GE IC697CPX928-FE is a central processing unit (CPU) module that is an important component of the GE Fanuc 90-70 series programmable logic controller (PLC). It serves as the ‘brain’ of the control system, executing user-defined programs to manage industrial processes.
IC697CPX928- FE
In a typical PLC based control system, GE IC697CPX928-FE is at the core, communicating with various input/output (I/O) modules, sensors, and actuators. It receives data from sensors (which may measure parameters such as temperature, pressure, or position), processes this data according to programmed logic, and then sends control signals to actuators (such as motors, valves, or solenoid valves) to adjust the process as needed.
IC697CPX928- FE
Main features and advantages:
From a functional perspective, the GE IC697CPX928-FE is indeed outstanding. It uses a 96 MHz 80486DX4 microprocessor, which can execute control algorithms and logic operations at extremely fast speeds. Its typical scanning rate is 0.4 microseconds per Boolean function, which can quickly process large amounts of data and is very suitable for applications that require real-time response. It supports 32-bit floating-point operations, which are crucial for handling complex mathematical operations in applications such as process control and motion control.
In terms of I/O capability, this module can handle up to 12K arbitrary combinations of inputs and outputs, as well as up to 8K analog inputs and outputs. This extensive I/O capacity enables it to interface with various field devices, thus adapting to different industrial applications.
Compatibility is a major advantage of GE IC697CPX928-FE. It is compatible with multiple GE Fanuc modules, including IC660/661 I/O and IC697 I/O modules. This compatibility allows for seamless integration of different components into a coordinated control system. It also supports communication protocols such as SNP (Slave), Break free SNP (Slave), SNPX, and RTU, enabling it to communicate with other devices in the network, such as remote I/O units or other PLCs.
GE IC697CPX928-FE has built-in long-term reliability. Battery backup memory and non-volatile flash memory ensure data integrity. The module also has a self diagnostic function, with seven status LED indicators on the front panel providing visual feedback on its operating status. These LED indicators can indicate power issues, communication errors, or program execution failures, making troubleshooting easier.
IC697CPX928- FE
Technical specifications:
Model IC697CPX928-FE
Brand GE
Type Central Processing Unit (CPU) module
Microprocessor 96 MHz 80486DX4
6MB memory, battery backup RAM, 256KB non-volatile user flash memory
I/O capacity up to 12K inputs and outputs (any combination), up to 8K analog I/O
Serial port: 1 RS232 port, 2 RS485 ports, 1 factory reset port
Supported Protocol SNPs (Dependent), Break free SNPs (Dependent) SNPX、RTU
Required current 3.1 amperes
Input voltage 5 volts DC
Working temperature (with forced air cooling) 32-140 degrees Fahrenheit
Working temperature (without forced air cooling) 32-122 degrees Fahrenheit
Installation method: Single slot installation in GE Fanuc 90-70 PLC rack
Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com
Application areas:
Precision and efficiency are core requirements in manufacturing factories, from automotive assembly lines to electronic product production facilities. GE IC697CPX928-FE is located at the core of the control system, coordinating the operation of robotic arms, conveyors, and other automation equipment. For example, in an automobile factory, it precisely controls the robotic arm that welds the car frame. By processing real-time data from various sensors on the production line, it can ensure that every welding reaches the highest quality, reducing defects and rework. This not only improves production efficiency, but also enhances product quality, ultimately saving costs for manufacturers.
In the energy sector, power plants rely on GE IC697CPX928-FE to manage and optimize operations. In thermal power plants, it monitors and adjusts the combustion process to ensure efficient combustion of fuel for power generation. By controlling variables such as fuel flow rate, intake air volume, and steam pressure, it maximizes power generation while reducing emissions. In a hydroelectric power plant, this module controls the turbine and regulates the water flow to maintain stable power output, regardless of fluctuations in water level.
