HIMA F7126 High Performance DC/DC Converter Module

Description

HIMA F7126 is a high-performance DC/DC converter module designed to meet the strictest safety and reliability requirements in the field of industrial automation. As part of HIMA’s comprehensive product line, it is specifically designed to power safety related systems and is an important cornerstone for industries where human safety, environmental protection, and continuous operation cannot be compromised.

HIMA F7126

This power module is designed to provide stable and reliable power to various components in industrial control systems. It is not just a simple power provider, but also a key driver for seamless operation of safety critical functions. Its design revolves around providing power with high safety and efficiency, in compliance with international standards such as SIL 3 (Safety Integrity Level 3) and PL e (Performance Level e). These certifications ensure that F7126 is trustworthy in applications where a single point of failure may result in serious consequences.

F7126 is compact in size and suitable for installation in control cabinets where space may be limited. Its physical size and ease of installation make it a convenient choice for new installations and retrofitting existing systems. With its standardized interface and compatibility with multiple industrial protocols, it can be easily integrated into HIMA’s own control systems as well as systems from other manufacturers.

HIMA F7126

Main features and advantages:
Wide input voltage range: F7126 can accept an input voltage range of 18-36 V DC. This wide range enables it to be used in various industrial environments where there may be fluctuations in the input power supply. For example, in areas with mobile industrial equipment or unstable power grids, the module can still operate at its optimal state, ensuring the continuous operation of the connected security system.
Stable output voltage: It provides a precisely regulated 5V DC output, which is crucial for powering sensitive electronic components in safety related automation systems. The output voltage can be adjusted within a range of ± 0.5 V, with the factory setting at 5.4 V DC ± 0.025 V. This level of accuracy ensures stable power supply to the connected devices, minimizing the risk of faults caused by voltage fluctuations.
High output current capacity: With an output current of 6.3 A (some specifications) or up to 10 A (other specifications), F7126 can power multiple devices simultaneously. This high current capacity is crucial in large-scale industrial applications, where many sensors, actuators, and control units require power supply. It can meet the power requirements of complex security related device networks without any problems.
High efficiency: The efficiency rate of this module is>90% (some sources) or ≥ 77% (other sources). This high efficiency not only reduces power consumption, but also reduces heat generation. In industrial environments where energy conservation is important and excessive heat may cause problems for other components, the efficiency of F7126 is a significant advantage. It helps to reduce overall operating costs and improve the reliability of the entire system.
Safety isolation: There is a safety isolation of>3 kV DC between the input and output voltages. This isolation protects the connected equipment from electrical faults and surges in the input power supply. In industrial environments where electrical noise and voltage spikes are common, this isolation function ensures the integrity and safety of safety related automation systems.
Overvoltage and short circuit protection: The F7126 is equipped with overvoltage protection, set to 6.5 V ± 0.5 V. It also has a short circuit protection function to ensure that the output is protected under short circuit conditions. These protective functions can prevent damage to the module itself and the connected devices, improving the overall reliability and service life of the system.

HIMA F7126

Technical specifications:
Model F7126
Brand HIMA
Type DC/DC converter power module
Input voltage range 18-36 V DC
Output voltage 5 V DC
Output current 6.3 A
Efficiency>90%
Safe isolation>3 kV DC
The overvoltage protection is set to 6.5 V ± 0.5 V
Short circuit protection is
Working temperature range -40 to+70 ° C
Storage temperature range -40 to+85 ° C
Humidity 5 to 95% (non condensing)
Size 75 x 50 x 22 mm
Weight approximately 150 grams
Compliance with Class B of VDE 0871/0877 standard
Main fuse 6.3 A slow melting fuse

Contact Us
Phone:+86 16626708626
WhatsApp/WeChat:+86 16626708626
Email: 3772179818@qq.com

HIMA F7126

Application areas:
In the refinery,F7126 supplies power to the complex network of Safety Instrumented Systems (SIS). These systems are responsible for monitoring and controlling key parameters such as pressure, temperature, and flow rate. Once an abnormal situation occurs, such as a sudden increase in pressure that could lead to catastrophic rupture, the SIS powered by F7126 will quickly issue an emergency stop signal to isolate the affected area. The stable power output of this module is crucial here, as any power fluctuations can cause delays in operations that are critical to life and property safety.

In chemical plants, the safety requirements for handling hazardous substances are extremely high, and F7126 supplies power to a series of equipment. This includes designing safety valves to release excess pressure in the reaction vessel, as well as emergency lighting systems that are crucial for safe evacuation in emergency situations. This module is capable of operating within a wide temperature range of -40 to+70 ° C, making it suitable for harsh environments commonly found in chemical manufacturing, where extreme high or low temperatures may exist.

Related products:
HIMA F7553 Controller: This SIL 3 fail safe controller can be powered by F7126. The stable power supply provided by F7126 ensures that the controller can accurately and timely execute safety critical logic. The controller then manages and coordinates the operation of various safety related equipment in industrial systems.
HIMA X-DI1201 Digital Input Module: F7126 can provide power to this module, which is used to receive digital input signals from sensors, switches, and other devices. Then, the control system processes these input signals to make decisions regarding safety related operations.
HIMA X-DO1201 Digital Output Module: This module is responsible for sending digital output signals to actuators such as solenoid valves and contactors, and can be powered by F7126. The reliable power supply provided by F7126 enables the module to execute safety related commands in a timely manner.
HIMA F8627 Ethernet Communication Module: F7126 provides the necessary power for this module, which is used to establish communication between industrial control systems and other devices such as SCADA systems or cloud based platforms. This type of communication is crucial for remote monitoring and control of security related processes.
HIMA Z7149 safety relay module: F7126 can provide power to this module, which is used to isolate and protect critical processes by converting electronic safety signals into mechanical relay outputs. The safety relay module plays a crucial role in safety critical applications, and the stable power supply provided by F7126 ensures its normal operation.

Installation and maintenance:
Installation:
Installation method: F7126 can be installed in standard industrial control cabinets. Ensure that the installation location is away from excessive vibration, heat sources, and moisture. Use appropriate installation hardware to firmly secure the module.
Wiring: When connecting input and output cables, use high-quality, appropriately rated cables. Ensure proper cable routing and avoid interference from other electrical components. For input cables, ensure that they are connected to a reliable power source within the specified voltage range. For output cables, connect them to the devices that require power supply according to the correct polarity.
Configuration: Although F7126 usually does not require complex configuration in terms of power settings, it is important to ensure that any optional features or adjustments (such as output voltage adjustment) are correctly set according to application requirements. If there are test sockets and potentiometers on the front board (if any), they can be used to adjust the output voltage as needed.
maintain:
Regular inspection: Regularly check the module for any physical damage signs, such as cracks in the housing, loose connections, or signs of overheating. Check the status indicator lights (if any) to ensure the module is functioning properly. In environments with high humidity or exposure to chemicals, special attention should be paid to checking for signs of corrosion.
Performance monitoring: Regularly monitor input and output voltage and current. Use appropriate measuring tools to check if these values are within the specified range. If there is any significant deviation, it may indicate a problem with the module or connected devices. In addition, monitor the temperature during the operation of the module to ensure that it does not exceed the maximum allowable temperature.
Firmware Update: Regularly check with HIMA if there are any available firmware updates for F7126 Although it is primarily a hardware based module, firmware updates may be released to improve performance, add new features, or address any known issues. Before applying updates, make sure to back up any relevant configuration data and strictly follow the manufacturer’s instructions.
Spare parts management: In critical applications, a backup F7126 module should be available to minimize downtime. This allows for quick replacement in case of module failure, reducing the overall downtime of the system.
