The HIMA F3331 operates as an 8-channel digital output module, integrating seamlessly with HIMA F3 series safety controllers (such as the F3240) via the system’s high-speed backplane. Like its counterpart, the F3330, it delivers 24 V DC outputs capable of driving resistive and inductive loads up to 500 mA per channel—making it suitable for controlling valves, actuators, and indicator devices in safety-critical applications. Where the HIMA F3331 distinguishes itself is in its diagnostic engine: each channel features real-time monitoring that tracks signal integrity, voltage levels, and current draw, with data transmitted continuously to the host controller.
Model Number F3331
Brand HIMA
Type 8-Channel Digital Output Module
with Advanced Diagnostics Input Voltage 5 V DC (120 mA) for module operation; 24 V DC (200 mA max) for outputs
Operating Temp Range -25°C to +70°C (-13°F to +158°F)
Mounting Style Rack-mounted in HIMA F3 enclosures
Dimensions: 19.2 cm x 11.4 cm x 4.6 cm (7.5 in x 4.5 in x 1.8 in)
Weight 2.1 kg (4.6 lb)
Interface/Bus HIMA F3 backplane (100 Mbps)
Compliance SIL 3 (IEC 61508/61511), Cat. 4 (EN 954-1), PL e (EN ISO 13849-1), CE, RoHS
Output Channels 8 digital outputs (24 V DC)
Load Capacity 500 mA per channel (resistive/inductive); 4 W max for lamps
Diagnostic Capabilities Real-time current/voltage monitoring per channel; short-circuit logging; leakage current tracking; self-test logs
Voltage Drop monitors 0.1V resolution per channel
CommunicationDiagnostic data over backplane (integrated with SILWORX software)
Short Circuit ProtectionAuto-recovery with fault logging
Leakage Current Detection <350 µA (alert threshold adjustable via software)
Test Signal Duration <200 µs (non-intrusive to load devices)
Space Requirement 4 TE
The HIMA F3331 operates as an 8-channel digital output module, integrating seamlessly with HIMA F3 series safety controllers (such as the F3240) via the system’s high-speed backplane. Like its counterpart, the F3330, it delivers 24 V DC outputs capable of driving resistive and inductive loads up to 500 mA per channel—making it suitable for controlling valves, actuators, and indicator devices in safety-critical applications. Where the HIMA F3331 distinguishes itself is in its diagnostic engine: each channel features real-time monitoring that tracks signal integrity, voltage levels, and current draw, with data transmitted continuously to the host controller.
F3331
This diagnostic data includes granular details such as channel-specific voltage drops, short-circuit events, and leakage current trends—information that goes far beyond basic “on/off” status. The module also performs advanced self-tests, including dynamic load verification and communication path checks, which are logged and timestamped for audit trails. When paired with HIMA’s SILWORX software, the HIMA F3331provides a centralized dashboard showing all diagnostic metrics, allowing engineers to spot degradation in individual channels before they fail. This integration ensures that diagnostic insights are actionable, enabling targeted maintenance rather than blanket system checks. Whether deployed in a new SIS or as an upgrade to legacy systems, the HIMA F3331bridges the gap between safety control and predictive maintenance.
F3331
Technical specifications：
Model Number F3331
Brand HIMA
Type 8-Channel Digital Output Module
with Advanced Diagnostics Input Voltage 5 V DC (120 mA) for module operation; 24 V DC (200 mA max) for outputs
Operating Temp Range -25°C to +70°C (-13°F to +158°F)
Mounting Style Rack-mounted in HIMA F3 enclosures
Dimensions: 19.2 cm x 11.4 cm x 4.6 cm (7.5 in x 4.5 in x 1.8 in)
Weight 2.1 kg (4.6 lb)
Interface/Bus HIMA F3 backplane (100 Mbps)
Compliance SIL 3 (IEC 61508/61511), Cat. 4 (EN 954-1), PL e (EN ISO 13849-1), CE, RoHS
Output Channels 8 digital outputs (24 V DC)
Load Capacity 500 mA per channel (resistive/inductive); 4 W max for lamps
Diagnostic Capabilities Real-time current/voltage monitoring per channel; short-circuit logging; leakage current tracking; self-test logs
Voltage Drop monitors 0.1V resolution per channel
CommunicationDiagnostic data over backplane (integrated with SILWORX software)
Short Circuit ProtectionAuto-recovery with fault logging
Leakage Current Detection <350 µA (alert threshold adjustable via software)
Test Signal Duration <200 µs (non-intrusive to load devices)
Space Requirement 4 TE
The HIMA F3331 delivers tangible benefits that redefine how safety systems are managed, starting with reduced downtime. Its advanced diagnostics eliminate the need for scheduled “blind” maintenance—instead of shutting down the system to test every output channel, engineers can use real-time data to identify which channels require inspection. For example, a gradual increase in voltage drop on Channel 3 might indicate a loose connector, while a spike in leakage current on Channel 7 could signal a failing relay in a connected valve. By targeting only problematic channels, maintenance teams minimize disruption to operations—a critical advantage in industries like chemical processing or power generation, where unplanned shutdowns cost thousands per hour.
