GE IC693CPU363 High Performance CPU Module

Description

GE IC693CPU363 Product Description:
The GE IC693CPU363 is a high-performance CPU module for the GE Series 90-30 PLC platform, which is highly trusted for its scalability and ease of integration. As a central processing unit, it executes control logic, manages I/O operations, and facilitates communication with human-machine interfaces (HMI), drivers, and monitoring and data acquisition (SCADA) systems.

IC693CPU363

This module uses a 32-bit RISC processor and 1MB of user memory (expandable to 3MB with optional memory cards), supporting up to 1536 I/O points (remote I/O support), suitable for various applications ranging from standalone devices to small factory level systems. It is compatible with GE’s VersaPro programming software (supporting IEC 61131-3 languages such as ladder diagrams and structured text), simplifying the development work of engineers familiar with traditional PLC programming paradigms.

The unique feature ofIC693CPU363 lies in its balanced cost-effectiveness. It offers advanced features such as PID control, data recording, and real-time clock functionality at an affordable price, making it a popular choice for retrofitting old systems or deploying in budget sensitive projects. The compact DIN rail installation method (100mm width) and plug and play connection with Series 90-30 I/O modules simplify the installation process and shorten the installation time for integrators.

IC693CPU363

Main features and advantages:
Processing and memory performance
The 32-bit processor of IC693CPU363 provides fast scanning time, capable of executing ladder logic at a speed of 0.5 milliseconds per kilobyte and structured text at a speed of 0.3 milliseconds per kilobyte. This is crucial for batch processing applications that require high-speed counting (up to 50kHz) or precise timing. Scalable memory supports storing complex programs, trend data, and recipes without the need for external data loggers in simple applications.

Communication capability
This module has built-in RS-232 and RS-485 ports, supports protocols such as Modbus RTU and DF1, and can seamlessly integrate with third-party devices such as frequency converters (VFDs) or barcode scanners. For factory workshop connections, optional Ethernet modules (such as IC693ETM300) can add Ethernet/IP or TCP/IP support, allowing data transmission to SCADA systems or cloud platforms for remote monitoring and analysis.

Robust industrial design
IC693CPU363 is designed for harsh environments, complies with IEC 61000-6-2/6-4 electromagnetic compatibility standards, and can operate in environments with up to 95% humidity (non condensing). Its fault detection function (including watchdog timer and parity check) ensures stable operation, while the front panel LED indicator provides real-time status updates (power, operation, fault, communication). The hot swappable design of this module allows for on-site replacement without power interruption, minimizing downtime during maintenance.

Scalability and flexibility
IC693CPU363 supports up to three local I/O racks and five remote I/O racks through the Series 90-30 remote I/O protocol. This scalability allows the system to expand from a simple single rack setup to a multi rack configuration with multiple I/O types (digital, analog, temperature, motion). For applications that require redundancy, this module can be paired with an auxiliary CPU in a hot standby configuration, although this requires additional hardware (such as the IC693ALG223 analog module for synchronization).

IC693CPU363

Technical specifications:
Model IC693CPU363
Brand GE
Type PLC CPU Module (Series 90-30)
32-bit RISC processor
User memory 1MB (expandable to 3MB through memory card)
Power supply 24VDC (input range 10-30VDC)
Working temperature -20 ° C to+60 ° C
Installation method DIN rail (EN 50022)
Size 100 x 150 x 110 millimeters (width x height x depth)
Weight 0.8 kilograms
Local communication interfaces RS-232, RS-485 (Modbus RTU, DF1)
I/O supports up to 1536 I/O points (local+remote)
Programming supports VersaPro (IEC 61131-3 language)
Certification CE, UL, cUL, CSA
Expansion slot 1 (for memory or communication modules)

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp: 16626708626
Email: 3772179818@qq.com

IC693CPU363

Application areas:
In the packaging industry, IC693CPU363 can coordinate the synchronous operation of filling machines, labeling machines, and conveyors to ensure stable production speed while monitoring defects or blockages. Its ability to execute ladder logic at high speed (up to 0.5 milliseconds/kilobyte) makes it ideal for managing complex assembly lines, such as those in automotive parts manufacturing, where millisecond level response to sensor inputs can prevent high downtime costs. In water treatment plants, this module controls the sequence of pumps, monitors flow rates, and adjusts the dosage of chemical agents based on real-time water quality data to ensure compliance with environmental regulations.

IC693CPU363

Related products:
IC693MDL645- Digital output module (16 points, 24VDC, relay output), used to drive inductive loads.
IC693ALG223- Analog input module (8 channels, 12 bits, 4-20mA/0-10V), used for process variable monitoring.
IC693ACC302- High speed counter module (50kHz), used for motion control or packaging applications.
IC693ETM300- Ethernet module for connecting to IP based networks and SCADA systems.
IC693PWR321- Redundant power module (24VDC) for critical applications.
IC693CMM301- Communication module (RS-485), used to connect to Profibus DP network.
IC693CHS392- Handshake module, used to synchronize multiple CPUs in a distributed system.

Installation and maintenance:
Considerations before installation
Before installingIC693CPU363, please verify the temperature and ventilation of the control cabinet to ensure that it meets the working range of the module. Use a dedicated grounding wire to ground the chassis to reduce electromagnetic interference (EMI), especially when co located with high-power devices such as frequency converters. When configuring remote I/O, please ensure the correct termination of the remote I/O network and use GE’s diagnostic tools to check signal integrity.
maintenance agreement
Conduct a visual inspection once a month to check for loose connections, damaged cables, or overheating. Use VersaPro software to monitor CPU diagnostic information, including memory usage and scan time trends, and back up programs to PCs or storage cards every quarter. Replace the lithium battery inside the module (usually every 5 years) to maintain real-time clock and memory retention. For systems with remote I/O, the communication link is tested annually by simulating cable faults and verifying automatic recovery. Record all maintenance activities to comply with ISO 9001 or industry-specific standards.
