GE VMIAC-5595-208 350-8055955-208N is a high-precision vibration monitoring module and an important component of GE’s VMIC (Vibration Monitoring and Instrument Control) platform. It serves as a key link between on-site vibration sensors and advanced control systems in industrial automation settings.
VMIACC-5595-208 350-805595-2008N
Main features and advantages:
In terms of functionality, it serves as the center for collecting and analyzing vibration related data. It interfaces with various sensors such as proximity probes, accelerometers, and velocity sensors. Once the raw vibration data is collected, the microprocessor built into the module starts working. It uses advanced signal processing techniques such as Fourier transform and envelope analysis to transform raw data into meaningful insights. Then, these insights are used to identify any abnormal situations in the frequency domain that may indicate potential mechanical faults in the monitored equipment.
In terms of system compatibility, GE VMIAC-5595-208 350-8055955-208N has a high degree of versatility. It seamlessly integrates with GE’s iFix SCADA system, making it easy to incorporate into the existing plant wide control architecture. This integration enables operators to view and analyze vibration data in the context of other process variables, thereby gaining a more comprehensive understanding of the overall health status of the system. For engineers and integrators, the ability of this module to work in a larger ecosystem is a significant advantage. It simplifies the process of building or upgrading vibration monitoring systems, reducing the need for complex customized solutions. Therefore, GE VMIAC-5595-208 350-8055955-208N plays a key role in improving the reliability and performance of industrial machinery by providing accurate and timely vibration monitoring capabilities.
One of its main advantages is its multi-channel monitoring capability. It can support up to eight independent vibration channels, each of which can be configured to measure different vibration parameters such as velocity, acceleration, or displacement. This flexibility enables comprehensive analysis of complex machinery. For example, in large industrial turbines with multiple bearings, each bearing can be monitored on a separate channel to gain a detailed understanding of the mechanical condition of the turbine.
In terms of diagnostic tools, this module is equipped with advanced algorithms for real-time vibration analysis. It calculates parameters such as spectral density, peak factor, and kurtosis. These calculations help identify early signs of mechanical degradation. For example, an increase in kurtosis value may indicate a defect in the rolling element bearing. By detecting such issues in the early stages, proactive maintenance can be arranged to prevent catastrophic failures and reduce maintenance costs.
The hardware design of GE VMIAC-5595-208 350-8055955-208N is designed to withstand harsh environments. Its shell protection level is IP65, with dustproof and waterproof functions. The circuit is protected by a conformal coating to prevent corrosive substances from corroding. This makes it suitable for environments such as offshore platforms, refineries, and chemical plants. In addition, its wide operating temperature range of -20 ° C to+70 ° C ensures reliable performance under extreme weather conditions, whether in the cold winter of northern power plants or the hot summer of desert oil fields.
Compatibility is another advantageous area of this module. It can not only integrate with a range of industrial software from GE, but also integrate with third-party systems through open protocols such as Modbus and Ethernet/IP. This interoperability allows seamless data aggregation from multiple sources. It also supports remote monitoring through a human-machine interface (HMI) or cloud based platform, allowing operators to monitor the health status of machinery from anywhere in the world.
Finally, the module provides user configurable alarm functions. Operators can set independent alarm thresholds for each channel, including warning and danger levels. When these thresholds are exceeded, the relay output can trigger an automatic response, such as shutting down the device or issuing an alarm. This feature helps to minimize the risk of catastrophic failures by ensuring that any abnormal vibration levels are promptly addressed.
