The HIMA F7130A functions as a highly efficient DC/DC converter, taking in a 24 V DC input and delivering a stable 5 V DC output. This makes it an ideal power source for a variety of components within industrial control systems, such as HIMA’s Programmable Logic Controllers (PLCs) and Input/Output (I/O) modules. One of the standout features of the HIMA F7130A is its electrical isolation between the input and output voltages. This isolation acts as a protective barrier, shielding sensitive downstream components from electrical noise and potential voltage transients that could otherwise disrupt operations or cause damage.
Model NumberF7130A
Brand HIMA
Type DC/DC Power Supply Module
Input Voltage 24 V DC (-15% to +20% tolerance), ripple < 15%
Output Voltage: 5 V DC ± 0.25 V
Output Current 10 A (for central device / io modules); 1 A for HiBus
Efficiency Rate ≥ 70%
Protection Features Overvoltage protection, current limitation, short – circuit proof
Primary Fuse 5 AGL
LED Indicators Input voltage (L +) and output voltages
Module Size 4 SU (Standard Unit)
Weight Approximately 1000 g
Operating Temperature – 20 °C to + 60 °C
Storage Temperature – 40 °C to + 85 °C
Humidity 5% to 95% (non – condensing)
The HIMA F7130A functions as a highly efficient DC/DC converter, taking in a 24 V DC input and delivering a stable 5 V DC output. This makes it an ideal power source for a variety of components within industrial control systems, such as HIMA’s Programmable Logic Controllers (PLCs) and Input/Output (I/O) modules. One of the standout features of the HIMA F7130A is its electrical isolation between the input and output voltages. This isolation acts as a protective barrier, shielding sensitive downstream components from electrical noise and potential voltage transients that could otherwise disrupt operations or cause damage.
F7130A
In terms of protection mechanisms, the HIMA F7130A is well – equipped. It comes with integrated overvoltage protection, set to activate at a specific threshold to safeguard connected devices from harmful voltage spikes. Additionally, it features current limitation capabilities, ensuring that the module operates within safe current boundaries. This not only protects the power supply module itself but also prevents overloading of downstream components. The output circuits are also short – circuit proof, meaning that in the event of an accidental short circuit, the module can safely manage the situation without causing a system – wide failure.
The front plate of the HIMAF7130A is designed for easy monitoring and operation. It is equipped with LED indicators that clearly show the presence of input voltage (L +) and output voltages. Even if the 5 V CPU / EA LED illuminates slightly, it indicates proper operation, providing users with a quick visual check of the module’s status.
F7130A
Technical specifications：
Model NumberF7130A
Brand HIMA
Type DC/DC Power Supply Module
Input Voltage 24 V DC (-15% to +20% tolerance), ripple < 15%
Output Voltage: 5 V DC ± 0.25 V
Output Current 10 A (for central device / io modules); 1 A for HiBus
Efficiency Rate ≥ 70%
Protection Features Overvoltage protection, current limitation, short – circuit proof
Primary Fuse 5 AGL
LED Indicators Input voltage (L +) and output voltages
Module Size 4 SU (Standard Unit)
Weight Approximately 1000 g
Operating Temperature – 20 °C to + 60 °C
Storage Temperature – 40 °C to + 85 °C
Humidity 5% to 95% (non – condensing)
The HIMA F7130A offers several advantages that directly translate into enhanced system performance and reliability. Firstly, its stable power output ensures that connected components operate within their optimal parameters. In industrial automation processes, where split – second timing and accurate signal processing are crucial, the HIMA F7130A‘s ability to maintain a consistent 5 V DC output is essential. Whether it’s powering a PLC that controls the movement of heavy machinery in a manufacturing plant or providing power to I/O modules that interface with sensors and actuators, the stable power supply reduces the risk of errors and malfunctions.
Secondly, its protection features act as a safety net against electrical faults. In power – intensive industrial environments, voltage spikes and electrical noise are common. The HIMA F7130A‘s overvoltage protection can prevent sensitive components from being damaged by sudden increases in voltage, while its current limitation and short – circuit proof design ensure that the module and connected devices are safeguarded from abnormal current conditions. This not only helps to prevent unplanned downtime but also extends the lifespan of the components within the system.
