HIMA F3322 High-Density Digital I/O Expansion Module
Sale!
HIMA F3322 High-Density Digital I/O Expansion Module
The HIMA F3322 functions as a digital input/output expansion module, designed to integrate directly with HIMA F3 series safety controllers via the system’s high-speed backplane. Its primary role is to extend the controller’s I/O capacity, adding 32 digital input channels and 32 digital output channels—all while maintaining the same SIL 3 safety integrity level as the core controller. This integration is seamless: once installed in the F3 rack, the module is automatically recognized by the controller, eliminating the need for complex configuration or calibration.
Model NumberF3322
Brand HIMA
Type High-Density Digital I/O Expansion Module
Input Voltage 24 V DC ± 15% (from backplane)
Operating Temp Range -40°C to +70°C (-40°F to +158°F)
Mounting Style Rack-mounted in F3 system enclosures
Dimensions: 80 mm x 160 mm x 220 mm (3.1 in x 6.3 in x 8.7 in)
Weight 450 g (0.99 lbs)
Interface/Bus F3 backplane (100 Mbps)
Compliance IEC 61508 (SIL 3), IEC 61511, CE, RoHS, ATEX, IECEx
Supported Protocols Integrated with F3 controller protocols (PROFIBUS, Ethernet/IP)
Input Channels 32 digital inputs (24 V DC, sinking/sourcing)
Output Channels 32 digital outputs (24 V DC, 0.5 A per channel)
Typical Power Draw 8 W
The HIMA F3322 functions as a digital input/output expansion module, designed to integrate directly with HIMA F3 series safety controllers via the system’s high-speed backplane. Its primary role is to extend the controller’s I/O capacity, adding 32 digital input channels and 32 digital output channels—all while maintaining the same SIL 3 safety integrity level as the core controller. This integration is seamless: once installed in the F3 rack, the module is automatically recognized by the controller, eliminating the need for complex configuration or calibration.
F3322
What distinguishes the HIMAF3322 is its intelligent signal processing. Each input channel features built-in filtering to reduce noise from electromagnetic interference (EMI), a common issue in industrial environments with heavy machinery. Output channels, meanwhile, include short-circuit protection and overload detection, preventing damage to the module or connected devices during fault conditions. The module also communicates diagnostic data in real time to the host controller, providing visibility into channel status, connection integrity, and operating temperatures—critical information for proactive maintenance. Whether used to add I/O points to a new F3240 system or expand a legacy F3236 setup, the HIMA F3322 ensures that expanded safety systems maintain the same responsiveness and reliability as the original configuration.
F3322
Main features and advantages:
Choosing the HIMA F3322 delivers tangible benefits that extend beyond simple I/O expansion. Its high-density design—packing 64 channels into a module that occupies just one slot in the F3 rack—maximizes cabinet space efficiency. This is particularly valuable in retrofits or upgrades, where existing enclosures may have limited room for additional hardware. Engineers can add dozens of new I/O points without relocating the entire system or investing in larger cabinets, reducing both material costs and installation time.
The module’s native integration with F3 controllers ensures that expanded systems maintain consistent safety performance. Unlike third-party expansion modules that often introduce latency or compatibility issues, the HIMA F3322 communicates with the controller at backplane speeds, ensuring that input signals reach the safety logic processor in under 1 ms. This speed is critical in time-sensitive applications, such as emergency shutdown sequences, where delays could compromise safety. Additionally, the module’s diagnostic data is fully integrated into HIMA’s SILWORX software, allowing engineers to monitor all I/O points—original and expanded—from a single interface, simplifying troubleshooting and maintenance.
Durability is another key advantage. Like all HIMA components, the HIMAF3322 is engineered to withstand harsh industrial environments, with resistance to vibration, temperature extremes, and electrical noise. Its outputs are protected against short circuits and overloads, reducing the risk of module failure during field device faults. For facilities operating in challenging conditions—from chemical plants with corrosive atmospheres to offshore platforms with high humidity—this ruggedness translates to longer service life and fewer unplanned shutdowns.
