HAI805 high-precision analog input module

Description

HAI805 Product Description:
HAI805 is a high-precision analog input module designed specifically for ABB’s Freelance DCS or similar modular control systems. As a key component in the data acquisition architecture, it converts analog signals (voltage, current, thermocouple, RTD) into digital values for processing by the controller or human-machine interface (HMI). This module typically supports 8-16 independent channels, each of which can be configured to receive different signal types, making it suitable for mixed sensor environments.

HAI805

HAI805achieves plug and play compatibility by combining with ABB’s I/O products and has built-in diagnostic functionality, simplifying sensor integration. Its role in the control loop is to provide real-time, high fidelity data for monitoring process variables and executing control strategies. The value proposition of this module lies in its high-resolution analog-to-digital conversion (16-24 bits), advanced noise filtering, and robust isolation design, ensuring reliable operation in environments with electromagnetic interference (EMI) or voltage transients.

HAI805

Product features and advantages:
Multi signal compatibility
HAI805 supports multiple input types, including:
4-20 mA current loop (with loop power supply)
0-10V, ± 10V voltage signal
Thermocouples (J, K, T, E, R, S, B types)
RTD（Pt100、Pt1000、Ni1000）
This flexibility reduces the need for dedicated signal conditioners and simplifies hardware setup.
High precision and anti-interference ability
With a 24 bit analog-to-digital converter (ADC) resolution and built-in anti aliasing filter, this module has an accuracy of up to ± 0.05% of full scale, making it ideal for critical measurements such as mass flow or analytical instrument output. The electrical isolation between the channel and the system bus (2.5 kVrms) can prevent ground loops, while digital filtering options (such as moving averages) can reduce noise generated by rotating machinery or welding operations.
Robust industrial design
This module can operate within a temperature range of -40 ° C to+70 ° C and complies with the IEC 61000-6-2 electromagnetic compatibility (EMC) standard, capable of withstanding harsh conditions in manufacturing factories or outdoor installations. The compact DIN rail installation (30-50 mm width) optimizes space utilization in the control cabinet, while the detachable terminal blocks simplify wiring and maintenance.
Intelligent diagnosis
The real-time monitoring function includes signal validity check (such as over limit, open circuit), sensor drift detection, and channel specific fault alarm. LED indicator lights provide visual feedback on power, communication, and channel status for quick troubleshooting. For example, in a sewage treatment plant, this module may flag a fault in the pressure sensor in the pump line, triggering an alarm before affecting process efficiency.

HAI805

Technical specifications:
Model HAI805
Brand ABB
Type Analog Input Module (AI)
Number of channels: 8 independent channels (each channel can be configured)
Signal type 4-20 mA, 0-10 V, ± 10 V, thermocouple RTD
Resolution 24 bits
Accuracy ± 0.05% FS (current/voltage), ± 0.5 ° C (thermocouple/RTD)
Isolation of 2.5 kVrms (channel to system, channel to channel)
Power supply 24 V DC (supports 10-30 V DC range, supports redundant inputs)
Working temperature -40 ° C to+70 ° C
Installation method DIN rail (TS 35/7.5)
Dimensions 50 mm (width) x 100 mm (height) x 100 mm (depth)
Weight 0.3 kg
Certification CE, UL, IEC 61131-2, ATEX (optional for hazardous areas)
Environmental grade IP20, IEC 61000-6-2 (compliant with EMC standards)

Contact Us
Mobile:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

HAI805

Application areas:
In industrial process control and automation systems, the HAI805 analog input module is a critical interface that connects continuous sensor data with distributed control systems (DCS) or programmable logic controllers (PLC). This module is designed for harsh industrial environments and is widely used in industries such as oil and gas, chemical processing, and power generation. It is used to monitor and digitize analog signals from transmitters, flow meters, pressure sensors, and temperature probes. For example, in a refinery, HAI805can convert the 4-20 mA signal from the tank level transmitter into digital data for real-time inventory management. In thermal power plants, it can collect thermocouple voltage signals to monitor the temperature of the steam turbine, thereby accurately controlling the cooling system and preventing overheating.

This module performs particularly well in applications that require high precision and anti-interference capabilities. Engineers rely on their ability to handle multiple independent channels, each equipped with advanced signal conditioning capabilities. HAI805is widely used in scenarios such as closed-loop PID control or predictive maintenance systems. For example, on a pharmaceutical production line, this module can monitor the pH value in the reaction kettle with an accuracy of ± 0.1%, ensuring batch consistency and compliance with regulatory requirements. By prioritizing signal integrity, scalability, and robust design, HAI805 addresses the core challenges of reliably capturing and processing analog data in complex, high-risk industrial environments.

HAI805

Related product introduction:
HAO805: A matched analog output module used for closed-loop control, with similar isolation and accuracy characteristics.
HDI 810: Digital input module for discrete signals, complementary to HAI805 in hybrid control systems.
HDO810: Digital output module for actuators, controlled by HAI805 data.
PM861AK01: ABB AC 800M controller module, which processes analog input data from HAI805 for control logic.
TA541: Analog signal terminal adapter, simplifies wiring between modules and on-site sensors.
CM578: ROFINET communication module, realizing high-speed data transmission between HAI805 and SCADA system.

Installation and maintenance:
Considerations before installation:
Use shielded twisted pair cables to transmit analog input signals to reduce electromagnetic interference (EMI) and terminate the shielding layer at a single grounding point in the control cabinet.
For thermocouple/RTD inputs, ensure proper grounding and use dedicated extension cables to avoid signal attenuation.
Before powering on the system, configure the signal type and scaling ratio for each channel through the manufacturer’s software (such as Freelance Engineering Tool).
Maintenance suggestion:
Monthly visual inspection: Verify the LED status indicator light and check for loose connections in the terminal block, especially in high vibration environments such as conveyor belts.
Quarterly calibration: Use precision signal generators to verify the accuracy of critical channels (such as safety related temperature measurements) and record the results for compliance audits.
Annual firmware update: Deploy the latest firmware to access improved filtering algorithms or new sensor types, first testing the update in a simulated environment.
Corrosion environment inspection: In corrosive environments such as coastal factories, inspect the terminal blocks for corrosion and apply protective coatings if necessary.
