GE IS200WETAH1AEC is a printed circuit board (PCB) component that is an important part of the GE Mark VI Speedtronic series. The Mark VI system is developed by General Electric and is an advanced gas/steam turbine management program. The system was launched in the 1990s under the name “Speedtronic” and has since been a cornerstone of the turbine control industry.
IS200WETAH1AEC
As part of the Mark VI system, IS200WETAH1AEC is a critical interface between different components in the turbine control system. It is connected to the sub board (specifically IS210BPPBH2C) to expand its functionality. This connection enables a more comprehensive and integrated control system, enabling seamless transmission of data and commands between various elements in the turbine control infrastructure.
IS200WETAH1AEC
Main features and advantages:
One of the main advantages of GE IS200WETAH1AECis its high-quality construction and component selection. It is equipped with seven fuses and four transformers, which help achieve reliable operation. Three transformers are arranged in groups, and the fourth transformer is located on the other side of the board, which may optimize electrical performance and heat dissipation.
This board is equipped with six terminal blocks and more than twenty-five test points, as well as multiple jumper switches. These components provide flexibility for configuring the board according to specific application requirements. The presence of coil inductors, resistors, relays, diodes, capacitors, and integrated circuits further enhances their functionality, enabling them to handle various electrical signals and control functions.
More than 100 voltage regulators are arranged along the edge of the board (parallel to the three edges) to ensure stable and consistent power supply for connected components. This is crucial for maintaining the integrity of the control system in environments with common electrical fluctuations.
In terms of connectivity, the board is equipped with numerous connectors. It has six terminal blocks and a total of 45 or more plugs or connectors, including conductive connectors, vertical pin connectors (male), and female plugs. Some female plugs (such as P29A, P29B, and P29C) are labeled with similar reference identifiers, which simplifies the identification and connection of wires. This extensive connector configuration enables easy integration with various sensors, actuators, and other devices in turbine control systems.
IS200WETAH1AEC
Technical specifications:
Model IS200WETAH1AEC
Brand GE
Type Printed Circuit Board
Series Mark VI Speedtronic
Manufacturer General Electric Company
Compatibility and connection with sub board IS210BPPBH2C
Power supply 24V DC
Working temperature range -40 ° C to 70 ° C
Size 12 inches x 12 inches x 2 inches
Weight 10 pounds
Number of fuses 7
Number of transformers 4
Number of terminal blocks 6
More than 25 testing points
Connector type: conductive, vertical pin (male), female plug
More than 100 voltage regulators
