The HIMA F3 AIO 84 01 is a compact and high – performance analog input/output (AIO) module, designed to meet the demanding requirements of safety – related and industrial control applications. In industrial settings, precise monitoring and control of analog signals are essential for maintaining optimal process conditions. Whether it’s accurately measuring the temperature of a reactor in a chemical plant, the pressure in a pipeline of an oil refinery, or the flow rate of a liquid in a pharmaceutical manufacturing process, the F3 AIO 84 01 steps in as a reliable solution.
Model NumberF3 AIO 84 01
Brand HIMA
Type Analog Input/Output Module
Input Channels 8
Input Signal Types Thermocouples (J, K, T, E, etc.), RTDs (Pt100, Pt1000), 4 – 20mA, 0 – 10V
Output Channels 4
Output Signal Types 4 – 20mA, 0 – 10V
Accuracy ±0.1% of full scale
Operating Temp Range -20°C to +70°C
Power Supply 24V DC ±10%
Mounting Style DIN rail (35mm)
Dimensions 100mm x 120mm x 80mm (W x H x D)
Weight 350g
Compliance IEC 61508 SIL 3, IEC 61511, TUV SUD certified, ATEX, IECEx
Isolation Channel-to-channel isolation, input-to-output isolation (2.5kVrms)
The HIMA F3 AIO 84 01 is a compact and high – performance analog input/output (AIO) module, designed to meet the demanding requirements of safety – related and industrial control applications. In industrial settings, precise monitoring and control of analog signals are essential for maintaining optimal process conditions. Whether it’s accurately measuring the temperature of a reactor in a chemical plant, the pressure in a pipeline of an oil refinery, or the flow rate of a liquid in a pharmaceutical manufacturing process, the F3 AIO 84 01 steps in as a reliable solution.
F3 AIO 84 01
For instance, in a large – scale chemical manufacturing unit, inconsistent or inaccurate control of analog parameters can lead to product quality variations, equipment wear – and – tear, and even safety hazards. The F3 AIO 84 01 is engineered to address these concerns by providing a stable and accurate means of handling analog signals, thereby contributing to smooth and safe industrial operations.
Functionally, the HIMA F3 AIO 84 01 serves as a bridge between field – mounted analog sensors and actuators and the central control system. It is equipped with 8 analog input channels and 4 analog output channels. The input channels can accept a wide range of analog signals from sensors such as thermocouples, resistance temperature detectors (RTDs), pressure transmitters, and flow meters. These signals are then accurately processed and converted into a format that can be easily understood by the control system.
On the output side, the 4 analog output channels are used to control various analog – based actuators, such as control valves and variable – speed drives. This allows for precise regulation of industrial processes, ensuring that parameters remain within the desired operating ranges.
One of the standout features of the F3 AIO 84 01 is its high – accuracy signal conditioning. It employs advanced filtering and amplification techniques to minimize noise and interference, ensuring that the input signals are clean and reliable. This is crucial in industrial environments where electromagnetic interference (EMI) and electrical noise are prevalent.
The module also offers excellent linearity, which means that the relationship between the input and output signals is highly consistent. This linear behavior enables more accurate control algorithms to be implemented, resulting in better – tuned industrial processes.
F3 AIO 84 01
Main features and advantages:
The HIMAF3 AIO 84 01 finds applications in a diverse array of industries. In the power generation sector, it is used to monitor and control the temperature, pressure, and flow of steam in turbines. By accurately regulating these parameters, the module helps optimize the efficiency of power generation and ensures the safe operation of the turbine.
In the food and beverage industry, theF3 AIO 84 01 is employed to control the temperature and pressure during the cooking, sterilization, and bottling processes. Precise control of these parameters is essential for maintaining product quality and ensuring food safety.
In the water and wastewater treatment industry, the module is used to measure and control the pH value, dissolved oxygen content, and turbidity of water. By accurately regulating these parameters, it helps ensure the proper treatment of water and the protection of the environment.
