GE 760-P5-G5-S5-HI-A20-R Multi functional Control Module

Description

760-P5-G5-S5-HI-A20-R Product Description:
The GE 760-P5-G5-S5-HI-A20-R multifunctional control module plays a core hub role in automation systems. It can seamlessly integrate into mainstream industrial control platforms, adapt to various backplane system architectures, and quickly establish connections with sensors, actuators, and other devices through commonly used industrial bus interfaces.

760-P5-G5-S5-HI-A20-R

This module supports multiple communication protocols such as Modbus and Profinet, ensuring accurate and error free transmission of data between different devices. The module has a redundant design. When the main module fails, the backup module can automatically take over the work and maintain the stable operation of the system; The built-in intelligent diagnostic function can monitor the real-time operation status of the module. Once any abnormalities are detected, detailed fault information will be immediately provided to help engineers quickly locate and solve problems.

760-P5-G5-S5-HI-A20-R

Technical specifications:
Model 760-P5-G5-S5-HI-A20-R
GE brand
Type multifunctional control module
Input voltage 100-240VAC
Working temperature range -20 ° C to 60 ° C
Installation method: Panel installation
Size 200mm x 150mm x 80mm
Weight 1.5 kilograms
Interface/Bus Ethernet RS-485、CAN
Compliant with CE and UL standards
Supported protocols Modbus TCP, Profinet, CANopen
Typical power consumption of 15W

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp: 16626708626
Email: 3772179818@qq.com

760-P5-G5-S5-HI-A20-R

Main features and advantages:
Choosing the GE 760-P5-G5-S5-HI-A20-Rmultifunctional control module means choosing efficiency and reliability. Its sturdy design enables it to work stably for a long time in harsh environments such as high temperature, humidity, and dust, reducing equipment damage and replacement costs caused by environmental factors. The intelligent diagnostic function significantly reduces maintenance difficulty and time costs, eliminating the need for engineers to spend a lot of effort troubleshooting and significantly shortening production downtime. Strong protocol compatibility and flexible interface design enable modules to easily integrate into various new and old automation systems, greatly reducing the workload of system integration, accelerating project implementation speed, and saving labor and time costs for enterprises.

760-P5-G5-S5-HI-A20-R

Application areas:
The GE 760-P5-G5-S5-HI-A20-Rhas shown outstanding performance in multiple industries. In the energy industry, it is applied to wind power plants to monitor real-time parameters such as wind turbine speed, torque, temperature, etc., and dynamically adjust the operating status of wind turbines based on data to improve power generation efficiency; In the automated production line of the automotive manufacturing industry, it precisely controls the movement of the robotic arm to ensure high-precision assembly of components, while coordinating the rhythm of various production processes to ensure efficient operation of the production line; In the food and beverage industry, this module strictly controls parameters such as temperature, pressure, and liquid level during the production process to ensure stable product quality and meet food safety standards.

760-P5-G5-S5-HI-A20-R

Related products:
GE 760-P6-G6-S6-HI-A20-R data processing speed increased by 30%, suitable for complex control systems with extremely high real-time requirements
GE 760-P4-G4-S4-HI-A20-R， Lower cost, suitable for small automation projects
GE 760-P5-G5-S5-LO-A20-R， Suitable for distributed control systems with limited energy resources
GE 760-P5-G5-S5-HI-A10-R reduces the number of communication interfaces and is suitable for specific application scenarios with less interface requirements
GE 760-P5-G5-S5-HI-A30-R has added analog input and output channels, which can connect more sensors and actuators to meet the needs of large-scale data acquisition and control.

Installation and maintenance:
Before installing GE760-P5-G5-S5-HI-A20-R, it is necessary to carefully confirm that the power specifications of the existing control system match the input voltage of the module to avoid damaging the module due to voltage mismatch. At the same time, check the type and protocol settings of the communication bus to ensure consistency with the protocols supported by the module, and plan the installation location of the module in advance, reserving sufficient heat dissipation space and maintenance operation space.
During daily maintenance, regularly check the status of module indicator lights to determine if they are operating normally; Check if the communication cable connection is secure to prevent loosening and abnormal data transmission; It is recommended to conduct a comprehensive performance test on the module every six months to ensure its continuous and stable operation.
