FOXBORO L0130AD L0130AE-0H Circuit power supply analog signal conditioning module

Description

FOXBORO L0130AD L0130AE-0H is a loop power supply analog signal conditioning module used as an interface between field equipment and control systems. L0130AD serves as a two-wire circuit isolator, converting the 4-20 mA signal of the transmitter into an isolated output for DCS use; As a signal conditioner supporting HART communication, L0130AD L0130AE-0H can achieve bidirectional data exchange with intelligent field devices. Both modules belong to Foxboro’s extensive portfolio of I/O and signal conditioning solutions, compatible with the I/A series and EcoStruxure Automation Expert system.

L0130AD L0130AE-0H

In the control system architecture, these modules are located at the field level, serving as bridges between sensors/actuators and central processing units. Its core value lies in:
Electrical isolation: protects the control system from electrical surges and grounding loops.
Signal conditioning: Amplify, filter, and linearize signals to achieve precise process monitoring.
HART compatibility (L0130AE-0H): Supports configuring and diagnosing smart devices without interrupting analog control loops.
For integrators, this means reducing troubleshooting time, improving system uptime, and being compatible with both traditional and modern control settings.

L0130AD L0130AE-0H

Main features and advantages:
functional performance
Circuit power supply design: Obtain power from the 4-20 mA circuit without the need for a separate power source, simplifying installation in remote or space limited environments.
High precision: Maintain a linearity of ± 0.1% to ensure accurate representation of process variables such as temperature, pressure, or flow rate.
HART transparent transmission (L0130AE-0H): Supports the HART protocol on the secondary side, allowing engineers to access device diagnostics and configuration parameters without interrupting the analog control loop.
hardware design
Durable casing: suitable for industrial environments, with a working temperature range of -20 ° C to+60 ° C, dust-proof, moisture-proof, and vibration proof.
Compact structure: Can be installed on standard DIN rails, suitable for dense control panels or on-site installation of junction boxes.
LED diagnosis: The front panel indicator lights display power, signal status, and HART communication (L0130AE-0H) for quick troubleshooting.
compatibility
Protocol independence: Suitable for standard 4-20 mA analog signals and HART enabled devices, suitable for retrofitting old systems or integrating with modern smart sensors.
System integration: seamlessly paired with Foxboro FBM (fieldbus module) racks and other I/A series components to reduce engineering complexity.
reliability
Electrical isolation: A 250 V rms isolation barrier can prevent voltage spikes and extend the service life of on-site equipment and control system components.
Low power consumption: usually ≤ 1.5 W, reducing heat generation and energy consumption in large-scale deployment.

L0130AD L0130AE-0H

Technical specifications:
Model L0130AD L0130AE-0H
Brand FOXBORO FOXBORO
Type of Loop Power Supply Isolator Supports HART Loop Power Supply Signal Conditioner
Input signal 4-20 mA (two-wire loop) 4-20 mA (two-wire loop, compatible with HART)
Output signal isolation 4-20 mA isolation 4-20 mA+HART data
Power supply circuit (typical 24 VDC) Power supply circuit (typical 24 VDC)
Working temperature -20 ° C to+60 ° C -20 ° C to+60 ° C
Installation method DIN rail (35 mm) DIN rail (35 mm)
Dimensions 17.5mm (width) x 100mm (height) x 115mm (depth) 17.5mm (width) x 100mm (height) x 115mm (depth)
Weight approximately 0.1 kg, approximately 0.1 kg
Isolation 250 V rms (input/output/ground) 250 V rms (input/output/ground)
Accuracy ± 0.1% range ± 0.1% range
Is HART compatible? Yes (supports FDT/DTM)
Certified CE, FM (Class I, Div 2), ATEX CE, FM (Class I, Div 2), ATEX

Contact Us
Phone:+86 16626708626
WhatsApp/WeChat:+86 16626708626
Email: 3772179818@qq.com

L0130AD L0130AE-0H

Application areas:
In refineries, the L0130AD module ensures stable transmission of 4-20 mA signals from pressure transmitters monitoring pipeline conditions to the distributed control system (DCS), isolating electrical interference that may affect safety or efficiency.
In chemical plants, the L0130AE-0H module plays a critical role in regulating reactor temperature sensor signals, ensuring accurate data transmission even in high humidity or corrosive environments. These modules are also widely used in water treatment facilities to isolate flow meter signals and prevent grounding loops from interfering with pump control systems.

L0130AD L0130AE-0H

Related products:
FOXBORO FBM200 series: fieldbus module that interfaces with L0130AD/L0130AE-0H to transmit conditioned signals to DCS.
FOXBORO FCP270/FCP280: Field control processor integrated with these modules to achieve centralized process control.
FOXBORO P0971GN: Power unit that provides stable voltage to the control panel.

HART compatible transmitter (such as Rosemount 3051): Used in conjunction with L0130AE-0H to achieve intelligent device integration.

Installation and maintenance:
Precautions before installation
Wiring: Ensure the use of shielded cables to reduce electromagnetic interference (EMI), especially in high noise environments. Follow the polarity guidelines for 4-20 mA circuits.
Grounding: Connect the grounding terminal of the module to the grounding terminal of the control system to prevent grounding loops.
Environmental inspection: Confirm that the installation location meets temperature and humidity requirements, and avoid direct exposure to corrosive gases or excessive vibration environments.
maintenance
Visual inspection: Regularly check for loose connections, damaged wiring, or triggered LED indicator lights (such as red fault lights).
Signal diagnosis: Use a loop calibrator to test the input/output accuracy annually, ensuring that the signal remains within the specified range of ± 0.1%.
Firmware update: For L0130AE-0H, regularly update the HART device driver through DCS to support new sensor models or protocol revisions.