F3 AIO 84 01
Technical specifications：
Model NumberF3 AIO 84 01
Brand HIMA
Type Analog Input/Output Module
Input Channels 8
Input Signal Types Thermocouples (J, K, T, E, etc.), RTDs (Pt100, Pt1000), 4 – 20mA, 0 – 10V
Output Channels 4
Output Signal Types 4 – 20mA, 0 – 10V
Accuracy ±0.1% of full scale
Operating Temp Range -20°C to +70°C
Power Supply 24V DC ±10%
Mounting Style DIN rail (35mm)
Dimensions 100mm x 120mm x 80mm (W x H x D)
Weight 350g
Compliance IEC 61508 SIL 3, IEC 61511, TUV SUD certified, ATEX, IECEx
Isolation Channel-to-channel isolation, input-to-output isolation (2.5kVrms)
The HIMA F3 AIO 84 01 offers several distinct advantages in industrial applications. Its high – accuracy measurement and control capabilities make it suitable for industries where tight process tolerances are required. In the pharmaceutical industry, for example, accurate control of temperature and pressure during drug manufacturing is critical to ensure product quality and safety. The F3 AIO 84 01 can precisely monitor and adjust these parameters, helping pharmaceutical companies meet strict regulatory requirements.
The module’s compatibility with a wide range of analog sensors and actuators enhances its versatility. It can be easily integrated into existing industrial control systems, whether they are part of a small – scale manufacturing unit or a large – scale industrial complex. This reduces the need for extensive system re – engineering and simplifies the process of upgrading or expanding industrial control setups.
Furthermore, the F3 AIO 84 01‘s robust design and wide operating temperature range make it suitable for use in harsh industrial environments. It can withstand vibrations, temperature fluctuations, and electrical noise, ensuring reliable operation even in the most challenging conditions. This is particularly important in industries such as mining, where equipment must operate in rugged and unpredictable environments.
F3 AIO 84 01
Application areas:
The HIMA F3 AIO 84 01 finds applications in a diverse array of industries. In the power generation sector, it is used to monitor and control the temperature, pressure, and flow of steam in turbines. By accurately regulating these parameters, the module helps optimize the efficiency of power generation and ensures the safe operation of the turbine.
In the food and beverage industry, theF3 AIO 84 01 is employed to control the temperature and pressure during the cooking, sterilization, and bottling processes. Precise control of these parameters is essential for maintaining product quality and ensuring food safety.
In the water and wastewater treatment industry, the module is used to measure and control the pH value, dissolved oxygen content, and turbidity of water. By accurately regulating these parameters, it helps ensure the proper treatment of water and the protection of the environment.
F3 AIO 84 01
Related products:
HIMA F3 AIO 44 01 – A smaller – scale version with 4 analog input and 4 analog output channels, suitable for applications with fewer analog signal requirements.
HIMA F3 AIO 88 01 – A more extensive version with 8 analog input and 8 analog output channels, designed for large – scale industrial processes with a high number of analog signals to manage.
HIMA F3 AIO 84 01 – PRO – A professional – grade variant with enhanced diagnostic and data – logging capabilities, ideal for applications where detailed process monitoring and analysis are required.
HIMA AIO – CAL – 01 – A calibration tool specifically designed for the F3 AIO series modules, ensuring accurate measurement performance over time.
HIMA AIO – COMM – 01 – A communication adapter that enables the F3 AIO 84 01 to connect to different industrial communication networks, such as Ethernet/IP or Profibus – DP, expanding its connectivity options.
Installation and maintenance:
Installing the HIMA F3 AIO 84 01 requires careful attention to detail. The module should be mounted securely on a 35mm DIN rail in a control cabinet. Proper grounding is essential to minimize the effects of EMI and ensure reliable operation. When connecting the input and output signals, it is crucial to follow the wiring diagrams provided in the technical documentation carefully. The correct selection of shielded cables can also help reduce signal interference.
During installation, it is important to verify that the power supply voltage is within the specified range. Any deviation from the recommended voltage can affect the module’s performance and reliability. Additionally, the module’s configuration settings, such as input signal type and range, should be set correctly according to the requirements of the industrial process.
For ongoing maintenance, regular calibration of theF3 AIO 84 01 is recommended. Calibration intervals can vary depending on the application and environmental conditions, but typically range from 6 months to 2 years. During calibration, the module’s accuracy is checked and adjusted if necessary to ensure continued reliable operation.
It is also important to periodically inspect the module for signs of physical damage, such as cracks or corrosion. Loose connections should be tightened, and any signs of overheating, such as discolored components, should be investigated immediately. By following these maintenance procedures, the lifespan of theF3 AIO 84 01 can be extended, and the risk of unexpected failures can be minimized.
