HIMA F6217 984621702 is an 8-channel analog input module designed with safety at its core.
HIMA F6217 984621702
This module is capable of processing various input signals, including 0/4… 20 mA current input and 0… 5/10 V voltage input. This wide input range makes it suitable for various industrial sensors and transmitters. For example, it can accurately measure the current output of a temperature sensor that uses a 4-20 mA signal to indicate temperature changes, or detect the 0-10 V voltage change proportional to the applied pressure output of a pressure transmitter. This module is equipped with a redundant safety related processor system, which allows for comprehensive self checking directly on the module. During operation, it continuously verifies its integrity to reduce the risk of undetected faults. The main self-test program includes checking for crosstalk between eight input channels and the functionality of input filters. With a resolution of 12 bits, this module is able to provide high-precision measurements, ensuring that even small changes in analog signals can be accurately detected and processed. In addition, it also has a safety isolation function, which is crucial for preventing electrical interference and short circuits in safety critical applications.
HIMA F6217 984621702
Technical specifications:
Model: F6217 984621702
Brand: HIMA
Type: 8-channel analog input module (safety related type)
Input voltage range: 0 to 55 VDC
Working temperature range: -20 ° C to 160 ° C
Input signal type: current (0/4… 20 mA), voltage (0… 5/10 V)
Resolution: 12 bits
Security features: redundant processor system, secure isolation
Long term drift:<0.3%
Frequency range: 24 to 68 kHz
contact us
Phone:+86 16626708626
WhatsApp/WeChat:+86 16626708626
Email: 3772179818@qq.com
HIMA F6217 984621702
Main features and advantages:
This module is designed for high reliability and can withstand the harsh conditions commonly found in industrial environments, including dust, vibration, and extreme temperature fluctuations. Its long-term drift is less than 0.3%, ensuring long-term stable performance and reducing the need for frequent calibration and maintenance. The wide input voltage range and compatibility with various signal types of this module simplify system integration, making it easy to integrate into existing control systems based on programmable logic controllers (PLC) or distributed control systems (DCS). This reduces the engineering costs associated with customized interfaces and signal conditioning circuits. The built-in diagnostic function of the module is implemented by a redundant processor system, enabling maintenance personnel to take proactive measures. By continuously monitoring input signals and the internal status of modules, potential problems can be detected early, allowing for timely intervention and reducing unexpected downtime. This not only improves the overall productivity of industrial processes, but also reduces maintenance costs associated with major malfunctions.
HIMA F6217 984621702
Application areas:
In petrochemical plants, it is used to monitor the flow of various chemicals in pipelines. By accurately measuring analog signals from flow meters (which typically use 4-20 mA current signals), this module helps ensure that chemical processes operate within safe and efficient parameter ranges.
In power generation facilities, the F6217 984621702 module can measure the voltage and current of electrical systems, as well as the temperature and pressure of generators and turbines. These data are crucial for optimizing power generation, preventing equipment failures, and maintaining grid stability.
In the manufacturing industry, this module can be used to monitor the performance of production machinery. For example, it can measure the vibration level of motors or the pressure in hydraulic systems, providing valuable insights for predictive maintenance and improving product quality.
HIMA F6217 984621702
Related products:
HIMA F6218- Upgraded version with additional input channels or enhanced signal processing capabilities, suitable for more complex industrial applications that require processing large amounts of analog signals.
HIMA F6217-EX – Explosion proof type, designed for use in hazardous areas with explosive atmospheric risks. This version provides an additional layer of security to ensure reliable operation in environments where standard modules may pose security risks.
HIMA F6216- Cost effective, slightly reduced feature set, suitable for small industrial settings or applications that do not require all the functions of F6217 984621702.
HIMA F6217-R – Redundant Configuration Module provides higher reliability for critical mission applications. In the event of a module component failure, redundant systems can seamlessly take over, ensuring continuous operation and maintaining safety integrity.
HIMA F6217-PRO – Professional grade model with advanced diagnostic and communication capabilities. This version is customized for complex industrial environments that require in-depth monitoring and precise control, allowing for more detailed analysis of analog signals and better integration with other advanced control systems.
HIMA F6217-LITE – Compact and lightweight, perfect for space constrained installation scenarios where size and weight are important considerations. Despite its smaller size, it still retains the basic safety and analog signal input functions of the standard F6217 984621702 module.
HIMA F6217 984621702
Installation and maintenance:
Before installing the HIMA F6217 984621702 module, several important pre installation checks need to be performed. Firstly, carefully verify whether the input voltage range at the installation site is within the range of 0 to 55 VDC supported by the module. Ensure that the ambient temperature and other environmental conditions at the installation location are within the specified operating temperature range of -20 ° C to 160 ° C. Check the available installation space to ensure proper installation, especially if there are specific space requirements. In addition, confirm that the communication protocol and signal requirements of the existing control system are compatible with the F6217 984621702 module.
For ongoing maintenance, regularly review the diagnostic information provided by the module. Pay close attention to any status indicator lights or fault messages that may be displayed. Regularly check for signs of wear, corrosion, or looseness in the connections. Conduct a comprehensive functional test once a year to ensure that all input channels are functioning properly, the self checking mechanism is running as expected, and the module maintains its high performance and safety integrity level.
