GDB021BE01 HIEE300766R0001 Product Description:
GDB021BE01 HIEE300766R0001 is a multi-channel relay interface module designed specifically for industrial control systems, integrating digital input, output, and isolation relay contacts. As a key component in automation architecture, it bridges the gap between low-voltage control signals (such as 24 V DC from PLC) and high-voltage/high current field devices (such as 230 V AC motors), providing electrical isolation to prevent noise interference and component damage. This module is designed to be compact and supports DIN rail installation, suitable for control panels with limited space. Its modular layout is easy to replace or expand.
GDB021BE01 HIEE300766R0001
This module simplifies wiring and reduces the number of components by integrating multiple relay functions into one unit. Its function in the control circuit is to amplify weak control signals, isolate different voltage domains, and provide physical switches for inductive or resistive loads. GDB021BE01 HIEE300766R0001 is particularly valuable in old systems that require renovation, as it can interface with modern PLCs and older electromechanical control equipment. Its value proposition lies in combining long-term reliability with flexibility to adapt to multiple signal types, making it an indispensable component in industrial applications where durability and compatibility are essential.
GDB021BE01 HIEE300766R0001
GDB021BE01 HIEE300766R0001
Main features and advantages:
Multi functional channel design: This module typically includes [4-8] isolated channels, each of which can be configured as a digital input, digital output, or relay contact (single pole double throw/double pole double throw). For example, the channel can be configured to accept 24 V DC input signals (digital input) from limit switches, provide 24 V DC output (digital output) to solenoid valves, or switch 250 V AC loads through mechanical relays (single pole double throw). This multifunctionality reduces the need for multiple specialized modules.
Electrical isolation and anti-interference capability: The channel and system bus have an isolation degree of 2.5 kVrms, which can prevent grounding loops and electromagnetic interference (EMI), which is crucial in environments with high-power machinery. Surge suppression for inductive loads, such as metal oxide varistors and freewheeling diodes, extends the lifespan of relays by dissipating voltage spikes during the switching process.
Durable industrial design: This module can operate within a temperature range of -40 ° C to+70 ° C and withstand vibrations up to 5 g (IEC 60068-2-6), making it suitable for harsh environments. The sturdy plastic casing (IP20) is dustproof and moisture-proof, while the screw free terminal block simplifies wiring and reduces installation time. The LED indicator lights of each channel provide real-time status feedback (such as input activation, relay power on), which helps with troubleshooting.
Fault safe operation: Many variants include latch relays or fault safe outputs, which default to a safe state (such as open or closed) when powered off, comply with safety standards such as IEC 61508, and are suitable for SIL compliant systems. This feature is crucial in safety critical applications such as elevator control or gas shut-off systems.
GDB021BE01 HIEE300766R0001
Technical specifications:
Model GDB021BE01 HIEE300766R0001
Brand ABB
Type: Multi channel Relay Interface Module
Number of channels: 8 isolated channels
Input voltage 24 V DC (10-30 V DC range)
Output voltage/current relay: 250 V AC/30 V DC, 5 A (single pole double throw); Digital output: 24 V DC, 0.5 A
Isolation degree of 2.5 kVrms (between channels, channel to ground)
Working temperature -40 ° C to+70 ° C
Installation method DIN rail (TS 35/7.5)
Dimensions 100 mm (width) x 125 mm (height) x 60 mm (depth)
Weight 0.4 kg
Certification CE, UL, IEC 61000-6-2 (Electromagnetic Compatibility), IEC 60947-5-1 (Relay Standard)
Environmental protection level IP20, IEC 60068-2-27 (impact resistance)
Contact Us
Mobile:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com
Application areas:
In industrial power distribution and motor control systems, GDB021BE01 HIEE300766R0001 (usually a relay or interface module produced by ABB or similar industrial manufacturers) is a key component for managing low-voltage control circuits in harsh environments. This module is designed specifically for industries such as oil and gas, mining, and heavy machinery, ensuring reliable signal transmission between control systems and on-site equipment such as motor starters, circuit breakers, or safety interlocks. For example, in a mining conveyor system, this module can serve as a safety relay to cut off motor power in case of emergency stop or fault conditions, preventing catastrophic failures. In chemical plants, it can serve as an interface between programmable logic controllers (PLCs) and high-voltage switchgear, providing electrical isolation and protecting sensitive control electronic equipment from voltage surges.
The application of this module also extends to scenarios that require compliance with safety standards, such as emergency shutdown (ESD) systems or fire and gas detection networks. Engineers value its ability to handle multiple isolated channels, with each channel capable of switching between AC and DC signals, making it suitable for hybrid control settings. For example, in the turbine control system of a power plant, GDB021BE01 HIEE300766R0001can monitor vibration sensors (analog inputs) and trigger relay outputs in case of abnormal conditions, cutting off circuit breakers to ensure fast response and prevent equipment damage. This module addresses the core challenge of maintaining control integrity in high-risk industrial environments by prioritizing robustness, isolation, and fail safe operation.
Related products:
GDB020AE01- A relay module with fewer channels, suitable for smaller control panels.
DSRI110- Relay interface module for PLC, can be used in conjunction with GDB021BE01 to expand digital output capabilities.
TA521- Terminal adapter for relay module, simplifies on-site wiring and provides mechanical support.
PS501-24 V DC power supply ensures stable voltage for module control input.
CM572- Modbus RTU communication module for remote monitoring of relay status through SCADA system.
ABB S200 series circuit breaker – overcurrent protection device, paired with modules to protect load circuits from short-circuit effects.
Installation and maintenance:
Precautions before installation:
Clearly label the function of each channel (such as “Motor 1 Start”, “Emergency Stop”) to simplify troubleshooting. Use stranded copper wire with conduit (14-22 AWG) for terminal connection to ensure firm contact.
For inductive loads such as motors and solenoid valves, surge suppression devices (such as freewheeling diodes) should be installed on the load side instead of the module side to protect against voltage spikes.
If multiple modules are installed, ensure that the control cabinet has sufficient ventilation, as relay operation generates heat (typically ≤ 5 W per module).
Maintenance suggestion:
Perform a visual inspection every six months to check for loose terminals, burnt contacts, or signs of overheating (such as discoloration of the casing). Replace relays with arc damage or excessive contact wear.
Test each channel annually by applying control signals and verifying output actions using a multimeter or voltage tester. For safety critical channels, simulate fault conditions to ensure safe operation.
In a dusty environment, clean the module with compressed air to prevent debris from interfering with the relay mechanism. Check for signs of corrosion on the terminal block in a humid environment.
Reserve backup modules for critical applications, as relay contacts have a limited lifespan (typically 105-106 operations for inductive loads).
