GE IC695CRU320CA-EL is a high-performance redundant processor and an important component of GE’s PACSystem RX3i series. As a programmable automation controller (PAC), it is the intelligent core of industrial control systems, capable of accurately and efficiently handling various control tasks.
IC695CRU320CA -EL
In the PACSystem RX3i architecture, IC695CRU320CA-EL interacts with numerous other components such as input/output (I/O) modules, communication cards, and human-machine interfaces (HMI). It acts as a central decision-maker, receiving data from sensors through I/O modules, processing this data using complex algorithms, and then sending control signals to actuators to perform the required operations.
IC695CRU320CA -EL
Main features and advantages:
One of the most impressive features of GE IC695CRU320CA-EL is its powerful 1GHz Celeron M processor. This high-speed processor enables the controller to execute complex control algorithms in real-time, ensuring fast response times even in the most demanding applications. Whether processing large amounts of data from multiple sensors or making quick control decisions, a 1GHz processor can easily handle them.
In terms of memory,IC695CRU320CA-ELis equipped with 64 MB battery backed RAM and 64 MB non-volatile flash user memory. Battery backed up RAM ensures that critical data and programs are not lost in the event of a power outage, while non-volatile flash provides a reliable storage solution for long-term data retention. Adequate memory capacity allows for storing large control programs and processing large amounts of data logs, which is crucial for analyzing system performance and troubleshooting.
GE IC695CRU320CA-ELhas excellent communication capabilities. It has two serial communication ports that support RS232 and RS485 communication standards. This allows it to seamlessly integrate with various devices, including sensors, actuators, HMIs, and other controllers. In addition, when used in conjunction with a suitable rack mounted Ethernet module (such as IC694ETM001), it can communicate through Ethernet, enabling connections to a wider range of industrial networks and enterprise systems.
The redundancy design ofIC695CRU320CA-ELis a significant advantage. When configured as a redundant system with another IC695CRU320CA-ELand redundant memory swapping module, it provides hot standby redundancy. In the event of a failure in the main controller, the backup controller can be connected for up to one logical scan cycle (minimum 3.133 milliseconds) to ensure uninterrupted operation. This high availability feature is crucial in industries where continuous production is essential, such as manufacturing, power generation, and the oil and gas industry.
IC695CRU320CA -EL
Technical specifications:
Model IC695CRU320CA-EL
Brand GE
Type redundant processor
Series PACSystem RX3i
Manufacturer GE Fanuc/Emerson Automation
Processor 1GHz Celeron M
Memory 64 MB battery backup RAM, 64 MB non-volatile flash user memory
Communication ports: 2 serial ports (RS232 and RS485), supporting Ethernet (additional module required)
Power supply+3.3 VDC: 1.0 ampere (rated); +5 VDC: 1.2 amperes (rated)
Working temperature: 0 to 60 ° C (32 ° F to 140 ° F)
Floating point operation support
The maximum drift of clock time accuracy is 2 seconds per day
Accumulated time clock (internal timing) with a maximum accuracy of 0.01%
Supported serial protocol Modbus RTU slave SNP、 Serial I/O
Backplane dual backplane bus support: RX3i PCI and high-speed serial bus
PCI compatibility complies with PCI 2.2 standard
The maximum number of program blocks is 512, and the maximum size of each block is 128 KB
Memory Error Checking and Correction (ECC) Single Bit Correction and Multi Bit Check
Switching time up to 1 logical scan cycle, minimum 3.133 milliseconds
The maximum amount of data in the transmission list is 2 Mbytes
The maximum number of redundant links supported is two IC695RMX128/228 synchronous links
Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com
IC695CRU320CA -EL
Application areas:
Taking the manufacturing industry as an example. In large automobile factories, thousands of components require precise and coordinated assembly. GE IC695CRU320CA-EL controls the movement of robotic arms to ensure they can accurately grasp, place, and weld components. It also manages the speed of the conveyor belt to ensure the continuous and smooth flow of materials on the production line. Once the control system malfunctions, it may cause component misalignment, production bottlenecks, and ultimately result in significant economic losses.