Another key benefit is enhanced safety integrity. The HIMAF3331’s ability to detect incipient faults means potential issues are addressed before they compromise safety functions. In a refinery’s emergency shutdown system, for instance, early detection of a weakening output channel controlling a pressure relief valve ensures the valve operates when needed during an overpressure event. This proactive fault management also simplifies compliance with safety standards like IEC 61511, which require evidence of ongoing system integrity— the module’s timestamped diagnostic logs provide automatic documentation of performance trends.
Operational efficiency is further improved by the module’s integration with existing HIMA ecosystems. Since the HIMA F3331 uses the same form factor and backplane communication as the F3330, it can replace older modules without reconfiguring racks or rewiring. Its diagnostic data feeds directly into HIMA’s safety management software, avoiding the need for separate monitoring systems. For facilities scaling their safety systems, this compatibility reduces engineering overhead, allowing teams to standardize on a single module type that balances performance and diagnostics.
F3331
Application areas:
The HIMA F3331 excels in industries where both safety and operational visibility are critical, proving its value in applications that demand proactive maintenance and high reliability. In oil and gas refineries, it is widely used to control emergency shutdown valves (ESVs) in distillation units. Here, its channel-specific diagnostics are invaluable: a sudden drop in current on an ESV output channel can alert engineers to a sticking valve—allowing maintenance during a scheduled outage instead of risking a failure during a crisis. The module’s ability to log short-circuit events also helps identify wiring issues in harsh environments, where vibration or corrosion can degrade connections over time.
In pharmaceutical manufacturing, the HIMA F3331controls safety interlocks on sterile processing lines, where unplanned shutdowns can ruin batches worth millions. Its diagnostic data ensures that output channels powering door locks or pressure relief mechanisms are continuously verified, with trends in voltage drop flagging potential issues before they disrupt production. The module’s compliance with strict regulatory standards (including GMP requirements) also simplifies audit trails, as diagnostic logs provide irrefutable evidence of system health.
Water treatment plants, too, benefit from the HIMA F3331’s capabilities, particularly in systems managing chemical dosing pumps. By monitoring current draw on output channels, the module can detect a pump’s increasing power demand—an early sign of mechanical wear—allowing replacement during off-peak hours. In each of these settings, the HIMA F3331 demonstrates that advanced diagnostics aren’t just a convenience—they’re a critical tool for balancing safety, compliance, and operational efficiency.
Related products:
HIMA F3331-EX – Explosion-proof variant with ATEX/IECEx certification for Zone 1 hazardous areas, featuring enhanced sealing and corrosion resistance.
HIMA F3331-HD – High-density version with 16 channels (instead of 8) for space-constrained enclosures, maintaining per-channel diagnostics.
HIMA F3331-R – Redundant output module with mirrored channels for 24/7 operations, where single-point failures are unacceptable.
HIMA F3330 – Base model without advanced diagnostics, ideal for cost-sensitive applications with lower maintenance needs.
HIMA F3332 – High-voltage variant (48 V DC outputs) with similar diagnostic features, for industrial actuators requiring higher power.
HIMA F3331-LT – Long-term support model with extended component lifecycle, designed for facilities with multi-decade operational plans.
HIMA F3334 – Compact 8-channel module with reduced depth, retaining diagnostics for enclosures with space restrictions.
Installation and maintenance:
Before installing the HIMA F3331, verify that the host F3 controller’s firmware is version 6.2 or higher to ensure full compatibility with diagnostic data transmission. Check the backplane for available 4 TE slots, ensuring at least 30 mm of clearance above the module for airflow—diagnostic components generate slightly more heat than basic output modules. Confirm that the 24 V DC power supply can handle the module’s 200 mA max draw (plus connected loads), with stable voltage to avoid false diagnostics from power fluctuations.
For ongoing maintenance, leverage the HIMA F3331’s diagnostic data to create a condition-based schedule. Weekly, review SILWORX dashboards to track voltage drop trends across all channels—consistent increases in a single channel may indicate a loose terminal or aging load device. Monthly, export diagnostic logs to compare against baseline values, using this data to prioritize preventive maintenance (e.g., re-torquing connectors on channels showing rising resistance). During annual safety tests, use the module’s built-in test mode to simulate faults and validate that diagnostics trigger correctly—this ensures the monitoring system itself remains reliable. Unlike basic modules, the HIMA F3331 rarely requires calibration, but its communication path to the controller should be verified quarterly to ensure diagnostic data isn’t being interrupted.
