GE D20 MIC 10BASE-T is a high-performance intelligent communication module that plays a critical role in industrial automation infrastructure. It serves as a central hub connecting various field devices (such as sensors, instruments, and actuators) with control platforms (such as programmable logic controllers (PLCs) and monitoring and data acquisition (SCADA) systems) through a D20 MIC 10BASE-T Ethernet interface.
D20 MIC 10BASE-T
This module serves as a protocol converter and data aggregator. It can communicate with devices using different protocols such as Modbus RTU, Profibus, and various proprietary industrial protocols, and convert their data into a format compatible with control networks based onD20 MIC 10BASE-TEthernet. Once data aggregation is complete, it will efficiently transmit data to the control system at a rate of 10 Mbps through the 10BASE-T interface, ensuring real-time availability of information. The General Electric D20 MIC 10BASE-T also has advanced data processing capabilities, including filtering, normalization, and basic analysis, which help reduce the data load on control systems and provide more meaningful insights. This module has a built-in diagnostic function that can continuously monitor its own operation and the status of connected devices, and send status updates and alerts through a D20 MIC 10BASE-T connection. In the automation architecture, it is located between the field device layer and the control layer system, achieving seamless flow of data and communication, and enhancing the overall intelligence and responsiveness of industrial automation settings.
D20 MIC 10BASE-T
Technical specifications:
Model D20 MIC 10BASE-T
Brand General Electric (GE)
Type: Intelligent Communication Module
Input voltage 18-36 VDC
Working temperature range -40 ° C -70 ° C
Installation method: DIN rail
Size [20mm x 70mm x 45mm
Weight 0.4 kg
Interface/Bus 10BASE-T Ethernet
Compliance with CE, RoHS, UL
Supports protocols such as Modbus RTU, Modbus TCP, Profibus DP, HART, etc
Up to 16 data aggregation channels
Data transmission rate 10 Mbps
Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com
D20 MIC 10BASE-T
Main features and advantages:
This module is designed to withstand harsh industrial environments, ensuring reliable operation even under challenging conditions, and reducing the risk of data collection failures and system interruptions. This reliability directly contributes to improving the normal operation time and productivity of industrial operations.
This module can integrate various devices and convert multiple protocols, simplifying automation infrastructure and eliminating the need for complex and expensive customized solutions. By aggregating and preprocessing data, it reduces the burden on the control system, enabling faster decision-making and more efficient resource allocation. The stable 10 Mbps data transmission rate provided by the D20 MIC 10BASE-Tinterface ensures real-time availability of data, which is crucial for applications such as predictive maintenance, as timely understanding of device health can prevent costly failures. The built-in diagnostic function improves maintenance efficiency, proactively detects and resolves potential issues, further reducing downtime and long-term maintenance costs.
D20 MIC 10BASE-T
Application areas:
In the oil and gas industry, it is used to connect and manage a large number of on-site equipment located in remote oil wells and pipelines, including pressure sensors, flow meters, and temperature probes. This module aggregates data from these devices and transmits it in real-time to the central control system through a D20 MIC 10BASE-T interface, enabling operators to monitor production processes, detect leaks, and optimize mining operations.
In the food and beverage manufacturing industry, maintaining product quality and safety is crucial, and the General Electric D20 MIC 10BASE-T integrates sensors to monitor parameters such as temperature, humidity, and ingredient levels on the production line. It ensures that data from these sensors can be accurately collected, processed, and transmitted to the control system for immediate adjustment to maintain consistent product quality. In addition, in intelligent building automation, this module can connect various devices such as HVAC sensors, lighting control, and access control systems to achieve centralized monitoring and control, and optimize energy consumption and living comfort.
D20 MIC 10BASE-T
Related products:
General Electric D20 MIC 100BASE-TX: With a data transmission rate of up to 100 Mbps, it is suitable for applications that require faster data processing and larger scale data aggregation.
General Electric D15 MIC 10BASE-T: equipped with basic data acquisition and protocol conversion functions, suitable for small industrial settings or less complex monitoring applications.
General Electric D20 MIC-H 10BASE-T: With enhanced heat dissipation capabilities, designed for sustained high load operation in environments where temperature may affect performance, ensuring stable data communication.
General Electric D20 MIC-R 10BASE-T: a redundant model equipped with dual 10BASE-T channels, providing higher reliability and ensuring uninterrupted data acquisition and transmission in the event of component failure.
General Electric D20 MIC-S 10BASE-T: Designed specifically for high-speed data acquisition applications, providing faster sampling rates and real-time data processing capabilities, suitable for applications that require immediate response.
General Electric D20 MIC-C 10BASE-T: Equipped with integrated security features such as data encryption and access control, it meets the strict security requirements of data sensitive industrial applications in industries such as finance and healthcare.
Installation and maintenance:
Before installing the General Electric D20 MIC 10BASE-T , it is essential to carefully plan the integration with existing industrial automation systems. Verify whether the input voltage provided to the module is within the specified range to avoid damage. Comprehensively evaluate the communication protocols of the on-site devices you intend to connect and ensure that General Electric D20 MIC 10BASE-T supports these protocols. Check the compatibility of network infrastructure with D20 MIC 10BASE-T interfaces, including Ethernet ports, network switches, and overall network bandwidth, to support data transmission rates of 10 Mbps without congestion. When configuring modules, set appropriate communication parameters for each connected device, such as baud rate, parity, and data format, and assign a unique IP address for seamless integration into D20 MIC 10BASE-T Ethernet networks.
For continuous maintenance, regularly monitor the diagnostic indicator lights of the module and the status of connected devices through the D20 MIC 10BASE-T interface. Diagnostic information can reveal communication errors, equipment malfunctions, or data transmission issues. Regularly check Ethernet cables and connectors for signs of wear, damage, or loose connections, as these issues may interrupt data flow. Conduct regular data quality checks to ensure the accuracy and reliability of aggregated and transmitted data. If any problems arise, please refer to the detailed troubleshooting guide provided by General Electric, which includes specific steps for resolving D20 MIC 10BASE-T related communication and equipment integration issues to quickly identify and resolve the problem.
