GE SLN042 IC086SLN042-A is a high-performance digital output module and an important component of the GE Series 90-30/90-70 PLC platform. As a digital output module, its main function is to receive digital signals from the PLC logic controller and convert them into physical actions on site.
SLN042 IC086SLN042-A
It is an important bridge between the control system and the on-site equipment. In a typical industrial control system architecture, PLC processes data from sensors and makes decisions based on pre programmed logic. GE SLN042 IC086SLN042-A executes these decisions by controlling devices such as motors, valves, and indicator lights.
SLN042 IC086SLN042-A
Main features and advantages:
It can drive inductive or resistive loads to meet the power requirements of various industrial equipment. Its 16 isolated output channels can operate independently, providing high-density output control. This is particularly useful in compact control panels with limited space, as it can integrate more control functions in a smaller area.
In terms of hardware design, this module is durable and long-lasting. Its sturdy structure, including a metal reinforced casing and conformal coating circuit, can withstand the harsh tests of industrial environments. It can operate at extreme temperatures ranging from -40 ° C to+85 ° C and is suitable for various environments such as cold storage and high-temperature processing plants. This module also has high anti vibration (3 g rms) and anti impact (15 g peak) capabilities, ensuring normal operation even when the equipment is subjected to mechanical stress (such as applications in mobile machinery).
Compatibility is another advantage of GE SLN042 IC086SLN042-A . It supports multiple load voltages, including 24 V DC and 120 V AC. This universal voltage compatibility eliminates the need for multiple modules in hybrid voltage systems, simplifying inventory management and system design. It also has electrical isolation (2.5 kV AC) between the channel and the controller, which can prevent voltage surges and grounding circuits, ensuring signal integrity in high noise environments.
The design of this module ensures long-term reliability. The LED status indicator lights of each channel provide real-time feedback on the output status. This enables operators to quickly identify any operational issues, such as unactivated outputs or circuit faults. In addition, the module also supports fault reporting through PLC, which can be seamlessly integrated with the monitoring system to achieve proactive maintenance and reduce unexpected downtime.
SLN042 IC086SLN042-A
Technical specifications:
Model SLN042 IC086SLN042-A
Manufacturer GE
Product Type: Digital Output Module
Platform Series 90-30/90-70 PLC
16 isolated output channels
Output type relay (SPDT), 2 A per channel
Voltage rating 24 V DC/120 V AC
Electrical isolation between isolation channel and logic (2.5 kV AC)
Physical dimensions: 101.6 mm (height) x 152.4 mm (width) x 76.2 mm (depth)
Weight 0.9 kg
Working temperature -40 ° C to+85 ° C
Installation method: DIN rail installation or rack installation
Certified CE, UL 508, IEC 61131-2
Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com
SLN042 IC086SLN042-A
Application areas:
This module plays a crucial role in manufacturing factories, especially those involved in automobile production. It controls various actuators on the wiring, such as a robotic arm for precise placement of components. For example, when installing a car dashboard, GE SLN042 IC086SLN042-A ensures that the robotic arm can move with millisecond level accuracy, receive digital commands from the control system and convert them into physical actions, thereby accurately picking up and installing dashboard components. This not only accelerates the production process, but also significantly reduces the error rate, thereby improving product quality.
Power generation facilities are also highly dependent on GE SLN042 IC086SLN042-A. It is responsible for managing critical equipment such as motor starters and circuit breakers. In thermal power plants, when it is necessary to adjust the power generation according to the grid demand, this module can quickly turn on or off the motor starter to control the speed of the generator. Its ability to withstand high voltage and high current loads makes it suitable for such harsh application scenarios, ensuring stable and safe operation of the power generation process.
The oil and gas industry also benefits from GE SLN042 IC086SLN042-Adue to its harsh and hazardous environment. It is used to operate valves that regulate the flow of oil and natural gas in pipelines. On offshore platforms, reliability is crucial due to the difficulty of maintenance. The robust design of this module enables it to operate normally in extreme temperatures, high humidity, and corrosive environments. Whether opening or closing valves to prevent leaks or guide resource flow, GE SLN042 IC086SLN042-Aprovides necessary digital output control.
SLN042 IC086SLN042-A
Related products:
GE IC086SLM042- GE’s managed switch module can be used in conjunction with GE SLN042 IC086SLN042-A to provide enhanced network management capabilities for industrial automation settings.
GE IC086SLN080- Another unmanaged switch module. In large industrial networks that require multiple switches, GE SLN042 IC086SLN042-A can be used as part of the overall control system for communication through these network devices.
GE Series 90-30/90-70 PLC CPUs – These are the central processing units for PLC platforms. GE SLN042 IC086SLN042-A is designed to work in conjunction with these CPUs, receiving commands and providing feedback on status information to achieve smooth operation of the control system.
GE CIMPLICITY HMI software – This software can be used to monitor and control operations related to GE SLN042 IC086SLN042-A. It provides a user-friendly interface for operators to view the status of output channels and make necessary adjustments.
GE DS200 series cards – Some of these cards, such as DS200DCCAG4A driver control card, can be integrated with GE SLN042 IC086SLN042-A in complex industrial control systems to jointly manage and control various aspects of equipment operation.
GE SINAMICS Drivers – In applications that require motor speed and torque control, these drivers can be controlled by GE SLN042 IC086SLN042-A. This module sends digital signals to the driver to regulate its operation.
Installation and maintenance:
Before installing GE SLN042 IC086SLN042-A, it is crucial to carefully consider the installation environment. When installing with DIN rails, please ensure that the DIN rails are securely installed and there is sufficient space around them. This module should be installed in a well ventilated area to prevent overheating, especially in high ambient temperatures. In addition, please ensure that the electrical connections comply with relevant safety standards. Proper grounding of this module is crucial for preventing electrical interference and ensuring the safety of the entire system.
In terms of maintenance, it is recommended to conduct regular visual inspections. Check for any physical signs of damage to the module, such as cracks in the casing or loose connections. The LED status indicator on the module can provide valuable information about its operation. If an output channel is not working as expected, please check the corresponding LED to see if an error is displayed. In addition, it is recommended to regularly use the built-in diagnostic tools of the PLC for diagnostic checks. This helps identify potential issues before they cause system failures. Additionally, please keep the module clean and avoid the accumulation of dust and debris, as these can affect its performance over time.