In the oil and gas industry, operations are typically carried out in harsh and remote environments, and IC695CRU320CA-EL is used to monitor and control the extraction, refining, and transportation processes. It regulates the flow of oil and natural gas in pipelines to ensure optimal pressure and flow rate. In refineries, it manages complex chemical reactions, controls variables such as temperature and pressure to produce high-quality fuels and petrochemical products. Here, the reliability of GE IC695CRU320CA-EL is crucial as any failure could lead to safety hazards and environmental disasters.
The power plant also heavily relies on IC695CRU320CA-EL. Whether it is coal-fired, gas-fired, or nuclear power plants, this controller is responsible for managing the processes of power generation, distribution, and grid connection. It monitors the performance of turbines, generators, and other critical equipment, making real-time adjustments to maintain stable power output. In renewable energy plants such as wind and solar power, GEIC695CRU320CA-ELhelps optimize energy production by controlling the angle of wind turbine blades or tracking systems for solar panels.
IC695CRU320CA -EL
Main features and advantages:
One of the most impressive features of GE IC695CRU320CA-ELis its powerful 1GHz Celeron M processor. This high-speed processor enables the controller to execute complex control algorithms in real-time, ensuring fast response times even in the most demanding applications. Whether processing large amounts of data from multiple sensors or making quick control decisions, a 1GHz processor can easily handle them.
In terms of memory,IC695CRU320CA-ELis equipped with 64 MB battery backed RAM and 64 MB non-volatile flash user memory. Battery backed up RAM ensures that critical data and programs are not lost in the event of a power outage, while non-volatile flash provides a reliable storage solution for long-term data retention. Adequate memory capacity allows for storing large control programs and processing large amounts of data logs, which is crucial for analyzing system performance and troubleshooting.
GE IC695CRU320CA-EL has excellent communication capabilities. It has two serial communication ports that support RS232 and RS485 communication standards. This allows it to seamlessly integrate with various devices, including sensors, actuators, HMIs, and other controllers. In addition, when used in conjunction with a suitable rack mounted Ethernet module (such as IC694ETM001), it can communicate through Ethernet, enabling connections to a wider range of industrial networks and enterprise systems.
The redundancy design of IC695CRU320CA-EL is a significant advantage. When configured as a redundant system with another IC695CRU320CA-EL and redundant memory swapping module, it provides hot standby redundancy. In the event of a failure in the main controller, the backup controller can be connected for up to one logical scan cycle (minimum 3.133 milliseconds) to ensure uninterrupted operation. This high availability feature is crucial in industries where continuous production is essential, such as manufacturing, power generation, and the oil and gas industry.
IC695CRU320CA -EL
Technical specifications:
Model IC695CRU320CA-EL
Brand GE
Type redundant processor
Series PACSystem RX3i
Manufacturer GE Fanuc/Emerson Automation
Processor 1GHz Celeron M
Memory 64 MB battery backup RAM, 64 MB non-volatile flash user memory
Communication ports: 2 serial ports (RS232 and RS485), supporting Ethernet (additional module required)
Power supply+3.3 VDC: 1.0 ampere (rated); +5 VDC: 1.2 amperes (rated)
Working temperature: 0 to 60 ° C (32 ° F to 140 ° F)
Floating point operation support
The maximum drift of clock time accuracy is 2 seconds per day
Accumulated time clock (internal timing) with a maximum accuracy of 0.01%
Supported serial protocol Modbus RTU slave SNP、 Serial I/O
Backplane dual backplane bus support: RX3i PCI and high-speed serial bus
PCI compatibility complies with PCI 2.2 standard
The maximum number of program blocks is 512, and the maximum size of each block is 128 KB
Switching time up to 1 logical scan cycle, minimum 3.133 milliseconds
The maximum amount of data in the transmission list is 2 Mbytes
The maximum number of redundant links supported is two IC695RMX128/228 synchronous links
Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com
Application areas:
Taking the manufacturing industry as an example. In large automobile factories, thousands of components require precise and coordinated assembly. GE IC695CRU320CA-EL controls the movement of robotic arms to ensure they can accurately grasp, place, and weld components. It also manages the speed of the conveyor belt to ensure the continuous and smooth flow of materials on the production line. Once the control system malfunctions, it may cause component misalignment, production bottlenecks, and ultimately result in significant economic losses.
