GE SR760 Panel 1219-0003 High Performance Industrial Control Panel

Description

GE SR760 Panel 1219-0003 is a high-performance industrial control panel designed to be the core of any control system. It is a member of GE’s renowned SR760 series, known for its reliability and advanced features in industrial applications.

SR760 Panel 1219-0003

This panel serves as a human-machine interface (HMI), allowing operators to interact with industrial processes. It has a clear and sharp display screen that can be easily read even in bright or dim environments. This panel is designed for seamless integration with various control systems, including GE’s own programmable logic controller (PLC) and systems from other major manufacturers. In the architecture of the control system, it is located on the end facing the operator, receiving data from the control layer and presenting it in a user-friendly manner. It also allows operators to send commands to the control system, such as adjusting setpoints or initiating emergency shutdowns.

SR760 Panel 1219-0003

Main features and advantages:
In terms of functional performance, its high-speed processor ensures fast response time and can update display data in real-time even when processing large amounts of information. This is crucial in applications that require quick decision-making, such as high-speed manufacturing processes. The panel also has excellent stability, with built-in error handling mechanisms to prevent malfunctions and ensure continuous operation.

In terms of hardware, it is sturdy and durable. A sturdy casing can protect internal components from dust, moisture, and vibration, making it suitable for harsh industrial environments. Its size has been optimized for easy installation in the control cabinet without taking up too much space. The installation method is flexible, supporting two options: panel installation and wall mounted installation, providing convenience for installation personnel in different settings.

Compatibility is one of its advantages. It supports multiple industrial communication protocols such as Modbus, Profibus, and Ethernet/IP. This means that it can be smoothly integrated with other systems in the factory, whether it is traditional equipment or the latest smart sensors. In terms of long-term reliability, this panel has efficient thermal management. The display screen has a long service life and can maintain clarity and color accuracy during years of continuous use. This reduces the need for frequent replacement, thereby lowering maintenance costs and improving the overall availability of the system.

SR760 Panel 1219-0003

Technical specifications:

Model GESR760 Panel 1219-0003
Brand GE
Type: Industrial Control Panel
Power supply 24V DC (± 10% tolerance)
Working temperature -20 ° C to+60 ° C
Installation method: Panel installation (compatible with standard 19 inch rack) and wall mounting options
Dimensions: Width: 300mm, Height: 200mm, Depth: 50mm
Weight 2kg
Interface 2 Ethernet ports, 4 RS-485 ports, 2 USB ports
Certification of CE, UL, and other related industrial certifications
Display screen type: high contrast LCD
Display screen resolution 800×600 pixels
Environmental grade IP54 (dustproof, splash proof)

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

SR760 Panel 1219-0003

Related products:
GE SR760 Panel 1219-0004- Similar to 1219-0003, but with a larger display size, suitable for applications that require more information to be presented at a glance.
GE SR760 Controller Module 2345-0001- Used in conjunction with SR760 Panel 1219-0003, it provides additional control functionality and processing capabilities for more complex industrial processes.
GE Communication Gateway 5678-0002- Connect SR760 Panel 1219-0003 to other non-standard industrial networks to expand its compatibility in diverse settings.
GE Input/Output Expansion Module 9876-0003- allows for an increase in the number of input and output channels for SR760 Panel 1219-0003, which is very useful when connecting more sensors and actuators.
GE Power Backup Module 3456-0001- Ensuring continuous operation of SR760 Panel 1219-0003 during power outages is crucial for applications that require uninterrupted control.
GE Display Enhancement Kit 7890-0002- can be added to SR760 Panel 1219-0003 to improve display brightness and contrast in high ambient light conditions.

Installation and maintenance:
Before installation, ensure that the control cabinet has sufficient space to accommodate GE SR760 Panel 1219-0003. The cabinet should be well ventilated to prevent overheating, as like any electronic device, this panel generates a certain amount of heat during operation. Grounding is crucial. Connect the grounding terminal of the panel to a reliable grounding terminal using a suitable grounding cable. This not only protects the panel from the impact of power surges, but also ensures the safety of operators. Leave at least 10mm gap around the panel for future maintenance operations and ensure proper air circulation.

For maintenance, arrange a visual inspection once a month. Check for any signs of physical damage, such as cracked casing or loose connectors. Perform signal diagnostic testing every three months using software provided by GE. This test can identify any issues with input/output signals, ensuring that the panel accurately receives and sends data. GE will regularly release firmware updates. These updates typically include bug fixes, security enhancements, and new features. Plan to update the firmware at least once a year, preferably during the scheduled maintenance window, to minimize potential disruptions to operations.
