GE VMIVME-7452 is a 6U single slot VMEbus module. It serves as a storage component in the GE embedded VMEbus processor system. This module is designed as a passive board that obtains power from standard VMEbus P1 and P2 connectors. It is equipped with a floppy drive and a hard drive, and can also be optionally equipped with a flash drive, increasing flexibility.
GE VMIVME-7452
In the architecture of the control system, it seamlessly interfaces with a series of VMEbus compatible PC/AT single board computer (SBC) boards from VMIC. These SBC boards come with onboard floppy drives and IDE controllers, and the GEVMIVME-7452 has been carefully designed to work in conjunction with them. For engineers and system integrators, this module simplifies the storage implementation in complex industrial control settings. They can rely on GE VMIVME-7452 to provide a unified storage solution in VMEbus based systems without the need to piece together multiple storage components and interfaces. Its ability to support hard and floppy disk storage, as well as optional flash drives, makes it an ideal choice for meeting different data storage and access needs in industrial and embedded applications.
GE VMIVME-7452
Main features and advantages:
Functionally speaking, GE VMIVME-7452 provides great flexibility. It can be configured to use only floppy drives, only hard drives, or both simultaneously. This allows for a wide range of data storage and transmission scenarios. For example, in legacy systems that still rely on floppy disks for data transfer or applications that use hard disks for long-term, high-capacity data storage, this module can meet these diverse needs.
In terms of hardware design, its 6U single slot VMEbus external dimensions make it a compact and space saving solution in control cabinets. It is a passive board, which means it does not generate too much heat and helps improve the overall thermal stability of the system. This module is designed to be sturdy and capable of withstanding common vibrations and temperature changes in industrial environments. This ensures its reliable operation over a long period of time.
Compatibility is a major advantage of this module. It seamlessly interfaces with VMIC’s VMEbus compatible PC/AT SBC board and supports multiple operating systems, including Windows, Linux, and VxWorks. This broad compatibility enables engineers to more easily integrate GE VMIVME-7452 into existing systems without the need for large-scale modifications. This module can be relatively easily integrated into both older Windows based industrial control systems and new Linux based embedded applications.
In terms of long-term reliability, the design of this module ensures stable power supply from the VMEbus P1 and P2 connectors. This stable power supply, combined with its sturdy structure, gives it a longer service life. In industrial applications, downtime can be costly, and the long-term stable operation of GE VMIVME-7452 is a significant advantage, reducing the need for frequent replacement and maintenance.
GE VMIVME-7452
Technical specifications:
Model VMIVME-7452
Brand GE
Type VMEbus storage module
The power supply obtains power from the standard VMEbus P1 and P2 connectors
Installation method: single slot, designed for installation in VMEbus systems with 6U external dimensions
Size standard VME dual height European card (one slot): 160 x 233.25 x 20.32 millimeters
User connector 34 pin for floppy drive, 40 pin for IDE
The drive supports one floppy drive and one hard drive (optional flash drive)
Compatibility with VMIC’s VMEbus compatible PC/AT SBC board interface, supporting Windows, Linux, VxWorks operating systems
Passive board type
Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com
GE VMIVME-7452
Application areas:
Reliable and high-performance storage is crucial in manufacturing factories. Consider an automobile manufacturing production line that requires real-time storage and retrieval of a large amount of data related to production processes, quality control indicators, and equipment status. GE VMIVME-7452 becomes an ideal solution, providing hard disk and floppy disk storage options for embedded VMEbus processors in factory control systems. This ensures that the production line can run smoothly without any bottlenecks related to data.
In the field of energy, such as thermal power plants or solar power plants, it is necessary to securely store data from sensors that monitor various parameters such as temperature, pressure, and power output. GEVMIVME-7452 is capable of implementing this storage function, allowing operators to analyze historical data for predictive maintenance and optimize power generation processes. This module is also widely used in medical imaging equipment. In the radiology department of hospitals, a stable and fast storage solution is required for the large amount of image data generated by MRI or CT scanners. GE VMIVME-7452perfectly meets this requirement, ensuring secure storage of patient data and quick retrieval for accurate diagnosis. In addition, in telecommunications infrastructure, network management and customer data processing require large-scale data storage and retrieval, and this module has proven its value in industrial control and embedded applications.
GE VMIVME-7452
Related products:
VMIVME-7455: This module also belongs to the VMEbus product line. Compared to GE VMIVME-7452, it may have different storage capacities or interface options, but they can be used in the same VMEbus based system. For example, in large industrial control networks, VMIVME-7455 can be used for high-speed data storage, while GE VMIVME-7452 handles more general storage requirements.
VMIC VMIVME-3114: It is a VMEbus compatible module that can work in conjunction with GE VMIVME-7452. Although GE VMIVME-7452 focuses on storage, VMIC VMIVMME-3114 may handle data processing or input/output functions related to data stored on GE VMIVMME-7452.
GE FANUC VMIVME-1182: This VMEbus card can be integrated into systems that include GE VMIVME-7452. It may help improve the overall processing capability of the system, as data stored on GE VMIVME-7452 can be accessed and processed by GE FANUC VMIVMME-1182.
VMIVME-5565: It provides a high-speed, low latency, deterministic interface. In complex industrial control systems, VMIVME-5565 can be used for time critical data transfer related to data stored on GE VMIVME-7452, ensuring that stored data can be quickly retrieved and used when needed.
VMIMB1-5576: This module can interface with GE VMIVME-7452 to enhance the overall functionality of data storage and transmission networks. It may provide additional communication channels or data management capabilities for data stored on GE VMIVME-7452.
GE VMIVME-7452
Installation and maintenance:
Before installing GE VMIVME-7452 , the integrator should first ensure that the VMEbus system has appropriate slots and the correct power supply capability. As it is a 6U single slot module, please ensure that there is sufficient vertical space in the control cabinet. In addition, please check the compatibility between the existing VMEbus compatible PC/AT SBC board and GE VMIVME-7452 . The correct grounding module is crucial for preventing electrical interference and ensuring stable operation.
For maintenance, it is recommended to conduct regular visual inspections. Check for any signs of loose connections at the 34 pin floppy drive and 40 pin IDE connectors. Check for any signs of physical damage to the module or its built-in drivers. If an optional flash drive is installed, please also check its connection. It is a good habit to regularly check the integrity of data stored on hard drives and floppy disks. Appropriate data integrity checking software can be used to complete this operation. If any problems arise, GE provides detailed technical documentation that can be used for troubleshooting.
