GE VMIVME1150 64 bit optically coupled digital input board

Description

GE VMIVME1150 is a 64 bit optically coupled digital input board designed and optimized for VME (Versa Module Europa) bus systems. As part of GE’s extensive industrial control product portfolio, it plays a critical role in achieving efficient data transmission and control in industrial automation settings.

VMIVME1150

Main features and advantages:
From a functional perspective, GE VMIVME1150 serves as a bridge between on-site equipment and advanced control systems. It is designed to receive digital input signals from various sources such as sensors, switches, and other digital devices. These signals are optically isolated and processed before being transmitted to the VME bus for further processing by the control system. The optical isolation function is particularly important because it provides a high level of electrical noise and interference protection, ensuring the integrity of the input signal.

In terms of system compatibility, GE VMIVME1150 has a high degree of versatility. It fully complies with the electrical and mechanical specifications of the VME bus standard. This means that it can be easily integrated into existing VME systems, whether it’s simple single board setup or complex multi module industrial control architectures. For engineers and integrators, this compatibility simplifies the process of system design and expansion. They can trust GE VMIVME1150 to seamlessly collaborate with other VME compatible components, reducing development time and the risks that may arise from integrating new hardware.

The continuous isolation voltage is 1000 V, and the pulse isolation voltage is 7500 V, providing excellent protection against electrical noise and interference. In industrial environments, electrical equipment generates a large amount of electromagnetic interference, and this high isolation characteristic ensures that the digital input signals received by the module remain clear and accurate. For example, in factories filled with large motors, power inverters, and other noisy electrical equipment, the GE VMIVME1150 can still accurately detect and process input signals from sensors without being affected by surrounding electrical noise. This not only improves the reliability of the control system, but also reduces the possibility of misreading and system failures.

This module provides a flexible and cost-effective 8-byte digital input port. This allows multiple digital devices to be connected simultaneously, providing a high-density input solution. In manufacturing plants that require monitoring a large number of sensors and switches, GE VMIVME1150 can efficiently process all of these input signals without the need for multiple smaller capacity input modules. This not only simplifies system design, but also reduces overall hardware costs.

VMIVME1150

Technical specifications:
Model GE VMIVME1150
Manufacturer GE
Product Type: 64 bit Optical Coupled Digital Input Board
Isolation voltage continuous: 1000 V; pulse: 7500 V
Input port: 8-byte numeric input port
Bus compatibility VME (Versa Module Europa) bus
Address modification bit supports short supervision or non privileged short I/O access
DTACK response to data gating (DS0 or DS1) and decoding board address
Board size standard double height printed circuit board
Working temperature -40 ° C to+85 ° C
Storage temperature -55 ° C to+125 ° C

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

VMIVME1150

Application areas:
In the field of industrial automation, accuracy and speed are crucial, and GE VMIVME1150 is commonly used in manufacturing plants. Taking a large automobile assembly line as an example, it serves as an important component of the control system, responsible for coordinating the operation of robotic arms, conveyors, and other automation equipment. By accurately processing and transmitting digital input signals, it can achieve precise synchronization of these different elements. For example, it can detect the position of car bodies on conveyor belts and send signals to robotic arms to ensure that they install components with extremely high precision. This not only improves the quality of assembled vehicles, but also significantly enhances production efficiency.

The power generation industry is also highly dependent on GEVMIVME1150. In power plants, whether coal-fired, gas-fired, or hydroelectric, there are numerous sensors and control devices in operation. This module interfaces with these components to monitor key parameters such as temperature, pressure, and voltage. In gas-fired power plants, it can receive digital input signals from sensors that monitor gas flow and combustion chamber temperature. Based on this data, it can help control the operation of turbines and generators, ensure optimal power generation efficiency, and reduce the risk of equipment failure.

Even in military and aerospace applications that require extremely high reliability and resilience, GE VMIVME1150 can find its place. In military vehicles, it can be used to manage communication systems, control the operation of various subsystems, and process data from sensors that detect threats or environmental conditions. In the aerospace field, during the testing and operation of aircraft, it can handle complex data acquisition and control tasks, withstand common environmental conditions such as extreme vibration, temperature changes, and electromagnetic interference.

VMIVME1150

Related products:
GE VMIVME1120: Suitable for applications with relatively few digital input sources, such as small laboratory setups or simple automated test benches.
GE VME – I/O Expansion Chassis: This chassis can be used in conjunction with GE VMIVME1150 to expand the overall I/O capabilities of the system. It provides additional slots for installing other VME compatible modules, allowing for the integration of more digital input or output boards, as well as other types of modules such as analog input/output boards.

VMIVME1150

Installation and maintenance:
Before installing GE VMIVME1150, it is necessary to ensure that the VME bus system is properly prepared. Check the VME chassis to confirm that there are available slots and that its mechanical and electrical specifications meet the requirements of the module. Ensure that the chassis is powered off during installation to avoid any electrical hazards.

When handling GE VMIVME1150, it is essential to use appropriate ESD (electrostatic discharge) protection measures. Static electricity may damage sensitive components on the module. Wear an ESD grounding wristband and work on an ESD protective surface. Carefully align the module with the VME slot and gently insert it, ensuring it is fully seated and the connector is properly engaged. Do not apply excessive force during installation to avoid damaging the module or VME slot.

For maintenance, it is recommended to conduct a visual inspection at least once a month. Check for any physical signs of damage to the module, such as cracked casing, bent pins, or loose components. Check if the connection is secure and free from corrosion. If any problems are found, please handle them immediately.
