GE V7768-320001 is a high-performance VMEbus single board computer. It is designed as a central processing unit in industrial control systems, aerospace electronic equipment, and telecommunications networks. As part of GE’s extensive portfolio of industrial and embedded computing solutions, it aims to provide top-notch computing power in a compact and reliable package.
V7768-320001
This single board computer is based on an Intel Core 2 dual core processor, with a maximum operating speed of 2.16 GHz. This high-speed processing capability enables it to handle multiple tasks simultaneously, whether running complex control algorithms in industrial automation systems or processing large amounts of sensor data in aerospace applications. It is equipped with up to 2 Gbyte of DDR2 SDRAM through a single SODIMM slot, ensuring fast data access and smooth multitasking.
V7768-320001
Main features and advantages:
In terms of performance, the GE V7768-320001 can be considered powerful. The Intel Core 2 dual core processor’s clock speed of up to 2.16 GHz enables it to execute complex algorithms and process large amounts of data in a short amount of time. This is particularly beneficial in applications where real-time response is crucial, such as in industrial control systems where instantaneous decisions can prevent equipment damage or product defects. The 2 Gbyte DDR2 SDRAM further enhances its performance and reduces data processing latency by providing fast data storage and retrieval.
In terms of hardware design, the motherboard is durable and long-lasting. It adopts a compact external size, suitable for installation in small spaces, which is common in industrial control cabinets and aircraft avionics cabins. The use of high-quality components ensures its durability and can withstand harsh environmental conditions, including temperature changes, vibrations, and electromagnetic interference. The aluminum alloy casing not only protects the internal components, but also helps with heat dissipation, ensuring stable operation even under heavy load conditions.
Compatibility is one of its advantages. With the Intel 945GME Express chipset, it offers a wide range of I/O options. It has dual Gigabit Ethernet ports, making it ideal for high-speed network communication, whether for transmitting data between different parts of industrial networks or for connecting to telecommunications backbone networks. There are also two serial ports, four USB 2.0 ports, and two SATA interfaces, making it easy to connect various external devices. It also supports connecting keyboards and mice through the PS/2 interface on the front panel. This extensive interface enables it to be easily integrated into existing systems without the need for complex and expensive adapters.
Long term reliability is also one of its key characteristics. The GEV7768-320001 has undergone rigorous testing to ensure its ability to operate continuously in harsh environments. It has built-in diagnostic functions that can detect and report any potential issues for proactive maintenance. The software updates provided by GE ensure that the motherboard can keep up with the latest technological advancements and improve its performance and security over time.
V7768-320001
Technical specifications:
Model GE V7768-320001
Brand GE
Manufacturer GE
Type VMEbus Single Board Computer
Processor Intel Core 2 Duo, up to 2.16 GHz
Memory equipped with up to 2 Gbyte DDR2 SDRAM via a single SODIMM slot
Secondary cache up to 4 Mbyte
System and memory bus 667 MHz
Compact flash memory with bootable storage capacity of up to 8 Gbyte
PMC expansion slot 1 PCI-X PMC slot, 3 additional PMC expansion slots
Two Gigabit Ethernet ports on the front panel of the Ethernet port
2 serial ports
USB ports 4 USB 2.0 ports
2 SATA interfaces
Front panel interface PS/2 interface keyboard/mouse SVGA
Supported operating systems Windows ® XP、VxWorks ®、 Linux ®
Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com
V7768-320001
Application areas:
In the field of industrial automation, factories rely on this component to control complex production lines. For example, in an automobile manufacturing factory, it can manage real-time data transmitted by countless sensors on the assembly line. It can process information related to the position of the robotic arm, welding quality, and conveyor belt speed. By processing this data at high speed, we ensure a smooth, efficient, and error free production process. In power generation facilities, GE V7768-320001 is used for monitoring and controlling turbines. It is capable of real-time analysis of data from temperature, pressure, and vibration sensors, adjusting the operation of turbines to optimize energy production and prevent potential failures.
In the aerospace industry, reliability and high-speed data processing capabilities are indispensable, and this product plays a crucial role in it. It can be applied to aircraft avionics systems, undertaking tasks such as flight control calculations, navigation data processing, and communication with ground control. In the telecommunications field, it helps manage network traffic, efficiently route data packets, and ensure stable connections between wired and wireless communication networks. It can be integrated into existing systems and handle complex computing tasks, making it an indispensable part in harsh environments and critical task systems.
V7768-320001
Related products:
GE V7768-330000- This module is designed to expand the I/O capabilities of the GE V7768-320001 system. It can be added to increase the number of digital and analog input/output channels, suitable for applications that require more sensor and actuator connections, such as large industrial automation plants.
PMC237CM1/V PMC expansion board – connected to GE V7768-320001 through board to board connectors. It provides additional customer customized I/O functionality, enhancing users’ customization options. This is very beneficial for special applications where standardized I/O configurations cannot meet the requirements.
GE 90-30 series PLC module – can be integrated with GE V7768-320001 in industrial control systems. The PLC module is responsible for logic control, while the GE V7768-320001 is responsible for high-performance computing and data processing, creating a more comprehensive and efficient control solution.
GE IC697MDL655 digital input module – works in conjunction with GE V7768-320001 in industrial automation settings. It provides digital input functionality, allowing the system to receive signals from switches, sensors, and other digital devices, which are then further processed by GE V7768-320001.
GE IC697ACC700 AC Power Module – Provides power to GE V7768-320001 and other components in the system. It ensures a stable and reliable power supply, which is crucial for the normal operation of high-performance computing boards, especially in industrial environments where power fluctuations may occur.
GE IC697BEM731 Ethernet Communication Module – Provides high-speed network communication for GE V7768-320001. It can be used to connect systems to industrial networks, enabling data transmission between other devices such as servers, human-machine interfaces (HMI), or other control systems.
GE V7768-320002- Related models within the same series may have some differences in configuration or performance. In applications that require high availability, such as aerospace or mission critical industrial applications, it can be used as a substitute or for redundancy purposes.
Installation and maintenance:
Before installing GE V7768-320001, it is necessary to ensure that the installation environment meets certain requirements. The control cabinet or installation location should be well ventilated to prevent overheating, as the motherboard may generate heat during operation, especially under heavy load conditions. There should be sufficient space around the motherboard for easy operation during maintenance and to ensure proper air circulation. The installation surface should be flat and stable to prevent vibration, as vibration may damage internal components over time.
In terms of maintenance, it is recommended to conduct regular visual inspections. Check for any signs of physical damage, such as bent pins, broken components, or loose connections. These issues can usually be detected early through visual inspection to prevent more serious problems from arising. Regular software updates provided by GE should be installed to maintain motherboard performance optimization and address any security vulnerabilities. In addition, running diagnostic tests using built-in diagnostic tools can help identify any potential hardware or software issues. If any issues are detected, you can contact GE’s technical support for further assistance. If the motherboard has hot swappable functionality (if any), it should be utilized during maintenance to minimize system downtime. This allows for the replacement of the motherboard without shutting down the entire system, ensuring continuous operation.