The HIMA F7130A also simplifies system integration. Its compact 4 SU size makes it easy to install in standard HIMA enclosures, alongside other system components. Its compatibility with a wide range of HIMA products, such as safety controllers and I/O modules, streamlines the process of building or upgrading industrial control systems. This ease of integration is particularly valuable for facilities looking to expand or modernize their operations, as it reduces engineering complexity and associated costs.
Application areas:
The HIMA F7130A finds extensive use in industries where precision and reliability are non – negotiable. In the manufacturing sector, it is commonly used to power PLCs that control automated production lines. These PLCs rely on a stable power source to execute complex control logic, ensuring that products are manufactured with consistent quality. The HIMA F7130A‘s reliable power supply helps to minimize production errors and optimize throughput.
In the process control industry, the HIMA F7130Apowers I/O modules that interface with a variety of sensors and actuators. For example, in a chemical processing plant, these I/O modules are used to monitor and control variables such as temperature, pressure, and flow. The stable power provided by the HIMA F7130A ensures that accurate sensor readings are transmitted and that actuators respond precisely to control signals, maintaining the safety and efficiency of the process.
Even in building automation systems, the HIMA F7130A plays a role. It can power control panels that manage lighting, heating, ventilation, and air – conditioning (HVAC) systems. By providing a reliable power source, it ensures that these systems operate smoothly, enhancing the comfort and energy efficiency of buildings. In each of these settings, the HIMAF7130Ademonstrates that a reliable power supply is not just a technical requirement but a fundamental element for the seamless operation of industrial and building systems.
Related products:
HIMA F7130A – E – An enhanced version with a wider input voltage range, designed for applications where input voltage stability is a concern. It may also feature an improved efficiency rate, making it more energy – efficient.
HIMA F7129 – A lower – power variant, offering a reduced output current capacity, suitable for applications with less demanding power requirements. It may share some of the protection and monitoring features of the F7130A but in a more compact form factor.
HIMA F7131 – A high – power module with an increased output current capacity, designed for applications that require more substantial power delivery. It may include advanced thermal management features to handle the higher power dissipation.
HIMA F7130A – EX – An explosion – proof variant, certified for use in hazardous areas. It has a reinforced enclosure and additional safety features to prevent ignition sources, making it suitable for use in environments with explosive gases or dust.
HIMA F7130A – R – A redundant power supply module, designed for applications where continuous operation is essential. It features dual power inputs and automatic failover, ensuring that power is never interrupted, even in the event of a module failure.
HIMA F7130A – HD – A high – density version, designed to fit more power supply capacity into a smaller space. It offers the same functionality as the standard F7130A but in a more compact form factor.
HIMA F7130A – LT – A long – term support model, with extended component availability and a longer warranty period. It is designed for applications where system longevity and support are crucial, such as in critical infrastructure projects.
Installation and maintenance:
Before installing the HIMA F7130A, it is crucial to verify that the input power source meets the module’s requirements. The 24 V DC input should be within the -15% to +20% tolerance range, with a ripple factor of less than 15%. Check the installation location for available space, as the module has a 4 SU size requirement. Ensure that there is sufficient ventilation to dissipate the heat generated by the module during operation, as overheating can affect its performance and lifespan. Inspect the wiring connections to ensure they are properly terminated and that the primary fuse (5 AGL) is correctly installed.
For ongoing maintenance, regularly monitor the output voltage using the LED indicators on the front plate. Compare the visual indication with the expected output voltage to ensure that the module is operating within the specified tolerance. Check the module for any signs of overheating, such as discoloration or unusual odors. Although the HIMAF7130Ais designed to be highly reliable, periodic visual inspections can help identify any potential issues early. If operating multiple F7130A modules in parallel, use appropriate measuring tools to verify that the output voltage difference between modules does not exceed the recommended value to avoid unbalanced loads.
