GE WESDAC D20ME 18-MAR-13 High Performance Power System Automation Control Equipment

Description

GE WESDAC D20ME 18-MAR-13 is a high-performance power system automation control equipment and an important member of GE’s WESDAC series. It occupies a core position in the power automation control system, undertaking key tasks such as data acquisition, processing, analysis, and instruction issuance. By connecting with various sensors, circuit breakers, transformers and other power equipment, the device can obtain real-time operating status information of the power system and transmit this information to the higher-level control system for comprehensive analysis.

WESDAC D20ME 18-MAR-13

For power engineers and system integrators, the value of GE WESDAC D20ME 18-MAR-13lies in its high reliability and strong adaptability. It can seamlessly integrate into power systems of different scales and complexities, providing stable and efficient automation control support for the upgrading and transformation of traditional power grids and the deployment of new smart grid projects, significantly reducing the difficulty of system construction and operation.

WESDAC D20ME 18-MAR-13

Main features and advantages:
In terms of functionality, it has ultra high speed data processing capability, which can complete the collection and analysis of a large amount of power data in milliseconds, quickly respond to changes in the state of the power system, adjust control strategies in a timely manner, and ensure the stable operation of the power system. Its stability has been rigorously tested and verified through practical applications, and it can continue to work reliably even in the event of sudden faults such as short circuits or lightning strikes in the power grid, thereby reducing the probability of system failures. In terms of hardware design, the device adopts a sturdy and durable shell material, which has good resistance to electromagnetic interference and moisture and dust, and can adapt to harsh electrical working environments. The installation methods are flexible and diverse, with the option of cabinet installation or wall mounted installation, making it easy to integrate into different power control environments. In terms of compatibility, GE WESDAC D20ME 18-MAR-13supports multiple power industry standard communication protocols, such as IEC 61850, which facilitates data exchange and collaborative work with other power equipment and systems. In terms of long-term reliability, its optimized heat dissipation design and low-power circuit architecture effectively extend the service life of the equipment and reduce maintenance costs.

WESDAC D20ME 18-MAR-13

Technical specifications:
Model WESDAC D20ME 18-MAR-13
Brand GE
Type of power system automation control equipment
Power supply 110-220 V AC
Working temperature -10 ° C to 50 ° C
Installation methods: Cabinet style installation, wall mounted installation
Ethernet interface RS – 485、RS – 232
Certified in accordance with IEEE standards and CE certification
Cooling method: forced air cooling
Protection level IP45

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

WESDAC D20ME 18-MAR-13

Application areas:
In large power plants, precise power distribution and real-time monitoring are crucial for both steam turbine control in thermal power plants and turbine regulation in hydroelectric power plants. This device can collect various key data of the power grid in real time, such as voltage, current, and frequency, to help engineers detect and deal with potential power fluctuations in a timely manner, thereby ensuring the stability and reliability of power supply. In the dispatch center of the urban power grid, GE WESDAC D20ME 18-MAR-13 plays a central nervous system role, coordinating power transmission in different regions, allocating loads reasonably, and effectively preventing power outages caused by local overload. In addition, in the construction process of the smart grid, it relies on its powerful data processing and communication capabilities to collaborate with distributed energy resources and smart meters, promoting the development of the power system towards a more intelligent and efficient direction.

WESDAC D20ME 18-MAR-13

Related products:
The GE WESDAC D10ME has relatively simplified functions and is suitable for small power systems or cost sensitive projects.
The GE WESDAC D30ME has significantly improved data processing capabilities and the number of communication interfaces, making it suitable for large and complex power systems.
GE WESDAC C10 is a matching communication expansion module that enhances the network communication capabilities of GE WESDAC D20ME 18-MAR-13 and supports connecting more devices.
GE WESDAC A10 is an analog input expansion module that can increase the number of data acquisition channels for equipment and meet more complex power parameter monitoring needs.
GE WESDAC R10 is a digital output expansion module that can be used in conjunction with GE WESDAC D20ME 18-MAR-13 to achieve remote control of more power equipment.

Installation and maintenance:
Before installing GE WESDAC D20ME 18-MAR-13, it is necessary to plan the installation location in advance. Ensure good ventilation in the installation space for equipment heat dissipation, and stay away from strong electromagnetic interference sources such as large motors and transformers to avoid affecting the normal operation of the equipment. During installation, it is necessary to strictly follow the electrical wiring specifications to ensure that the power wiring is correct and secure, and that the grounding resistance meets the standard requirements, in order to prevent equipment failure or safety accidents caused by electrical connection problems.

In terms of maintenance, it is recommended to conduct a visual inspection of the equipment once a month to check for any obvious physical damage or loose wiring. Conduct a comprehensive data accuracy verification every quarter, comparing actual power parameters with equipment collected data to ensure the reliability of data collection. In addition, it is necessary to pay timely attention to the equipment software update information released by GE, regularly upgrade the equipment firmware to obtain the latest functional optimization and security protection, and ensure that the equipment is always in the best operating state.