F3322
Technical specifications:
Model NumberF3322
Brand HIMA
Type High-Density Digital I/O Expansion Module
Input Voltage 24 V DC ± 15% (from backplane)
Operating Temp Range -40°C to +70°C (-40°F to +158°F)
Mounting Style Rack-mounted in F3 system enclosures
Dimensions: 80 mm x 160 mm x 220 mm (3.1 in x 6.3 in x 8.7 in)
Weight 450 g (0.99 lbs)
Interface/Bus F3 backplane (100 Mbps)
Compliance IEC 61508 (SIL 3), IEC 61511, CE, RoHS, ATEX, IECEx
Supported Protocols Integrated with F3 controller protocols (PROFIBUS, Ethernet/IP)
Input Channels 32 digital inputs (24 V DC, sinking/sourcing)
Output Channels 32 digital outputs (24 V DC, 0.5 A per channel)
Typical Power Draw 8 W
The HIMA F3322 finds its stride in industries where safety system scalability is critical, proving its value in applications that demand both high I/O density and uncompromising reliability. In large-scale chemical processing plants, it is frequently used to expand safety systems monitoring reactor vessels and pipeline networks. Here, the module adds input channels for pressure and temperature switches while providing outputs for emergency isolation valves—all without exceeding cabinet space limits. Its noise-filtering inputs ensure accurate signal transmission even in environments with heavy motor or pump interference, a common issue in these facilities.
In automotive manufacturing, the HIMAF3322 supports the expansion of safety systems in production lines, where dozens of sensors monitor robotic welders, conveyor belts, and material handling equipment. The module’s high channel count allows engineers to add safety interlocks for new workstations without replacing the existing F3 controller, minimizing disruption to production schedules. Its fast response times are crucial here, ensuring that a detected hazard—such as a worker entering a restricted zone—triggers an immediate shutdown of nearby machinery.
Water and wastewater treatment plants also benefit from the HIMA F3322, particularly in facilities upgrading from legacy systems. These plants often require additional I/O points to monitor new filtration systems, chemical dosing pumps, or overflow detectors. The module’s compatibility with older F3 controllers allows for incremental upgrades, letting facilities expand safety coverage as their needs grow without incurring the cost of a full system replacement. In each of these settings, the HIMA F3322 demonstrates its ability to scale safety systems efficiently while maintaining the performance required for critical operations.
F3322
Related products:
HIMA F3321 – Lower-density variant with 16 inputs/16 outputs, ideal for smaller expansions.
HIMA F3323 – High-power output version, with 2 A per output channel for controlling larger actuators.
HIMA F3324 – Mixed-signal module combining 16 digital inputs, 16 digital outputs, and 8 analog inputs.
HIMA F3325 – Redundant I/O module with dual backplane connections for fault-tolerant systems.
HIMA F3326 – Explosion-proof version certified for Zone 1 hazardous areas, with reinforced enclosures.
HIMA F3327 – Fiber-optic interface module, pairing with the F3322 to extend I/O signals over long distances.
HIMA F3328 – Diagnostic add-on module that enhances the F3322’s monitoring capabilities with advanced fault analysis.
Installation and maintenance:
Before installing the HIMA F3322 verify that the host F3 controller (such as the F3240) is running firmware version 6.0 or higher—older versions may limit the module’s diagnostic functionality. Check the rack’s backplane for available slots, ensuring there is at least 20 mm of clearance above and below the module for airflow, as it generates slightly more heat than lower-density I/O modules. Confirm that the system’s power supply can accommodate the additional 8 W draw, particularly if multipleF3322 modules are being added; HIMA recommends a 24 V DC supply with at least 5 A capacity for every four modules.
For ongoing maintenance, include the HIMA F3322 in regular safety system checks. Weekly, review SILWORX software logs to monitor for input signal noise or output overload events, which may indicate failing field devices. Every six months, inspect the module’s backplane connector for corrosion or bent pins—pay special attention in humid or dusty environments. During annual system testing, verify that all 64 channels respond correctly to test signals, ensuring that the module’s internal circuitry hasn’t degraded. Unlike some expansion modules, the HIMA F3322 does not require periodic calibration, reducing long-term maintenance overhead.
