Complies with IP20 standards, has impact/vibration resistance (IEC 60068-2), and adopts conformal coating to ensure reliability in harsh environments such as flushing areas or offshore platforms.
Future oriented protocols: Supports OPC UA over TSN, MQTT 5.0, and Ethernet Advanced Physical Layer (APL), suitable for process automation, and can seamlessly integrate with 5G dedicated networks and edge computing.
For integrators, the module’s hot swappable design and pre diagnostic features (LED indicator lights, USB-C interface) simplify maintenance work, while its compact size (40mm wide) maximizes space savings inside the control cabinet.

F8627X

Technical specifications:
Model HIMA F8627X
Brand HIMA
Type Advanced Ethernet Communication Module (SIL 3 Certified)
Power supply 24 V DC (powered through the controller backplane, typical power consumption 6 W)
Working temperature -40 ° C to+85 ° C
Installation method: Plug in module, suitable for HIMA F7000 series rack
Dimensions 40mm (width) x 160mm (height) x 110mm (depth)
Weight 0.35 kg
Interface 2 x 1 Gbps Ethernet (RJ45+small package hot swappable fiber module), 1 x USB 3.0 (configuration)
Support protocols PROFINET IRT, Ethernet/IP, OPC UA over TSN, MQTT, Ethernet Advanced Physical Layer
Network security features AES-256/Transport Layer Security (TLS) 1.3, secure boot, intrusion detection system, dynamic firewall, role-based access control
Redundant Function Dual Port Media Redundancy Protocol/Parallel Redundancy Protocol, Hot Plug, Battery Backup Configuration Storage
Real time performance PROFINET IRT cycle time: 1 millisecond (100 nodes), jitter less than 1 microsecond
Certified International Electrotechnical Commission (IEC) 61508 (SIL 3), IEC 61511, ISA/IEC 62443-4-2, Explosion proof (ATEX), Canadian Standards Association (CSA), Det Norske Veritas (DNV GL)

contact us
Phone:+86 16626708626
WhatsApp/WeChat:+86 16626708626
Email: 3772179818@qq.com

F8627X

Application areas:
In the intelligent tire manufacturing factory, HIMA F8627X synchronizes the safety interlock of the robot assembly unit with the real-time quality control system, ensuring that emergency shutdown can be triggered within milliseconds in case of abnormalities, while transmitting production data to the edge analysis platform. At the liquefied natural gas (LNG) export terminal, it supports the PROFINET IRT protocol for isochronous control of low-temperature pump units, and microsecond level delays may lead to process instability. Engineers deploy this module to address the challenge of integrating security critical data (such as fire detector status) with operational technology (OT)/information technology (IT) networks, enabling predictive maintenance without compromising security integrity.

HIMA F8627X performs well in harsh environments, such as chemical plants with high electromagnetic interference (EMI) or desert solar power plants with extreme temperatures (-40 ° C to+85 ° C). Its dual port 1 Gbps Ethernet interface supports redundancy (Media Redundancy Protocol/Parallel Redundancy Protocol), ensuring zero downtime in the event of network failures, which is crucial for scenarios that require 24/7 operation and where downtime means revenue loss and security risks.

F8627X

Related products:
HIMA F7553- SIL 3 Fault Safety Controller, forming a core safety pair with F8627X, achieves end-to-end safety communication.
HIMA F8652X – High speed module of the same series, suitable for Time Sensitive Networks (TSN)/5G networks, very suitable for mixed settings that require support for both PROFINET and advanced protocols.
HIMA X-DI1201- Secure Digital Input Module, whose sensor data is timestamped and prioritized by F8627X for real-time transmission to the cloud.
HIMA F9650X – a next-generation legacy system gateway compatible with F8627X, used to bridge Modbus RTU systems to networks that support time sensitive networks.
HIMA F7122- Enhanced Battery Backup Module ensures that the F8627X can continue to operate in the event of a power outage.
HIMA F3403X – High precision temperature input module, whose data is aggregated by F8627X for artificial intelligence (AI) driven analysis.

Installation and maintenance:
Installation:
Network segmentation: Use virtual local area networks (VLANs) to isolate secure traffic (such as emergency stop commands) from industrial IoT data (such as maintenance alerts), and configure access control lists (ACLs) through HIMA’s engineering tools to restrict external access.
Wiring: For PROFINET IRT, use Cat6a or fiber optic cables and equip with IEEE 1588 PTP master clock to achieve enterprise level time synchronization. Deploy cables that comply with Ethernet Advanced Physical Layer standards in hazardous areas.
Redundancy testing: Simulate a dual port fault, verify that the fault switch is completed within 1 millisecond, and ensure that the media redundancy protocol/parallel redundancy protocol configuration does not generate network loops.
maintain:
Monthly Network Security Audit: Use HIMA’s security analyzer to scan for firewall configuration errors or outdated encryption passwords.
Quarterly firmware update: Apply patches through secure over the air (OTA) updates and pre test rollback programs in a mirrored environment.
Annual Health Check: Monitor packet error rates and unauthorized media access control (MAC) addresses in Simple Network Management Protocol (SNMP) traps, and validate time sensitive network traffic shaping through the module’s built-in analyzer.
