GE IS420PPNGH1A serves as the core hub for power parameter management in industrial control systems. It interfaces with various power related components such as power transformers, switchgear, and motors to collect and analyze power data.
IS420PPNGH1A
This module is equipped with advanced sensors and signal processing circuits, which can simultaneously measure multiple power parameters. It can accurately measure voltage, current, active power, reactive power, power factor, and frequency. Subsequently, high-speed algorithms are used to internally process the measurement data to calculate other derived parameters and detect any deviations from normal operating conditions.
IS420PPNGH1A
Technical specifications:
Model IS420PPNGH1A
Brand General Electric (GE)
Type Power Parameter Monitoring and Control Module
Measurable parameters include voltage, current, active power, reactive power, power factor, and frequency
Communication interface Ethernet (10/100BaseT), serial (RS-232/RS-485)
Control output relay output, used to control power related equipment
The measurement accuracy of most parameters is as high as ± 0.5%
Working temperature -20 ° C to+60 ° C
Power supply 24V DC or 110-230V AC (switchable)
Installation method: DIN rail installation
Bus compatibility and compatibility with major industrial communication buses
Compliance with relevant industry standards, such as IEC 61000 (Electromagnetic Compatibility and Safety)
The built-in memory for data recording is used to store historical electricity data
Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com
IS420PPNGH1A
Main features and advantages:
After data processing,IS420PPNGH1A will convey this information to other parts of the control system. It has multiple communication interfaces, including Ethernet and serial ports, and can seamlessly integrate with programmable logic controllers (PLCs), monitoring and data acquisition (SCADA) systems, and energy management systems (EMS). This enables factory operators to monitor power parameters in real-time in the central control room and make informed decisions on power distribution and equipment operation.
In terms of control functions, GE IS420PPNGH1Acan be programmed according to preset thresholds to perform control operations. For example, if the power factor of a specific circuit is below a certain level, the module can send instructions to the capacitor bank to adjust the power factor and improve power quality. It can also be used to control the start stop sequence of motors to optimize power consumption during peak and off peak periods.
From a physical design perspective, GE IS420PPNGH1A is easy to install in standard industrial control cabinets. It is installed on a DIN rail, simplifying the integration process and ensuring a secure and orderly installation. Its compact size allows it to be installed in small spaces, making it very suitable for retrofitting existing power monitoring and control systems.
Its precise ability to measure power parameters enables factory operators to gain a deep understanding of power usage patterns. These knowledge can be used to optimize electricity consumption, resulting in significant cost savings on energy bills. For example, by identifying and correcting low power factor circuits, facilities can reduce overall energy demand and avoid fines from power companies.
The real-time monitoring and control function of this module enhances the reliability of power supply. By promptly identifying and resolving power quality issues, it helps prevent equipment failures and production shutdowns. This not only saves maintenance and repair costs, but also improves the overall production efficiency of the factory. In a continuous production manufacturing environment, even a brief power outage can lead to significant losses, andIS420PPNGH1A can help reduce such risks.
In addition, this module can interface with various industrial systems for seamless integration into existing infrastructure. This reduces the need for comprehensive retrofitting of complex and expensive systems, making it an ideal choice for new installations and upgrading existing power management systems.
IS420PPNGH1A
Application areas:
In power plants, it is used to monitor and control the power output of generators, ensuring stable and efficient power production. It helps optimize the power factor of the generated electricity, which is crucial for grid connection and power quality.
In data centers, stable power supply is crucial for the operation of servers and other critical IT equipment, and GE IS420PPNGH1A is deployed to monitor power quality and manage power distribution. It can detect and correct voltage fluctuations that may damage sensitive IT hardware, ensuring uninterrupted service.
The manufacturing industry is also highly dependent on GE IS420PPNGH1A. For example, in automobile manufacturing factories, it is used to monitor and control the power supply of robot arms, conveyors, and other high-power devices. By maintaining optimal power conditions, it helps improve the accuracy and efficiency of the manufacturing process, reduce scrap rates and production costs.
IS420PPNGH1A
Related products:
GE IS420PPNHH1A – This is a related power parameter monitoring module launched by General Electric (GE), which may have different functions or characteristics. It may provide additional features or be more suitable for specific application scenarios. However, before choosing these two models, it is important to carefully evaluate the requirements of your system.
IS420PPNGH1A
Installation and maintenance:
Before installing GEIS420PPNGH1A, be sure to carefully read the installation manual. Verify whether the module is compatible with your existing power monitoring and control system, including communication protocols, power supply requirements, and physical dimensions. Ensure that there are available DIN rail slots in the control cabinet for installing the module.
During the installation process, preventive measures should be taken to avoid electrical interference. Use shielded cables for communication and sensor connections to reduce the impact of electromagnetic noise. Carefully follow the recommended wiring diagram to ensure proper connection of power supply, sensors, and control outputs. Configure the module using the provided software or configuration tool, and set parameters such as measurement range, communication settings, and control thresholds according to your specific application requirements.
For daily maintenance, it is necessary to regularly check the status indicator lights of the module to ensure its normal operation. Monitor the collected power parameter data to detect any abnormal trends or fluctuations. Regularly update the firmware of this module to benefit from the latest features, bug fixes, and performance improvements provided by General Electric (GE). If any problems arise, please refer to the user manual or contact General Electric’s (GE) technical support team for assistance. They can provide troubleshooting guidance for common issues and help ensure the continuous and reliable operation of IS420PPNGH1A