In the oil and gas industry, operations are typically carried out in harsh and remote environments, and IC695CRU320CA-ELis used to monitor and control the extraction, refining, and transportation processes. It regulates the flow of oil and natural gas in pipelines to ensure optimal pressure and flow rate. In refineries, it manages complex chemical reactions, controls variables such as temperature and pressure to produce high-quality fuels and petrochemical products. Here, the reliability of GEIC695CRU320CA-ELis crucial as any failure could lead to safety hazards and environmental disasters.
The power plant also heavily relies on IC695CRU320CA-EL. Whether it is coal-fired, gas-fired, or nuclear power plants, this controller is responsible for managing the processes of power generation, distribution, and grid connection. It monitors the performance of turbines, generators, and other critical equipment, making real-time adjustments to maintain stable power output. In renewable energy plants such as wind and solar power, GE IC695CRU320CA-EL helps optimize energy production by controlling the angle of wind turbine blades or tracking systems for solar panels.
Related products:
IC695RMX128/228- These are redundant memory swapping modules. When used in conjunction with GE IC695CRU320CA – EL, they can achieve hot standby redundancy functionality. They facilitate data exchange between the main controller and the backup controller, ensuring seamless operation during the switching process.
IC694ETM001- An Ethernet module that allows IC695CRU320CA – EL to communicate via Ethernet. This expands the connectivity options of the controller, enabling it to integrate with Ethernet based devices and networks, such as enterprise systems used for remote monitoring and control.
IC695CHS001- Rack module in PACSystem RX3i series. IC695CRU320CA-EL is installed in this rack, providing the necessary mechanical and electrical connections for the controller to interface with other modules in the system.
IC695ACC302- An external high-capacity battery. It is used to power the battery backup RAM in IC695CRU320CA – EL, ensuring data retention during power outages.
IC695MDL655- A digital input/output module. It can be connected to IC695CRU320CA-EL to provide digital input and output capabilities for the control system. The controller can receive digital signals from sensors connected to the module and send digital control signals to the actuator.
IC695MDL754- An analog input module. This module interfaces with IC695CRU320CA – EL and provides analog input capability. It can measure analog signals from temperature sensors, pressure sensors, and other sensors, and convert them into digital data for the controller to process.
IC695MDL740- An analog output module. When connected to IC695CRU320CA – EL, it allows the controller to send analog control signals to devices such as frequency converters or valves, achieving precise control of analog based processes.
Installation and maintenance:
Before installing GEIC695CRU320CA-EL, the installation location must be carefully planned. The control cabinet should be placed in a clean, dry, and well ventilated area, away from electromagnetic interference sources. Ensure that the control cabinet has sufficient space to accommodate the controller and all related modules, and leave appropriate gaps for heat dissipation.
During the installation process, it is essential to follow the manufacturer’s guidelines. When installing IC695CRU320CA-EL on the RX3i backplane, make sure it is securely fixed to prevent any vibrations that may affect its performance. When connecting cables, use appropriate tools and ensure that all connections are secure and properly shielded, especially communication cables.
For maintenance, it is recommended to conduct regular visual inspections. Check for any signs of physical damage, such as cracked casing or loose connections. Regularly monitor the status indicator lights on the controller. The indicator lights provide important information about the operating status of the controller, such as whether it is running normally, running, or if there are any errors. Regularly conduct diagnostic tests to check the integrity of the controller’s memory and processing functions. In addition, maintain firmware updates forIC695CRU320CA-EL. GE will regularly release firmware updates, which may include bug fixes, performance improvements, and enhanced features. Installing these updates helps keep the controller in optimal operating condition at all times.
