FOXBORO P0926GV FBM231 On site equipment system integration module

Description

FOXBORO P0926GV FBM231 is a high-performance field equipment system integration module and an important component of the trusted FOXBORO I/A series. This series is a comprehensive platform that has been trusted by various industries worldwide for decades.

P0926GV FBM231

Main features and advantages:
In terms of functionality, FOXBORO P0926GV FBM231 is powerful. All four communication ports can be configured through software as RS-232, RS-422, or RS-485, providing unparalleled flexibility. This means that a single module can simultaneously connect multiple different types of devices. For example, it can interface with older legacy devices through RS-232 and communicate with modern high-speed sensors through RS-485.

The hardware design of this module is sturdy and durable, capable of withstanding the harsh tests of industrial environments. Its casing is dust-proof, moisture-proof, and vibration resistant, and can operate normally under the harshest conditions. Its compact size (approximately 10.4 cm x 4.5 cm x 11.4 cm) makes it suitable for installation in control cabinets where space may be limited. The DIN rail installation option further simplifies the installation process, enabling fast and safe fixation.

Compatibility is one of the strongest attributes of P0926GV FBM231. It supports multiple communication standards, including commonly found in industrial environments such as RS-232, RS-422, and RS-485. This enables seamless integration with devices from different manufacturers, whether they are sensors, actuators, or other control components. When using the RS-232 communication interface, it can even be used in conjunction with a modem, thereby expanding its connection options.

In terms of long-term reliability, FBM231 is designed to be durable and long-lasting. It is manufactured using high-quality components to ensure stable operation over a long period of time. This module can withstand 24 V DC ± 5% (redundant) and -10% input voltage range, with a maximum input power consumption of 7 W per module. This efficient power management, combined with its robust structure, helps extend its lifespan, reduce the need for frequent replacement, and minimize downtime in industrial operations.

P0926GV FBM231

Technical specifications:
Model P0926GV FBM231
Brand FOXBORO
Type: On site equipment system integration module
Input voltage range (redundant) 24 V DC ± 5%, -10%
Input power consumption: maximum 7 W per module
The installation method is to install it on the modular base plate. Modular baseboards can be installed horizontally or vertically on DIN rails, or horizontally in 19 inch racks using installation kits
Working temperature -20 to+70 ° C (-4 to+158 ° F)
Dimensions (length x width x height) 10.4cm x 4.5cm x 11.4cm
Weight 0.284 kilograms
Transport weight 1.5 kilograms
Interface four serial I/O communication ports; It can interface with four directly connected RS-232 and RS-422 dual port devices, or support up to 64 dual port devices (up to 16 devices per port) through four RS-485 buses. Each port is a dual logical port that can be connected to dual port devices
Communication standards support RS-232, RS-422, and RS-485
A redundant pair of FBM231 modules can provide redundancy at the fieldbus module (FBM) level
In RS-485 mode, each FBM231 can access up to 64 devices for data reading and writing. Up to 2000 Distributed Control Interface (DCI) data connections can be established from Foxboro control station to FBM231 for data read and write operations
The environmental protection shell can prevent dust, moisture, and vibration

Contact Us
Phone:+86 16626708626
WhatsApp/WeChat:+86 16626708626
Email: 3772179818@qq.com

P0926GV FBM231

Application areas:
Taking the oil and gas industry as an example, a vast pipeline network winds through complex terrain areas, transporting valuable resources. Here,P0926GV FBM231 is used to manage communication between various on-site devices and the central control system. It ensures seamless transmission of data such as pipeline pressure, flow rate, and temperature, enabling operators to maintain optimal operational efficiency and prevent potential disasters and accidents.

Chemical companies also heavily rely on FOXBORO P0926GV FBM231 due to their complex process flow and potential hazardous operations. It is a key link in controlling chemical reactions, accurately measuring raw materials, and regulating the flow of substances in complex pipelines and reactor networks. By maintaining stable communication channels between sensors, actuators, and overall control infrastructure, it ensures the integrity of the manufacturing process and the safety of factory personnel.

Power generation facilities, whether utilizing fossil fuels, water flow energy, or solar energy, have found P0926GV FBM231indispensable. It is responsible for managing the data exchange between different components of the power generation system, from sensors monitoring turbine speed to actuators controlling the opening and closing of cooling system valves. This enables precise control of power generation output, ensuring reliable and stable power supply to meet the constantly changing needs of consumers.

P0926GV FBM231

Related products:
P0922YU FPS400-24- A power module that provides the stable 24V DC power required for P0926GV FBM231, ensuring its reliable operation.
FBM230- This module is suitable for single port devices and complements FBM231 designed specifically for dual port devices. In some industrial settings, the two can be combined to handle various on-site devices.
FBM232 P0926GW – an Ethernet communication module. Although P0926GV FBM231 focuses on serial communication, FBM232 can be used to add Ethernet based communication capabilities to the entire system, enabling connections with devices and networks that rely on Ethernet protocols.
P0916AA – A control module in the FOXBORO I/A series. P0926GV FBM231 can work in conjunction with this control module, where FBM231 is responsible for communicating with field devices, while P0916AA is responsible for processing and responding to received data.
P0931RQ – A power related module that can be integrated into systems deploying P0926GV FBM231 to enhance power management or distribution, ensuring stable power supply to all connected components.
IM155-6 PN HF (if applicable) – an interface module that expands communication and connection options within industrial control networks, particularly useful when integrating P0926GV FBM231 into larger and more complex systems.
FBM241d – a fieldbus module that can be used to expand the input/output capabilities of the entire system, working in conjunction with P0926GV FBM231 to handle more field device connections.

Installation and maintenance:
Before installing FOXBORO P0926GV FBM231, it is necessary to carefully plan the layout of the control cabinet. Ensure there is sufficient clearance around the module to achieve proper heat dissipation, as overheating can lead to performance degradation and potential damage. Check the DIN rail or rack installation structure to ensure that it is in good condition and can securely fix the modular base plate of FBM231. Verify whether the input power supply meets the specified voltage range and ensure that the grounding system is installed correctly and meets safety standards. The correct grounding connection is crucial for protecting modules from surges and interference.

For maintenance, it is recommended to conduct regular visual inspections. Look for any signs of physical damage, such as cracks in the casing or loose connections. Check the status indicator lights on the module (if any) to ensure proper operation. Regularly use the diagnostic tools provided by FOXBORO to test the communication capability and data transmission accuracy of the module. Keep the module clean and prevent dust and debris from accumulating, as this may affect its performance over time. Stay up-to-date with any firmware updates or service announcements from FOXBORO, as these updates can enhance module functionality, fix potential vulnerabilities, and improve compatibility with other components in the system.
