Foxboro FEM100 P0973CA fieldbus expansion module

Description

The Foxboro FEM100 P0973CA is a fieldbus expansion module that is an essential part of the Foxboro (Schneider Electric) I/A series distributed control system (DCS). Its main function is to provide an extension path for the on-site control processor 270 (FCP 270).

FEM100 P0973CA

In the overall architecture of the control system, it serves as a bridge, allowing more field level devices to be connected to the central control processor. It provides four additional fieldbuses for FCP 270, each bus can accommodate up to 32 200 series fieldbus modules (FBMS). This expansion capability is a revolution for engineers and integrators, as it allows them to expand control systems according to the specific needs of industrial applications without the need for major overhauls of the entire system. It provides an economically efficient way to enhance the functionality of existing control settings.

FEM100 P0973CA

Main features and advantages:
In terms of functional performance, it supports high-speed 2 Mbps HDLC (Advanced Data Link Control) module fieldbus for communication between FCP 270 and 200 series FBMS. This high-speed communication ensures that data can be transmitted quickly, which is crucial for real-time control applications. Data can be quickly transmitted between on-site devices and control processors, enabling timely response to any changes in industrial processes.

The hardware design of FEM100 P0973CAis sturdy and durable, capable of withstanding harsh industrial environments. It can operate within a wide temperature range of -20 ° C to+70 ° C (-4 ° F to+158 ° F) and can withstand relative humidity levels of 5% to 95% (non condensing). This makes it suitable for various industrial environments, whether it’s hot and humid petrochemical plants or cold and dry power plants. It is installed on a dual slot (P0973CG) or four slot (P0973CN) expansion base plate, which can be easily installed on a vertical DIN rail, providing installation flexibility.

In terms of compatibility, it is designed to seamlessly collaborate with Foxboro I/A series DCS components, especially FCP 270 and 200 series FBMS. This ensures that it can be integrated into existing Foxboro control systems without compatibility issues. Its power consumption is relatively low, with a maximum power consumption of 2.2 W, which is beneficial for industrial operations that focus on energy conservation.

FEM100 P0973CA

Technical specifications:
Model FEM100 P0973CA
Brand Foxboro
Type fieldbus expansion module
Input voltage range 21-26 V DC
The transmission rate of the 200 series DIN FBMS is 2 Mbps
Maximum power consumption of 2.2 W
Working temperature -20 ° C to+70 ° C (-4 ° F to+158 ° F)
Working relative humidity 5-95% (non condensing)
Working altitude -300 to+3000 meters (-1000 to+10000 feet)
Installation method: Install on the dual slot (P0973CG) or four slot (P0973CN) expansion base plate, which can be installed on a vertical DIN rail
Dimensions (height x width x depth, approximately) 11.4 cm x 4.46 cm x 10.5 cm
Transport weight 3 kilograms
Certified to comply with relevant electrical and environmental safety industry standards

contact us
Phone:+86 16626708626
WhatsApp/WeChat:+86 16626708626
Email: 3772179818@qq.com

FEM100 P0973CA

Application areas:
As power plants continue to strive to meet fluctuating energy demands while maintaining operational safety and efficiency, the ability to add more on-site equipment for precise monitoring and control is crucial. For example, it can be used to connect additional sensors to monitor the temperature and pressure of the boiler, ensuring that the steam generation process remains within the optimal parameter range. This not only improves power generation efficiency, but also helps prevent potential equipment failures that may result in high downtime costs.

Petrochemical plants that handle hazardous substances and complex chemical reactions rely on Foxboro FEM100 P0973CA to enhance their control systems. These factories need to manage a large number of valves, pumps, and reactors. FEM100 allows for the connection of more fieldbus modules, which in turn can interface with various sensors and actuators. This makes the control of chemical processes more precise, such as adjusting the flow rate of reactants in the reactor based on real-time sensor data, thereby reducing the risk of accidents and environmental pollution while maximizing production output.

Manufacturing plants with large-scale production lines also benefit significantly from FEM100 P0973CA. With the increase in production volume and the increasing popularity of product customization, these factories require control systems that can be easily expanded. FEM100 can be used to connect additional modules to control conveyor belt speed, monitor product quality, and manage the operation of manufacturing machinery. This ensures smooth production processes, the ability to quickly respond to any issues on the production line, and the ability to adapt to constantly changing production demands.

FEM100 P0973CA

Related products:
Foxboro FCP270- This is the FEM100 P0973CA field control processor specifically designed for expansion. FCP270 is capable of managing a large number of control tasks, while FEM100 enhances its functionality by allowing for the connection of more fieldbus modules.
The Foxboro FBM200-200 series fieldbus module can be connected to FEM100 P0973CA. FBM200 provides additional input and output channels, which are crucial for connecting various sensors and actuators on site, thereby expanding the data acquisition and control capabilities of the entire system.
Foxboro P0971GN – A power unit that can be used to ensure stable and reliable power supply to FEM100 P0973CA. A stable power supply is crucial for the normal operation of modules, especially in industrial environments where power fluctuations may occur.
Foxboro I/A series operator interface station – can be integrated with systems including FEM100 P0973CA. It provides operators with an easy-to-use interface for monitoring and controlling industrial processes enhanced by the extended features of FEM100, thereby improving overall operational efficiency.
Foxboro Network Management Interface – Connect to systems containing FEM100 P0973CA for managing and optimizing communication networks. Due to the addition of more fieldbus connections in FEM100, proper network management is crucial to ensure smooth data flow between different components of the control system.

FEM100 P0973CA

Installation and maintenance:
Before installing the Foxboro FEM100 P0973CA, the installation process must be carefully planned. Ensure the correct selection and installation of the expansion base plate (dual slot P0973CG or four slot P0973CN) on the vertical DIN rail. Check the power supply to ensure it meets the 21-26 V DC range required by the module. When connecting FEM100 to FCP 270 and 200 series FBMS, carefully check the wiring diagram to ensure proper connection. During installation, take preventive measures to avoid electrostatic discharge, as this may damage sensitive components of the module.

For maintenance, a regular visual inspection plan should be established. Check for any physical signs of damage to the module casing, such as cracks or dents, and inspect for loose connections. Regularly conduct diagnostic tests to verify the communication capability and data transmission accuracy of the module. Maintain firmware updates for modules, as new versions of firmware typically include bug fixes, performance improvements, and enhanced compatibility with other system components.
