GE IS200TTURH1CCC S1DF00Z High Performance Turbine Terminal Board

Description

GE IS200TTURH1CCC S1DF00Z is a high-performance turbine terminal board that occupies a central position in GE’s famous Mark VI Speedtronic turbine control system. As a critical I/O module, it is the key connection point between the central control unit of industrial control systems and field devices.

IS200TTURH1CCC S1DF00Z

In the overall architecture of the Mark VI system, GE IS200TTURH1CCC S1DF00Z serves as the communication hub. It receives control signals from the main control processor and converts them into commands that can be executed by field devices such as sensors, actuators, and relays. On the contrary, it also collects data from these on-site devices and transmits it back to the central control system for analysis and further decision-making.

IS200TTURH1CCC S1DF00Z

Main features and advantages:
One of the most notable features of GE IS200TTURH1CCC S1DF00Z is its high-speed signal processing capability. It can quickly analyze and respond to input signals from sensors, ensuring that the turbine control system can respond promptly to any changes in the operating environment. This rapid response time is crucial for maintaining the stability of steam turbine operation, especially in situations where overspeed and other potential disasters may occur. Instant decision-making can prevent potential accidents from occurring.

In terms of hardware design, this terminal board can withstand the harshest industrial conditions. It adopts a sturdy structure and is coated with a conformal PCB, which can prevent dust, moisture, and vibration. This not only extends the service life of the terminal board, but also reduces the need for frequent maintenance and replacement. The existence of isolation transformers further improves their reliability and can shield common electrical noise and surges in industrial environments.

GE IS200TTURH1CCC S1DF00Z also performs well in compatibility. It is connected to TRPG (trip relay panel group) through three 37 pin connectors (P1/P2/P3) and two terminal blocks (24+24 pins), enabling seamless connection with other components in the control system. This enables precise control of turbine protection functions, including generator circuit breaker tripping and emergency shutdown. Its dual 28V DC power input provides an additional redundancy layer to ensure continuous operation during transient voltage fluctuations. Integrated fuses can protect terminal boards from damage caused by short circuits and overcurrent situations, and protect terminal boards and connected devices.

IS200TTURH1CCC S1DF00Z

Technical specifications:
Model IS200TTURH1CCC S1DF00Z
Brand GE
Type: Turbine Terminal Board
Dual 28V DC power supply
Working temperature range -40 ° C to 85 ° C
Interface three 37 pin connectors (P1/P2/P3) and two terminal blocks (24+24 pins)
Redundancy supports simple and TMR configuration
Signal processing speed, high-speed processing, achieving fast response
Protective features: conformal PCB coating, isolation transformer, integrated fuse

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

IS200TTURH1CCC S1DF00Z

Application areas:
In power plants, the reliable operation of steam turbines is crucial for efficient power generation, whether using gas, steam, or nuclear power. GE IS200TTURH1CCC S1DF00Z ensures seamless control of the turbine and plays a critical role in the synchronization process between the turbine and the generator. This synchronization is crucial, as any mistakes can lead to power fluctuations, grid instability, and potential equipment damage. By precisely managing the operation of steam turbines, it helps to maintain a stable and reliable power supply, meeting the growing energy demands of industry and households.

The oil and gas industry is also highly dependent on GE IS200TTURH1CCC S1DF00Z. Steam turbines are used in various stages of oil extraction, refining, and transportation. For example, in refineries, steam turbines provide power to pumps that propel crude oil through complex pipelines. The GE IS200TTURH1CCC S1DF00Z is connected to the sensors and actuators in these systems for real-time monitoring and control. It can detect changes in pressure, flow rate, or temperature and adjust the operation of the turbine accordingly. This not only optimizes the efficiency of oil and gas operations, but also improves safety by preventing situations such as overpressure or insufficient flow, which may lead to leaks or other hazardous events.

In addition, in heavy industrial environments such as steel plants, large machinery continues to operate, and GE IS200TTURH1CCC S1DF00Z is used to manage and drive steam turbines for key processes such as metal smelting and rolling. It is capable of handling complex control tasks under harsh conditions such as vibration, high temperature, and electromagnetic interference, making it the preferred solution for industries where continuous and reliable operation is crucial.

IS200TTURH1CCC S1DF00Z

Related products:
IS200TTURH1C – a closely related turbine terminal board within the same product series, sharing some basic functions but may differ in performance or specific application requirements. It can be used in scenarios with lower requirements or as a component in parallel settings to increase redundancy.
PTUR board – works in conjunction with GE IS200TTURH1CCC S1DF00Z to enhance overall turbine control functionality. They jointly provide more precise control and monitoring for the operation of steam turbines in complex industrial applications.
VTUR board – integrated with GE IS200TTURH1CCC S1DF00Z to manage and optimize the synchronization process between the turbine and generator. Their joint operation ensures smooth power generation and grid connection.
IS200ADIIH1A dual channel I/O module – can be connected to expand the system’s input/output capabilities. This enables GE IS200TTURH1CCC S1DF00Z to connect with more sensors and actuators, increasing the control and monitoring range of the system.
IS200ACLAH1A application control layer module – interacts with GE IS200TTURH1CCC S1DF00Z to coordinate and manage overall control functions at a higher level. It helps optimize the operation of the entire industrial process by integrating various control elements.
IS200TREGH1BEC – Provides independent emergency overspeed protection and can be integrated with GE IS200TTURH1CCC S1DF00Z to enhance the safety features of the turbine control system. This provides an additional layer of protection against potential turbine overspeed events.
IS200JPDMG1ACC S1AT005 distribution board – provides stable power supply for GE IS200TTURH1CCC S1DF00Z and other components in the system. A reliable power supply is crucial for the normal operation of the entire control setup, and this distribution board ensures a stable power supply without fluctuations for GE IS200TTURH1CCC S1DF00Z.

IS200TTURH1CCC S1DF00Z

Installation and maintenance:
Before installing GE IS200TTURH1CCC S1DF00Z, a thorough inspection of the installation site must be conducted. Ensure that the control cabinet is clean, free of dust and debris, and has sufficient space to accommodate the terminal board. The installation surface should be sturdy and well grounded to prevent electrical interference. When connecting the power supply, be sure to carefully check whether the wiring of the dual 28V DC input is correct and ensure that all grounding connections are firm. This not only prevents electrical faults in the terminal board, but also ensures safe operation in industrial environments.

For maintenance, it is recommended to conduct regular visual inspections. Check for any signs of physical damage, such as cracks on the PCB, loose connectors, or signs of overheating. Check the status of the isolation transformer and fuse to ensure they are working properly. Regular signal diagnosis should also be conducted to verify whether the terminal board accurately processes and transmits signals. GE may occasionally release firmware updates to improve the performance of terminal boards, fix vulnerabilities, or add new features. Be sure to stay informed of these updates in a timely manner and carefully follow the manufacturer’s guidelines when applying any updates. Before performing updates, it is essential to back up all relevant data and configurations to avoid any potential data loss.