VMIACC-5595-208 350-805595-2008N
Technical specifications:
Model GE VMIAC-5595-208 350-8055955-208N
Manufacturer GE
Product Type: Vibration Monitoring Module
8 analog input channels (for vibration sensors)
Input signal range speed: 0-100 mm/s rms; Acceleration: 0-10 g; Displacement: 0-250 μ m pk pk pk
Frequency range 0.5 Hz to 10 kHz
Output 4-20 mA analog output RS – 485（Modbus RTU）、 Ethernet (TCP/IP)
Power supply 100-240 V AC (50/60 Hz) or 24 V DC
Physical dimensions 229 mm (height) x 178 mm (width) x 102 mm (depth)
Weight 1.8 kg
Working temperature -20 ° C to+70 ° C
Installation method: DIN rail installation or panel installation
Certified CE, UL, API 670, ISO 10816
Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com
VMIACC-5595-208 350-805595-2008N
Application areas:
Taking a large power plant as an example, the turbines inside operate at high speeds and under extreme conditions. Even the slightest mechanical problem can lead to major power outages, causing thousands of dollars in production losses and emergency maintenance costs for power plants. The GE VMIAC-5595-208 350-8055955-208N vibration monitoring module can play a critical role. By continuously monitoring the vibration parameters of the turbine, it can detect early signs of issues such as imbalance, misalignment, or bearing wear. This early detection enables power plant operators to schedule maintenance during planned shutdowns, avoiding costly unplanned shutdowns.
In the oil and gas industry, offshore platforms are exposed to harsh environmental conditions, including high humidity, salty air, and strong vibrations. GE VMIAC-5595-208 350-8055955-208N is designed to withstand these conditions while accurately monitoring the operating status of compressors and pumps. It is capable of real-time analysis of vibration data, which is crucial for maintaining the integrity of production processes in remote and challenging environments.
Manufacturing factories with complex assembly lines and high-speed mechanical equipment can also benefit greatly from this module. For example, in an automotive manufacturing plant, GE VMIAC-5595-208 350-8055955-208N can monitor the vibration of robotic arms and conveyor belts. By ensuring the smooth operation of these components, it helps to maintain product quality and production efficiency. Essentially, GEVMIAC-5595-208 350-8055955-208N is an important tool for industries that rely on high-value rotating assets to maintain efficient and low-cost operations.
Related products:
GE VMIAC-5590: With fewer channels, it is suitable for small-scale applications with lower mechanical complexity, such as small manufacturing workshops with only a few critical rotating components.
GE VMIAC-5595-208J: Suitable for applications that require real-time analysis of extremely complex vibration modes, such as high-speed aerospace manufacturing machinery.
GE Proficy Predictive Analysis Suite: Used in conjunction with GE VMIAC-5595-208 350-8055955-208N, it provides in-depth data analysis and predictive maintenance capabilities. It can utilize the vibration data of modules and use advanced algorithms to more accurately predict equipment failures.
Installation and maintenance:
It is crucial to carefully consider the installation environment before installing GE VMIAC-5595-208 350-8055955-208N. For DIN rail installation, ensure that the rail is securely installed and there is sufficient space around it. It is recommended to leave a gap of at least 50 mm on all sides to promote proper ventilation and prevent heat accumulation, especially in situations where some heat may be generated during module operation. When installing with a panel, ensure that the panel has sufficient thickness and stiffness to support the module without causing any vibrations that may interfere with its accurate readings.
It is crucial to strictly follow the wiring diagram provided in the installation manual for electrical connections. The correct grounding module is essential. Connect the grounding terminal of the module to a dedicated and reliable grounding point using wires of appropriate specifications. This helps to protect the module from the impact of power surges and reduce electromagnetic interference, which may otherwise affect the accuracy of vibration data.
For maintenance, a regular visual inspection should be conducted at least once every quarter. Check for any physical signs of damage to the casing, such as cracks or dents. Meanwhile, check if the connection is secure and free from corrosion. It is recommended to run diagnostic tests using GE approved software every six months. This test can check the integrity of the internal components of the module, verify the accuracy of the connected sensors, and ensure that the signal processing algorithm is working properly. The firmware update provided by GE should be installed as soon as possible. However, before installing any updates, it is important to back up all configuration settings to avoid losing any critical data. These updates typically bring performance improvements, new diagnostic features, and enhanced compatibility with other system components.
